1995-96 ACCESSORIES & EQUIPMENT Subaru Power Mirrors
| Terminal No. (1) | Wire Color | Function |
|---|---|---|
| 1 | Red/Blue | Right, Left/Right Movement |
| 2 | Black/Red | Left, Left/Right Movement |
| 4 | Green | Power |
| 6 | Brown/Red | Right, Up/Down Movement |
| 7 | Blue/Red | Left, Up/Down Movement |
| 10 | Red | (2) Both Mirrors, Both Motors |
| 11 | Black | Ground |
| (1) Unlisted terminals are not used. (2) This wire is a power or ground circuit (depending on switch position) for motors in left and right mirror assemblies. | ||
| (1) | Unlisted terminals are not used. |
| (2) | This wire is a power or ground circuit (depending on switch position) for motors in left and right mirror assemblies. |
POWER MIRROR SWITCH CONNECTOR TERMINAL IDENTIFICATION
POWER MIRROR SWITCH
Pry mirror switch from instrument panel using a small screwdriver. Disconnect switch connector. Check continuity between specified terminals of switch connector with switch button in specified position. See POWER MIRROR SWITCH CONTINUITY TEST. (Scheme 3) Replace switch if continuity is not as specified.
| Switch Position | Terminal No. | |
|---|---|---|
| Left Mirror | ||
| Up | 4 & 7, 10 & 11 | |
| Down | 4 & 10, 7 & 11 | |
| Left | 2 & 4, 10 & 11 | |
| Right | 4 & 10, 2 & 11 | |
| Right Mirror | ||
| Up | 4 & 6, 10 & 11 | |
| Down | 4 & 10, 6 & 11 | |
| Left | 1 & 4, 10 & 11 | |
| Right | 4 & 10, 1 & 11 | |
POWER MIRROR SWITCH CONTINUITY TEST
Scheme 3
POWER MIRROR MOTOR
Remove door panel. Disconnect mirror motor harness connector. Using 12-volt power supply and 2 jumper wires, apply voltage and ground to specified terminal. See POWER MIRROR MOTOR TEST. (Scheme 4)
| Movement | Terminal No. (+) | Terminal No. (-) |
|---|---|---|
| Up | 1 | 3 |
| Down | 3 | 1 |
| Left | 2 | 3 |
| Right | 3 | 2 |
POWER MIRROR MOTOR TEST
