ADJUSTMENT

Operate the wiper once. Align the wiper blade to ceramic print point mark (A) of front window panel.

Scheme 8

1. Disconnect the ground cable from battery.
2. Remove the cowl panel. < Ref. to «REMOVAL»(ref-288634-S15537470112008062500000) , Cowl Panel. >
3. Disconnect the connector of wiper motor assembly.
4. Remove the bolt, and then remove the wiper assembly. NOTE: The wiper motor and wiper link is an assembly part and is not to be disassembled.

Scheme 9

Scheme 10

1. Turn the wiper switch to OFF position.
2. While the vehicle is at a standstill, adjust the washer injection position as shown in the figure. Spray position: A: 250 mm (9.84 in) B: 535 mm (21.06 in)
3. Spray angle should be adjusted by rotating adjusting dial (A) with a flat tip screwdriver. NOTE: Adjusting dial will return to the original spray angle with 1 rotation.

Scheme 11

1. Detach the wiper arm cover (A).
2. Remove the nut (B) to remove the wiper arm.

Scheme 12

1. Install in the reverse order of removal.
2. Operate the rear wiper once.
3. Align the blade with the marking (A) of the glass. Tightening torque: Refer to " «COMPONENT»(ref-303096-S39300703192008102300000) " of "General Description". < Ref. to «REAR WIPER (WAGON MODEL)»(ref-303096-S29938091162008102300000) , COMPONENT, General Description. >

1. Operate the rear wiper once.
2. Align the blade with the marking (A) of the glass.

Scheme 13

1. Disconnect the ground cable from battery.
2. Remove the rear wiper arm. < Ref. to «REMOVAL»(ref-303096-S25447422372008102300000) , Rear Wiper Arm. >
3. Remove the rear gate lower trim. < Ref. to «REMOVAL»(ref-288634-S06245839382008062500000) , Rear Gate Trim. >
4. Disconnect the harness connector of wiper motor assembly.
5. Remove the bolts to remove wiper motor assembly (A).

Scheme 14

1. Install in the reverse order of removal.
2. Be sure that the pivot cap with the arrow mark facing up, as shown in the figure. Tightening torque: Refer to " «COMPONENT»(ref-303096-S39300703192008102300000) " of "General Description". < Ref. to «REAR WIPER (WAGON MODEL)»(ref-303096-S29938091162008102300000) , COMPONENT, General Description. >

Scheme 15

Scheme 16

Scheme 17

1. Connect the battery to the wiper motor connector and confirm that wiper motor operates.
2. Connect the battery to the terminals to the connector, then run the wiper motor at low speed and disconnect the terminal in mid motion.
3. Connect the battery and confirm that the wiper motor stops at the automatic stop position after the wiper motor operates at low speed again.

Scheme 18

1. Detach the roof spoiler. < Ref. to «REMOVAL»(ref-288634-S39521640312008062500000) , Roof Spoiler. >
2. Remove the washer hose from washer nozzle.
3. Push the claw of the nozzle from the reverse side of roof spoiler with a flat tip screwdriver or equivalent, and remove the washer nozzle.
