Navigation — Stereo camera circuit Subaru Legacy BM/BR facelift
All systems — 34 systems
- Air conditioning 2.5l 2
- Air conditioning 3.6l 2
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines
- Cooling fan 2.5l
- Cooling fan 3.6l
- Cruise control
- Defoggers 3
- Engine performance 2.5l
- Engine performance 3.6l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems
- Navigation 5
- Power distribution
- Power door locks 2
- Power mirrors 5
- Power seats 2
- Power top/sunroof
- Power windows 2
- Radio 4
- Shift interlock 2
- Starting/charging 2.5l 5
- Starting/charging 3.6l 5
- Supplemental restraints
- Transmission 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 17
Click a component to highlight it on every diagram it appears on.
