SWITCH ASSEMBLY OPERATION

Note. Test period of each test must be within short time (3 - 5 seconds).

Scheme 5

Scheme 6

Scheme 7

1. Vacuum test Disconnect the harness from terminal M and connect it as shown in the figure. Make sure the pinion gear sticks out.
2. Hold test Make sure the pinion gear remains stick out even after disconnecting terminal M in the above condition.
3. Return test Connect the positive terminal to terminal S and the negative terminal to terminal M and starter body to pull the pinion gear at the main contact point. Make sure the pinion gear returns to its original position when the terminal S is disconnected.
