Engine Controls - Adjustments Subaru Outback BG

Adjustments 1 illustration ~312 words

ENGINE MECHANICAL

Before performing any on-vehicle adjustments to fuel or ignition system, ensure engine mechanical condition is okay.

VALVE CLEARANCE

Note. All models are equipped with hydraulic lash adjusters. No adjustment is required.

IGNITION TIMING

  1. Ensure engine is at normal operating temperature and idle speed is correct. Set transaxle in Neutral (M/T) or Park (A/T) position. Connect timing light to No. 1 spark plug wire.
  2. Observe timing marks, located on crankshaft pulley. See IGNITION TIMING SPECIFICATIONS table. If timing is not as specified, check self-diagnostic system for Diagnostic Trouble Codes (DTCs). Repair as necessary. See appropriate «TESTS W/CODES»(ref-26249) article.
ApplicationAuto. Trans.Man. Trans.
Legacy12-28 @ 7006-22 @ 700

IGNITION TIMING (Degrees BTDC @ RPM)

IDLE SPEED & MIXTURE

Note. Idle mixture is ECM controlled. Adjustment is not required.

COLD (FAST) IDLE

Note. Fast idle is ECM controlled. Adjustment is not required.

IDLE SPEED

  1. Ensure air filter is clean, vacuum hoses are properly routed, and timing is correct. Warm engine to operating temperature. Connect inductive pick-up tachometer to No. 1 spark plug wire. NOTE: Because spark plugs No. 1 and 2 fire simultaneously, some tachometers may register twice actual engine speed.
  2. Check idle speed with all accessories off, then with all accessories on. See IDLE SPEED SPECIFICATIONS table. If idle speed is not as specified, check self-diagnostic system for DTC(s). Repair as necessary. See «TESTS W/CODES»(ref-26249) article.
ApplicationRPM
With Accessories Off600-800
With Accessories On800-900

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION (TP) SENSOR

Note. All testing procedures are performed with engine at normal operating temperature. For further TP sensor diagnosis, see appropriate TESTS W/CODES article.

With engine off, unplug TP sensor harness connector. Check and record resistance between terminals No. 2 and 3 with throttle fully closed. (Scheme 1) Check and record resistance between terminals No. 2 and 4 with throttle fully closed, then with throttle fully open. If readings are not as specified, replace TP sensor. See TP SENSOR SPECIFICATIONS table.

Throttle Position & Terminal No.Specification
Terminals No. 2 & 312,000 Ohms
Terminals No. 2 & 4 Ohms
Throttle Fully Closed10,000-12,000 Ohms
Throttle Fully Open3000-5000 Ohms

TP SENSOR SPECIFICATIONS

Scheme 1
