TOTAL PRELOAD

Using a spring scale, check the total preload.

Total preload

Except for GT spec. B 6MT model

20.7 - 54.4 N (2.1 -5.5 kgf, 4.7 - 12.2 lb)

GT spec. B 6MT model

27.0 - 54.0 N (2.8 - 5.5 kgf, 6.1 - 12.2 lb)

If the total preload is not within the specification, adjust the side bearing retainer shims.

Scheme 118

Scheme 118: COMPANION FLANGE
Scheme 118: COMPANION FLANGE

Scheme 119

Scheme 119
Scheme 119
  1. If rust or dirt is attached to the companion flange, remove them.
  2. Set a dial gauge at a companion flange surface (mating surface of propeller shaft and companion flange), and then measure the companion flange runout. Limit of runout: 0.08 mm (0.003 in)
  3. Set the gauge inside of the companion flange, and measure the runout. Limit of runout: 0.08 mm (0.003 in)
  4. If either runout exceeds the limit, move the phase of companion flange and drive pinion 90° each, and find the point where the runout is within the limit.
  5. If the runout exceeds the limit even after changing the phase, replace the companion flange and recheck the runout.
  6. If the runout exceeds the limit after replacing the companion flange, the drive pinion may be assembled incorrectly or bearing is faulty.

Adjust the side gear backlash.

ASSEMBLY, Rear Differential (T-type).>

Adjust hypoid driven gear backlash.

ASSEMBLY, Rear Differential (T-type).>

Adjust the tooth contact between hypoid driven gear and drive pinion gear.

ASSEMBLY, Rear Differential (T-type).>

Adjust the side bearing shim.

ASSEMBLY, Rear Differential (T-type).>

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121

Scheme 122

Scheme 122
Scheme 122
  1. Disconnect the ground cable from the battery.
  2. Shift the select lever or gear shift lever to neutral.
  3. Release the parking brake.
  4. Lift the vehicle.
  5. Remove the rear exhaust pipe and muffler.
  6. Remove the heat shield cover.
  7. Remove the propeller shaft. REMOVAL , Propeller Shaft.>
  8. Prepare the transmission jack and band.
  9. Loosen the self-lock nuts which hold the rear differential to rear crossmember.
  10. Remove the DOJ of rear drive shaft from rear differential.
  11. Remove the nuts which hold the rear differential front member.
  12. Support the rear differential with the transmission jack.
  13. Remove the rear differential front member.
  14. Secure the rear differential using band.
  15. Remove the self-lock nuts which hold the rear differential to rear crossmember.
  16. Remove the rear differential stud bolt from rear crossmember bushing. NOTE: When removing the stud bolt, carefully adjust the angle and location of transmission jack and jack stand, if necessary.
  17. Lower the transmission jack stand after removing the rear differential stud bolt from the rear crossmember. Rear drive shaft should not come into contact with the lateral link bolt.
  18. Pull out the axle shaft from rear differential. NOTE: If it is difficult to remove the axle shaft from rear differential, remove it using tire lever.
  19. Lower the transmission jack.
  20. Secure the rear drive shaft to lateral link using wire.
  21. Remove the rear differential member plate from rear differential.

Scheme 123

Scheme 123: INSTALLATION
Scheme 123: INSTALLATION

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126
  1. Insert the rear differential member plate into rear differential.
  2. Set the rear differential to transmission jack. NOTE: Secure the rear differential to transmission jack using band.
  3. Attach the ST to rear differential. ST 28099PA090 OIL SEAL PROTECTOR
  4. Insert the spline shaft until the spline portion comes inside the side oil seal.
  5. Remove ST from rear differential. ST 28099PA090 OIL SEAL PROTECTOR
  6. Push the rear differential to insert the axle shaft into rear differential.
  7. Adjust the transmission jack, if necessary, and insert the rear differential stud bolt into rear cross-member bushing properly.
  8. After inserting the rear differential stud bolt into the rear crossmember bushing, lift up the transmission jack and align the rear differential to its attachment position.
  9. Tighten a new self-locking nut temporarily to rear crossmember.
  10. Remove the band from rear differential. Lift up the rear differential until the rear differential is separated from the transmission jack.
  11. Install the rear differential front member with a new self-locking nut. Tightening torque: T1:50 N.m (5.1 kgf-m, 36.9 ft-lb) T2:110 N.m(11.2 kgf-m, 81 ft-lb)
  12. Tighten the self-locking nut. Tightening torque: 70 N.m (7.1 kgf-m, 51 ft-lb)
  13. Lower the transmission jack.
  14. Install the propeller shaft. INSTALLATION , Propeller Shaft.>
  15. Install the heat shield cover.
  16. Install the rear exhaust pipe and muffler.
