Basic Diagnostic Chart (Without Subaru Select Monitor) - (1 Of 2). Scheme 109
Basic Diagnostic Chart (Without Subaru Select Monitor) - (2 Of 2). Scheme 110
| CAUTION | Remove foreign matter (dust, water, etc.) from the VDCCM connector during removal and installation. |
Note. To check harness for broken wires or short circuits, shake it while holding it or the connector. When ABS and/or VDC warning light illuminates, read and record trouble code indicated by ABS warning light.
Basic Diagnostic Chart (With Subaru Select Monitor). Scheme 111
Note. To check harness for broken wires or short circuits, shake it while holding it or the connector. Check list for interview. See Check List for Interview .
OPERATION
Reproduce the condition under which the problem has occurred as much as possible. Drive the vehicle at least ten minutes.
Note. Make sure vehicle does not pull to one side during normal driving.
Scheme 112
Identifying Trouble Codes (Without Subaru Select Monitor). Scheme 113
- After calling up a trouble code, disconnect diagnosis connector terminal 8 from diagnosis terminal. see scheme 31: Identifying Diagnosis Connector Terminals
- Repeat 3 times within approx. 12 seconds; connecting and disconnecting terminal 8 and diagnosis terminal for at least 0.2 seconds each time. see scheme 32: Time Line Identification Chart
Note. After diagnostics is completed, make sure to clear memory. Make sure only start code (11) is shown after memory is cleared.
