SPECIAL TOOL
SPECIAL TOOL ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 398477701 HANDLE Used for installing the front and rear bearing cones. 398477702 DRIFT Used for press-fitting the bearing cone of differential carrier (front). For T-type 398217700 ATTACHMENT SET Stand for rear differential carrier disassembly and assembly. 498447120 INSTALLER Used for installing the front oil seal. 498427200 FLANGE WRENCH Used for stopping rotation of companion flange when removing and tightening self-lock nut. 398467700 DRIFT Used for removing pinion, pilot bearing and front bearing cone. For T-type and VA1 -type 399780104 WEIGHT Used for installing the front bearing cone and the pilot bearing companion flange. 899580100 INSTALLER Used for press-fitting the front bearing cone and pilot bearing. 899904100 STRAIGHT PIN REMOVER Used for driving out differential pinion shaft lock pin. 498247001 MAGNET BASE Used for measuring backlash between side gear and pinion, and hypoid gear. Used together with the DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring backlash between side gear and pinion, and hypoid gear. Used together with the MAGNET BASE (498247001). 398507704 BLOCK Used for adjusting pinion height and preload. For T-type and VA1 -type 398177700 INSTALLER Used for installing the rear bearing cone. For T-type and VA2-type 398457700 ATTACHMENT Used for removing the side bearing retainer. For T-type 398477703 DRIFT 2 Used for press-fitting bearing race (rear) of differential carrier. For T-type and VA2-type 398437700 DRIFT Used for installing the side oil seal. For T-type and VA2-type 398507702 DUMMY SHAFT Used for adjusting pinion height and preload. For T-type 398507703 DUMMY COLLAR Used for adjusting pinion height and preload. For T-type 398517700 REPLACER Used for removing rear bearing cone. For T-type and VA2-type 398487700 DRIFT Used for press-fitting side bearing cone. For T-type and VA2-type 398507701 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For T-type 398527700 PULLER ASSY Used for removing front oil seal. Used for removing side bearing cup. (T-type) 28099PA090 OIL SEAL PROTECTOR Used for installing the rear drive shaft to the rear differential. For oil seal protection 28099PA100 DRIVE SHAFT REMOVER Used for removing the rear drive shaft from rear differential. For T-type 399703600 PULLER ASSY Used for removing companion flange. 899874100 INSTALLER Used for installing the companion flange. 498077000 REMOVER Used for removing the differential side bearing cone. For VA2-type 899864100 REMOVER Used for removing the differential side bearing. 499277200 INSTALLER Used for installing the front bearing cone. For VA2-type 18758AA000 PULLER Used for removing side bearing cup. For VA2-type 18759AA000 PULLER ASSY Used for removing the differential side bearing cone. For T-type 18678AA000 DUMMY SHAFT Used for adjusting pinion height and preload. For VA2-type 18831AA010 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For VA2-type 18630AA010 WRENCH ASSY Used for removing and installing the side oil seal holder. For VA2-type NOTE: Also available for VA1 -type. 498175500 INSTALLER Used for installing the rear bearing cone. For VA1-type 499785500 WRENCH ASSY Used for removing and installing the side oil seal holder. For VA1-type 498447100 INSTALLER Used for installing the oil seal. For VA1-type and T-type 399520105 SEAT Used for removing the side bearing cone. Used together with the PULLER SET (899524100). For VA-type 498485400 DRIFT Used for installing side bearing cone. For VA1-type 498505501 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For VA1 -type 498447110 DRIFT Used for press-fitting the bearing race (front) of the differential carrier. For VA1-type 498447150 DUMMY SHAFT Used for adjusting pinion height and preload. For VA1 -type 899524100 PULLER SET Used for removing the differential side bearing cone. Puller Cap 498515500 REPLACER Used for removing rear bearing cone. For VA1 -type 32285AA000 DUMMY COLLAR Used for adjusting pinion height and preload. For VA1-type 499705404 SEAT Used for removing the side bearing race. Used together with PULLER ASSY (499705401). For VA1-type 499705401 PULLER ASSY Used for removing the side bearing race. Used together with SEAT (499705404). For VA-type
