SPECIFICATION
| Model | OUTBACK except for 3.0 R | OUTBACK 3.0 R | ||
|---|---|---|---|---|
| Whole system | Minimum turning radius | M (ft) | Excluding 2.5 GT spec. B: 5.4 (17.8) 2.5 GT spec. B: 5.8 (19) | |
| Steering angle | Inner wheel | Excluding 2.5 GT spec. B: 37.6°±1.5° 2.5 GT spec. B: 33.8°+1.5° | ||
| Outer wheel | Excluding 2.5 GT spec. B: 33.0°±1.5° 2.5 GT spec. B:30.2°±1.5° | |||
| Steering wheel diameter | Mm (in) | 375 (14.76) | ||
| Lock to lock turn | Excluding 2.5 GT: 3.2, 2.5 GT: 2.8 | |||
| Gearbox | Type | Rack and Pinion, Integral | ||
| Backlash | 0 (Automatic adjusting) | |||
| Valve (Power steering system) | Rotary valve | |||
| Pump (Power steering system) | Type | Vane pump | ||
| Oil tank | Installed on body | |||
| Specific output | Cm 3 (cu in)/rev. | 8.5 (0.519) | 9.6 (0.586) | |
| Relief pressure | KPa (kg/cm 2 , psi) | 7,350 - 8,050 (75 - 82,1,067-1,167) | 8,300 - 9,000 (85 - 92,1,204-1,305) | |
| Hydraulic fluid control | Engine speed sensitive | |||
| Hydraulic fluid | L (USqt, lmp qt) | 1,000 rpm: 6.15 (6.5, 5.4) 3,000 rpm: 5.5 (5.8, 4.8) | 1,000 rpm: 6.5 (6.9, 5.7) 3,000 rpm: 5.5 (5.8, 4.8) | |
| RPM range | Rpm | 680 - 9,600 | ||
| Direction of rotation | Clockwise | |||
| Hydraulic oil (Power steering system) | Description | ATF DEXRON III or equivalent | ||
| Capacity l (US qt, lmp qt) | Oil tank | 0.2 (0.2, 0.2) | ||
| Whole system | 0.7 (0.7, 0.6) | |||
SPECIFICATION CHART
| Steering wheel | Free play | Mm (in) | 17(0.67) | |
|---|---|---|---|---|
| Steering shaft | Clearance between the steering wheel and column cover | Mm (in) | 3.0 (0.12) | |
| Steering gearbox (Power steering system) | Rack shaft play in the radial direction | Right-turn steering | Mm (in) | 0.12 (0.005) or less |
| Input shaft play | In radial direction | Mm (in) | 0.26 (0.01) or less | |
| In axial direction | Mm (in) | Without play | ||
| Rotation resistance | N (kgf, lb) | Maximum allowable value: 11.3 (1.15, 2.54) or less Difference between right and left sliding resistance: 24% or less | ||
| Oil pump (Power steering system) | Pulley shaft | Radial play | Mm (in) | 0.4 (0.016) or less |
| Axial play | Mm (in) | 0.9 (0.035) or less | ||
| Pulley | Ditch deflection | Mm (in) | 1.0 (0.039) or less | |
| Rotation resistance | N (kgf, lb) | 9.22 (0.94, 2.07) or less | ||
| Regular pressure (Unloaded) | KPa (kg/cm 2 , psi) | 981(10,142) or less | ||
| Steering wheel effort (Power steering system) | At standstill with engine idling on paved road | N (kgf, lb) | 29.4 (3.0, 6.6) or less | |
| At standstill with engine stalled on paved road | N (kgf, lb) | 294.2 (30, 66.2) or less | ||
SPECIFICATION CHART
| Recommended power steering fluid | Manufacturer |
|---|---|
| ATF DEXRON III or equivalent | B.R |
| CALXEX | |
| CASTROL | |
| MOBIL | |
| SHELL | |
| TEXACO |
POWER STEERING FLUID SPECIFICATION
Scheme 17
Scheme 18
Scheme 19
- Hose and tank
- Gearbox
Scheme 20
Scheme 21
- H4 model
- H6 model
| Recommended power steering fluid | Manufacturer |
|---|---|
| ATF DEXRON III or equivalent | B.P. |
| CALTEX | |
| CASTROL | |
| MOBIL | |
| SHELL | |
| TEXACO |
POWER STEERING FLUID SPECIFICATION
Scheme 22
- Check the power steering fluid for deterioration or contamination. If the fluid is highly deteriorated or contaminated, drain it and refill with new fluid.
- Check the joints and units for oil leakage. If any oil leaks are found, repair or replace the applicable part.
- Inspect the fluid level of reservoir tank with vehicle on level surface and engine stopped. If the level is at "MIN." point or below, add fluid to keep the level in the specified range of the indicator. If fluid level is at "MAX." point or above, drain fluid by using a syringe or the like. Check at power steering fluid temperature 20°C (68°F); read the fluid level on the "COLD" side. Check at power steering fluid temperature 80°C (176°F); read the fluid level on the "HOT' side.
