GENERAL TOOL Subaru Legacy BN/BS

GENERAL TOOL

Scheme 181

1. Park the vehicle on a level surface.
2. Turn the ignition switch to OFF, and wait until the engine cools.
3. Remove the oil level gauge and wipe it clean.
4. Reinsert the oil level gauge all the way. Be sure that the oil level gauge is correctly inserted in the proper direction.
5. Pull out the oil level gauge again, and check the oil level. If it is below the lower level, add oil through the oil level gauge hole to bring the level up to the upper level.

Scheme 182

1. Pull out the oil level gauge.
2. Lift up the vehicle.
3. Using the TORX® bit T70, remove the drain plug, and drain the transmission gear oil completely. CAUTION: Immediately after the vehicle has been running or after idling for a long time, the transmission gear oil will be hot. Be careful not to receive burns. Be careful not to spill the transmission gear oil on the exhaust pipe, to prevent emission of smoke or causing a fire. If gear oil is spilt, wipe it off completely.
4. Tighten the drain plug using TORX® bit T70. NOTE: Use a new gasket. Tightening torque: 44 N.m (4.5 kgf-m, 32.5 ft-lb) (Aluminum gasket silver) 70 N.m (7.1 kgf-m, 51.6 ft-lb) (Copper gasket, brown) 70 N.m (7.1 kgf-m, 51.6 ft-lb) (Metal gasket, black)
5. Lower the vehicle.
6. Pour gear oil through the oil level gauge hole. Recommended gear oil: GL-5 (75W-90) or equivalent Gear oil capacity: 3.3 L (3.5 US qt, 2.9 Imp qt)
7. Measure the transmission gear oil amount, and check that it is within the specification.

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

1. Set the vehicle on a lift.
2. Remove the front wheels.
3. Open the front hood completely.
4. Remove the air intake duct. Refer to «REMOVAL»(ref-645985-S11870961922014072500000) .
5. Remove the 10 clips and detach the grille bracket.
6. Disconnect the ground cable from battery.
7. Remove the radiator fan.
8. Remove the air intake boot assembly. Refer to «REMOVAL»(ref-645985-S19408889572014072500000) .
9. Disconnect the engine harness connector.
10. Disconnect the connector back-up light switch & neutral position switch.
11. Disconnect the transmission radio ground terminal.
12. Remove the throttle body. Refer to «REMOVAL»(ref-645983-S08040174612014072500000) .
13. Remove the starter. Refer to «REMOVAL»(ref-646021-S26218928502014072500000) .
14. Remove the operating cylinder from the transmission, and suspend on a wire.
15. Lift up the vehicle.
16. Remove the front under cover. Refer to «REMOVAL»(ref-646002-S00701002792014072500000) .
17. Drain transmission gear oil completely. Refer to «REPLACEMENT»(ref-645990-S23308059222014072500000) .
18. Remove the center exhaust pipe. Refer to «REMOVAL»(ref-646019-S20066601862014072500000) and «REMOVAL»(ref-646019-S19251222692014072500000) .
19. Remove the heat shield cover.
20. Remove the steering shaft universal joint. Refer to «REMOVAL»(ref-646000-S32412901232014072500000) .
21. Remove the propeller shaft. Refer to «REMOVAL»(ref-645998-S02224167242014072500000) .
22. Remove the MT gear shift cable and MT gear select cable from MT gear shift lever. Refer to «REMOVAL»(ref-646009-S04710020592014072500000) . CAUTION: Do not bend MT gear shift cable and MT gear select cable at a sharp angle. Disconnect the MT gear shift cable and MT gear select cable at the MT gear shift lever side. Always use new MT gear select cable if the cable is removed from selector lever COMPL of transmission side.
23. Disconnect the stabilizer link from the front arm. Refer to «REMOVAL»(ref-645996-S00915542132014072500000) .
24. Remove the bolt securing the ball joint of the front arm to the housing, then separate the front arms and the housing. Refer to «REMOVAL»(ref-645996-S37463635892014072500000) .
25. Separate the front drive shafts on both sides from the transmission. Refer to «REMOVAL»(ref-645998-S03685232552014072500000) .
26. Lower the vehicle.
27. Remove the nuts connecting the engine mounting and the transmission main mounting bracket.
28. Set the ST on the vehicle. CAUTION: Set the chain so that it does not contact the sensors. Set the arms of ST (ENGINE HANGER) at the locations shown in the figure. ST1 99099AJ000 ENGINE HANGER ST2 99099AJ010 CHAIN BALANCER
29. Lift the engine slightly and remove the bolts of front cushion rubber.
30. Remove the nut and bolt of the front cushion rubber, then remove the front cushion rubber.
31. Temporarily attach ST by using two bolts. ST 41099AJ130 SPECIAL TOOL FB
32. Lift up the engine unit high enough to install the bolt and nut to vehicle. CAUTION: Do not lift up higher than enough level to install the ST to avoid damage to the hoses and pipes inside the engine room. Do not tighten the bolts and nuts excessively, or the engine mounting bracket may be deformed. NOTE: If it is difficult to pull out the stud bolt from transmission mounting bracket, slightly shake the engine unit while lifting up.
33. Tighten the mounting bolts on the engine side. Tightening torque: 25 N.m (2.6 kgf-m, 18.4 ft-lb)
34. Remove the ST (ENGINE HANGER).
35. Remove the transmission main mounting bracket. NOTE: First, remove the transmission mounting bracket on the right side of vehicle, and then tilt the engine unit to remove the left transmission mounting bracket.
36. Remove the two mounting bolts on the upper side of the transmission.
37. Set the ST (ENGINE HANGER) again to loosen the chain sling.
38. Lift up the vehicle.
39. Place the transmission jack under the transmission. CAUTION: Always support the transmission case with a transmission jack.
40. Remove the bolts and nuts which hold lower side of transmission to engine.
41. Remove the front crossmember and rear crossmember from the vehicle.
42. Lower the transmission rear end (dust cover rear end). CAUTION: When lowering the transmission rear end, be careful not to let the converter case and steering mechanical parts contact each other. NOTE: Lower the transmission rear end by approx. 80 mm (3.1 in) (reference).
43. Rotate the handle of ST (ENGINE HANGER) to apply tension to the chain sling.
44. Remove the transmission assembly. NOTE: Move the transmission jack towards the rear until the main shaft is withdrawn from the clutch disc. Remove it while moving the transmission jack up and down so that the engine and transmission remain directly aligned.
45. Remove the transmission cushion rubber.

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

1. Replace the differential side retainer oil seal. Refer to «REPLACEMENT»(ref-645990-S37839474572014072500000) . NOTE: Be sure to replace the differential side retainer oil seal after removing the front drive shaft. ST 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER
2. Install the transmission cushion rubber to the transmission assembly, and tighten bolt (A).
3. Install the transmission cushion rubber to the center crossmember, and tighten the nut (B). Tightening torque: Bolt (A) 35 N.m (3.6 kgf-m, 25.8 ft-lb) Nut (B) 35 N.m (3.6 kgf-m, 25.8 ft-lb)
4. Tap the transmission hanger in the rear side of transmission with a rubber hammer to bend it until it is in close contact with the transmission case. CAUTION: Do not apply excessive load or impact to the transmission case.
5. Install the transmission onto the engine. CAUTION: This operation requires at least two persons. NOTE: Keep the engine level. Lift up the transmission gradually using a transmission jack. Engage at the spline section. NOTE: Be careful not to hit the main shaft against the clutch housing cover.
6. Temporarily tighten the bolts and nuts which hold lower side of transmission to engine.
7. Install the front crossmember and rear crossmember. Tightening torque: T1: 75 N.m (7.6 kgf-m, 55.3 ft-lb) T2: 140 N.m (14.3 kgf-m, 103.3 ft-lb)
8. Take out the transmission jack.
9. Tighten the bolts and nuts which hold the lower side of transmission to the engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
10. Lower the vehicle.
11. Install the two mounting bolts on the upper side of the transmission. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
12. Remove the ST (ENGINE HANGER).
13. Install the transmission main mounting bracket. NOTE: Incline the engine, and install the transmission main mounting bracket for the left side of the vehicle first. Tightening torque: 75 N.m (7.6 kgf-m, 55.3 ft-lb)
14. Attach the ST (ENGINE HANGER) again.
15. Remove the bolts from ST (SPECIAL TOOL FB).
16. Remove the bolt and nut to remove ST (SPECIAL TOOL FB).
17. Temporarily attach the front cushion rubber with bolts.
18. Install the bolt and nut to the front cushion rubber.
19. Tighten the bolts and nuts of front cushion rubber. NOTE: Always start tightening from the bolts on the engine side. Tightening torque: T1: 25 N.m (2.5 kgf-m, 18.4 ft-lb) T2: 45 N.m (4.6 kgf-m, 33.2 ft-lb)
20. Remove the ST (ENGINE HANGER) from the vehicle.
21. Tighten the nuts connecting the engine mount and the transmission main mounting bracket. Tightening torque: 45 N.m (4.6 kgf-m, 33.2 ft-lb)
22. Install the starter. Refer to «INSTALLATION»(ref-646021-S35262374382014072500000) .
23. Install the operating cylinder. Tightening torque: 37 N.m (3.8 kgf-m, 27.3 ft-lb)
24. Lift up the vehicle.
25. Install the front drive shaft into the transmission. Refer to «INSTALLATION»(ref-645998-S27218978612014072500000) .
26. Insert the front arm ball joint into the housing lower part. Refer to «INSTALLATION»(ref-645996-S12286497322014072500000) .
27. Attach the stabilizer link to the front arm. Refer to «INSTALLATION»(ref-645996-S14720633512014072500000) .
28. Install the MT gear shift cable and MT gear select cable to MT gear shift lever. Refer to «INSTALLATION»(ref-646009-S07991222172014072500000) . CAUTION: Do not bend MT gear shift cable and MT gear select cable at a sharp angle. Always use new MT gear select cable if the cable is removed from selector lever COMPL of transmission side.
29. Install the propeller shaft. Refer to «INSTALLATION»(ref-645998-S27738106242014072500000) .
30. Install the steering shaft universal joint. Refer to «INSTALLATION»(ref-646000-S26694721972014072500000) .
31. Install the heat shield cover. Refer to «INSTALLATION»(ref-646002-S18321241742014072500000) .
32. Install the center exhaust pipe. Refer to «INSTALLATION»(ref-646019-S36092120302014072500000) and «INSTALLATION»(ref-646019-S38975430962014072500000) .
33. Install the front under cover. Refer to «INSTALLATION»(ref-646002-S01834874552014072500000) .
34. Lower the vehicle.
35. Install the throttle body. Refer to «INSTALLATION»(ref-646021-S35262374382014072500000) .
36. Connect the following connectors. Transmission radio ground terminal Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb) Neutral position switch connector (Brown) Back-up light switch connector (Gray) Engine harness connectors
37. Fill transmission gear oil through the transmission oil level gauge hole. Refer to «TRANSMISSION GEAR OIL»(ref-645990-S32949908802014072500000) .
38. Install the air intake boot assembly. Refer to «INSTALLATION»(ref-645985-S25796957322014072500000) .
39. Install the radiator fan.
40. Attach the grille bracket.
41. Install the air intake duct. Refer to «INSTALLATION»(ref-645985-S11096322132014072500000) .
42. Install the front wheels.
43. Adjust the detent of the MT gear shift lever. Refer to «ADJUSTMENT»(ref-646009-S13241104622014072500000) .
44. Connect the battery ground terminal.

Scheme 206

1. Disconnect the ground cable from battery.
2. Lift up the vehicle.
3. Remove the front under cover. Refer to «REMOVAL»(ref-646002-S00701002792014072500000) .
4. Remove the front and center exhaust pipes. Refer to «REMOVAL»(ref-646019-S20066601862014072500000) and «REMOVAL»(ref-646019-S19251222692014072500000) .
5. Remove the heat shield cover.
6. Set the transmission jack. CAUTION: Always support the transmission case with a transmission jack.
7. Remove the front crossmember and the rear crossmember.
8. Remove the transmission cushion rubber.
