MEANING OF V.I.N.
The meaning of the VIN is as follows
North America
] 4S3BE635X17200001 [
The starting and ending brackets (][) are stop marks.
Meaning Of V.I.N. Chart. Scheme 4
MODEL NUMBER PLATE
The model number plate indicates: the applied model, the option code, the trim code, the engine type, the transmission type, and the exterior color code. This information is helpful when placing orders for parts.
BE9BY3J
Model Number Plate Chart. Scheme 5
The engine and transmission type are as follows
Engine
EZ30DAXBBB
Engine Identification Chart. Scheme 6
Transmission
TV1A4YCAAA
Transmission Identification Chart. Scheme 7
Rear differential 1
VA1REF
Rear Differential 1 Identification Chart. Scheme 8
Rear differential 2
T1
Rear Differential 2 Identification Chart. Scheme 9
Dimensions Specifications Chart. Scheme 10
| Model | Sedan/Station Wagon | |
|---|---|---|
| Engine type | Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine | |
| Valve arrangement | Overhead camshaft type | |
| Bore x Stroke | Mm (in) | 99.5 x 79.0 (3.917 x 3.110) |
| Displacement | Cm 3 (cu in) | 2,457 (149.9) |
| Compression ratio | 10.0 | |
| Firing order | 1-3-2-4 | |
| Idle speed at Park/Neutral position | Rpm | 650 (MT), 700 (AT) |
| Maximum output | KW (HP)/rpm | 123(165)/5,600 |
| Maximum torque | N.m (kgf-m, ft-lb)/rpm | 226 (23.0, 166)/3,600 |
Engine Specifications Chart
Electrical Specifications Chart. Scheme 11
Transmission Specifications Chart. Scheme 12
Steering Specifications Chart. Scheme 13
Suspension Specifications Chart. Scheme 14
Brake Specifications Chart. Scheme 15
Tire Specifications Chart. Scheme 16
Capacity Specifications Chart. Scheme 17
WEIGHT
- U.S. SPEC. VEHICLE
Weight Specifications Chart. Scheme 18
Weight Specifications Chart. Scheme 19
Weight Specifications Chart. Scheme 20
- CANADA SPEC. VEHICLE
Weight Specifications Chart. Scheme 21
Weight Specifications Chart. Scheme 22
Dimensions Specifications Chart. Scheme 23
| Model | Sedan/Station Wagon | |
|---|---|---|
| Engine type | Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine | |
| Valve arrangement | Overhead camshaft type | |
| Bore x Stroke | Mm (in) | 99.5 x 79.0 (3.917 x 3.110) |
| Displacement | Cm 3 (cu in) | 2,457 (149.9) |
| Compression ratio | 10.0 | |
| Firing order | 1-3-2-4 | |
| Idle speed at Park/Neutral position | Rpm | 650 (MT), 700 (AT) |
| Maximum output | KW (HP)/rpm | 123 (165)/5,600 |
| Maximum torque | N.m (kgf-m, ft-lb)/rpm | 226 (23.0, 166)/3,600 |
Engine Specifications Chart
Electrical Specifications Chart. Scheme 24
Transmission Specifications Chart. Scheme 25
Steering Specifications Chart. Scheme 26
Suspension Specifications Chart. Scheme 27
Brake Specifications Chart. Scheme 28
Tire Specifications Chart. Scheme 29
Capacity Specifications Chart. Scheme 30
- U.S. SPEC. VEHICLE
Weight Specifications Chart. Scheme 31
Note. When following optional parts are installed, add the weight to the curb weight.
Weight Specifications Chart. Scheme 32
- CANADA SPEC. VEHICLE
