Starting System & Charging System (H4SO): Overhaul Subaru Outback BR

Charging System 2 illustrations ~269 words

SWITCH ASSEMBLY

Using a circuit tester (set to "ohm"), check that there is continuity between terminals S and M, and between terminal S and ground.

Also check to be sure there is no continuity between terminals M and B.

Terminal/Resistance

S - M/1 ohms or less

S - Ground/1 ohms or less

M - B/1 Mohms or more

Scheme 58

Scheme 58: SWITCH ASSEMBLY

ASSEMBLY

Assemble in the reverse order of disassembly.

Note. Refer to component for tightening torque of each part. Ref. to GENERATOR , COMPONENT, General Description.

Scheme 59

Scheme 59: ASSEMBLY
  1. Push of the brush Before assembling the front and rear parts, press the brush down into the brush holder, then fix the brush in that position by inserting a [1 mm (0.08 in) dia., 40 - 50 mm (1.6 - 2.0 in) long] wire through the hole as shown in the figure. CAUTION: After re-assembling, remove the wire.
  2. Install the ball bearings. Set the ball bearings in the front cover, then securely install an appropriate tool (such as a socket wrench of proper size) to the bearing outer race. Using a press to press the ball bearings into the specified location. Install the bearing retainer.
  3. Use a press to install the bearings (rear side) to the rotor shaft.
  4. Heat the bearing box in rear cover to 50 - 60°C (122 - 140°F), and then press the rear bearing into rear cover. CAUTION: Do not apply grease to the rear bearings. If there is any oil on the bearing box, remove it completely.
  5. After re-assembling, manually turn the pulley to check that the rotor rotates smoothly.
