GENERAL DESCRIPTION
The on-board diagnosis function of the cruise control system uses Subaru Select Monitor. The on-board diagnosis function operates in two categories, which are used depending on the type of problems
- Cruise Control Cancel Conditions Diagnosis: This category of diagnosis requires actual vehicle driving in order to determine the cause, as when cruise speed is cancelled during driving although cruise cancel condition is not entered. Cruise control memory in ECM stores the cancel condition (Code No.) which occurred during driving. When there are multiple cancel conditions (Code No.), they are shown on the Subaru Select Monitor. CAUTION: The cruise control memory stores not only the cruise "cancel" which occurred (although "cancel" operation is not entered by the driver), but also the "cancel" condition input by the driver. The latest memory content (latest code) is cleared when ignition switch is turned to OFF. However, the memory content by the diagnosis of faulty switches relating to the system and cruise control is retained as the fault history (memory code) after the ignition switch is turned OFF.
- Real-time Diagnosis: Real-time diagnosis function is used to determine whether or not the input signal system is in good order, according to signal emitted from switches, sensors, etc. Vehicle cannot be driven at cruise speed when the problem occurs in the cruise control system or relevant circuits. Monitor the signal conditions from switches and sensors.
Scheme 10
- Prepare the Subaru Select Monitor kit.
- Connect the diagnosis cable to the Subaru Select Monitor.
- Connect the Subaru Select Monitor to the data link connector. Data link connector is located in the lower portion of the instrument panel (on the driver's side). Connect the diagnosis cable to the data link connector.
- Start the engine and turn the cruise control main switch to ON.
- Start up the Subaru Select Monitor.
- Select {2. Each System Check} in «Main Menu». On the system selection display screen, select the {Engine Control System} and the [OK]. Select the [OK] after the information of engine type is displayed.
- Drive vehicle at 40 km/h (25 MPH) or more and set the cruise control. CAUTION: When performing diagnosis, observe the legal speed limit on the road. DTC will be also displayed when cruise control is cancelled by the driver's operation. Do not confuse them. Be sure to get an assistant to support the diagnosis while driving, and have him/her operate the select monitor.
- When the set speed is canceled by itself (without any cancel operations such as applying brake) or when the cruise control could not be set by performing the setting operation, selecting the {Check Cancel Code} on the engine malfunction diagnosis screen will display the DTC on the select monitor display. NOTE: There are {Latest Code} and {Memorized Diagnostic Code(s)} in DTC. The latest code recognized during current test drive is displayed in {Latest Code}. DTCs by the diagnosis of faulty switches relating to the system and cruise control are displayed in {Memorized Diagnostic Code(s)}.
- Perform Engine DTC Clear Memory operation. < Ref. to «CLEAR MEMORY MODE»(/subaru/outback/bp-2006-2009/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so) (H4SO). > < Ref. to (H4DOTC) «OPERATION»(/subaru/outback/bp-2006-2009/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4dotc) , Clear Memory Mode . > < Ref. to (H6DO) «OPERATION»(/subaru/outback/bp-2006-2009/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h6do) , Clear Memory Mode . > DTCs of switches relating to the system and cruise control are deleted by clearing memory on the engine side. NOTE: The latest code will be cleared by turning ignition switch to OFF.
