Transmission 2.5l — 2.5l, a/t circuit Subaru Outback BP
All systems — 53 systems
- Air conditioning 2.0l turbo
- Air conditioning 2.5l
- Air conditioning 2.5l turbo
- Air conditioning 3.0l
- Anti-lock brakes 3
- Anti-theft 2
- Body control modules
- Computer data lines 2.0l turbo
- Computer data lines 2.5l
- Computer data lines 2.5l turbo
- Computer data lines 3.0l
- Cooling fan 2.0l turbo
- Cooling fan 2.5l
- Cooling fan 2.5l turbo
- Cooling fan 3.0l
- Cruise control 2.0l turbo
- Cruise control 2.5l 3
- Cruise control 2.5l turbo
- Cruise control 3.0l
- Defoggers 3
- Engine performance 2.0l turbo
- Engine performance 2.5l 3
- Engine performance 2.5l turbo
- Engine performance 3.0l
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 2
- Instrument cluster 2.0l turbo
- Instrument cluster 2.5l
- Instrument cluster 2.5l turbo
- Interior lights 2
- Interior lights 2.0l turbo
- Interior lights 2.5l
- Interior lights 2.5l turbo
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 2
- Power top/sunroof 3
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 2
- Starting/charging 2.5l 2
- Starting/charging 3.0l
- Supplemental restraints
- Transmission 2.0l turbo
- Transmission 2.5l 5
- Transmission 3.0l 2
- Warning systems
- Wiper/washer 3
Components on these wiring diagrams 35
Click a component to highlight it on every diagram it appears on.
