PROCEDURE
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. Refer to CHECK LIST FOR INTERVIEW . Before performing diagnostics, check the following items which might affect CVT problems. General inspection Refer to INSPECTION . Disconnection of harness connector Visual check for harness damage Oil leakage Stall speed test Refer to STALL TEST . Secondary pressure test Refer to SECONDARY PRESSURE (LINE PRESSURE) TEST . Transfer clutch pressure test Refer to TRANSFER CLUTCH PRESSURE TEST . Time lag test Refer to TIME LAG TEST . Road test Refer to ROAD TEST . Inhibitor switch Refer to INHIBITOR SWITCH . | Is the item that is thought to influence the CVT problem working properly? | Go to step 2 . | Repair the items which may be affecting the CVT trouble. |
| 2 CHECK AT OIL TEMP LIGHT. Turn the ignition switch to ON and wait for at least 2 seconds. | Does the AT OIL TEMP light illuminate? | Go to step 3 . | Check the AT OIL TEMP light. |
| 3 CHECK AT OIL TEMP LIGHT. Start the engine and wait for 2 seconds or more. | Does the AT OIL TEMP light blink? | Go to step 4 . | Go to step 6 . |
| 4 CHECK FOR ANY OTHER DTC ON DISPLAY. Read the DTC. NOTE: If the communication function of Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE . | Is DTC displayed on Subaru Select Monitor? | Record all DTC. Go to step 5 . | Go to step 6 . |
| 5 CHECK FREEZE FRAME DATA. Using the Subaru Select Monitor, check the Freeze Frame Data. | Are freeze frame data recorded? | Record the freeze frame data. Go to step 7 . | Go to step 7 . |
| 6 PERFORM GENERAL DIAGNOSTICS. Inspect using "Diagnostic Procedure without Diagnostic Trouble Code (DTC)". Refer to DIAGNOSTIC PROCEDURE WITHOUT DIAGNOSTIC TROUBLE CODE (DTC) . Inspect using "Diagnostics with Phenomenon". Refer to DIAGNOSTICS WITH PHENOMENON . Perform the Inspection Mode. Refer to INSPECTION MODE . Read the DTC. | Is DTC displayed on Subaru Select Monitor? | Go to step 7 . | Finish the diagnosis. |
| 7 PERFORM DIAGNOSIS. Inspect by referring to "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". Refer to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . NOTE: For the DTC table, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . Repair the trouble cause. Perform the Clear Memory Mode. Perform the Inspection Mode. Refer to INSPECTION MODE . Read the DTC. | Is DTC displayed on Subaru Select Monitor? | Inspect by referring to "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". Refer to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE . |
| NOTE |
|---|
| For the DTC table, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
CHECK
Check the following items when a problem has occurred.
Note. Use copies of this page for interviewing customers.
Scheme 626
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
The airbag system wiring harness is routed near the TCM.
| CAUTION | All the airbag system wiring harnesses and connectors are colored yellow. Do not use an electric test equipment to check these circuits. Be careful not to damage the airbag system wiring harness when performing diagnostics or servicing the TCM. |
MEASUREMENT
When measuring the voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert a pin of more than 0.65 mm (0.026 in) diameter.
BATTERY
Measure the battery voltage and specific gravity of the electrolyte.
Standard voltage: 12 V or more
Specific gravity: 1.260 or more
TRANSMISSION GROUND
Make sure that the ground terminal bolt is tightened securely.
Tightening torque
14 N.m (1.4 kgf-m, 10.3 ft-lb)
Scheme 627
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
| Oscilloscope | Used for measuring the sensor. |
Scheme 628
Scheme 629
Scheme 630
Scheme 631
Scheme 632
Note. Measure after warming up.
| Item | Connector No. | Terminal No. | Measuring condition | Measurement value | Resistance between terminal and chassis ground | Remarks |
|---|---|---|---|---|---|---|
| Backup power supply | B55 | 1 | 10 - 13 V | |||
| Ignition power supply | B55 | 21 | 10 - 13 V | |||
| Main power supply | B55 | 11 | 10 - 13 V | |||
| Main power supply | B55 | 2 | 10 - 13 V | |||
| Main power supply | B55 | 22 | 10 - 13 V | |||
| Manual mode switch | B55 | 4 | Manual mode switch ON | Less than 1 V | ||
| Manual mode switch OFF | 8 V or more | |||||
| Manual mode UP switch | B55 | 5 | Manual mode UP switch ON | Less than 1 V | ||
| Manual mode UP switch OFF | 8 V or more | |||||
| Manual mode DOWN switch | B55 | 16 | Manual mode DOWN switch ON | Less than 1 V | ||
| Manual mode DOWN switch OFF | 8 V or more | |||||
| Stop light switch | B55 | 13 | Stop light switch ON | 8 V or more | ||
| Stop light switch OFF | Less than 1 V | |||||
| P range switch | B54 | 5 | P range | Less than 1 V | ||
| Except for P range | 8 V or more | |||||
| R range switch | B54 | 18 | R range | Less than 1 V | ||
| Except for R range | 8 V or more | |||||
| N range switch | B54 | 9 | N range | Less than 1 V | ||
| Except for N range | 8 V or more | |||||
| D range switch | B54 | 22 | D range | Less than 1 V | ||
| Except for D range | 8 V or more | |||||
| ATF temperature sensor | B54 | 3 | ATF temperature at 20°C (68°F) | Approx. 2.5 V | Approx. 2.5 kohms | |
| ATF temperature at 80°C (176°F) | Approx. 0.7 V | Approx. 330 ohms | ||||
| ATF temperature sensor GND | B54 | 16 | Always | Approx. 0 V | ||
| Secondary pressure sensor power supply output | B54 | 2 | Ignition switch ON | 5 V | ||
| Secondary pressure sensor | B54 | 17 | Ignition switch ON, engine OFF | Approx. 0.5 V (0 MPa) | Value increases with increase of engine load. (0.5 - 4.5 V) | |
| Ignition switch ON, engine ON | Approx. 1.0 V (1.0 MPa) | |||||
| Secondary pressure sensor GND | B54 | 15 | Always | Approx. 0 V | ||
| Primary speed sensor | B54 | 6 | While driving | 0 or 5 V | (Scheme 633)the waveform (sensor) | |
| Secondary speed sensor | B54 | 7 | While driving | 0 or 5 V | (Scheme 633)the waveform (sensor) | |
| Turbine speed sensor | B54 | 20 | Engine ON, "P" or "N" range | 0 or 5 V | (Scheme 633)the waveform (sensor) | |
| Self shut output | B55 | 20 | For three seconds after ignition switch ON and OFF | Less than 1 V | ||
| Ignition switch OFF | 8 V or more | |||||
| F&R solenoid | B54 | 11 | Engine ON | (Scheme 634)the waveform (solenoid (1)) | Approx. 4 - 6 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| Secondary solenoid | B54 | 12 | Engine ON | (Scheme 634)the waveform (solenoid (2)) | Approx. 5 - 7 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| Primary UP solenoid | B54 | 24 | Engine ON, while UP shifting | (Scheme 634)the waveform (solenoid (3)) | Approx. 10 - 13.5 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| Primary DOWN solenoid | B54 | 25 | Engine ON, while DOWN shifting | (Scheme 634)the waveform (solenoid (4)) | Approx. 10 - 13.5 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| Lock-up duty solenoid | B54 | 26 | Lock-up ON | (Scheme 634)the waveform (solenoid (5)) | Approx. 10 - 13.5 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| AWD solenoid | B54 | 13 | Engine ON, "P" or "N" range | (Scheme 634)the waveform (solenoid (6)) | Approx. 2 - 4.5 ohms | Resistance value at 20°C (68°F). Value is higher as the temperature increase. |
| Engine ON, "D" range, brake ON | (Scheme 634)the waveform (solenoid (7)) | |||||
| CAN communication line (+) | B55 | 18 | ||||
| CAN communication line (-) | B55 | 17 | ||||
| GND | B54 | 1 | Always | Approx. 0 V | ||
| GND | B54 | 14 | Always | Approx. 0 V |
Scheme 633
Scheme 634
HOW TO USE SUBARU SELECT MONITOR
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
READ CURRENT DATA
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
| Item | Display | Unit of measure |
|---|---|---|
| Engine speed signal | Engine Speed | Rpm |
| Battery voltage | ECU ACC | V |
| Accelerator position sensor | Accel. Opening Angle | % |
| Vehicle speed converted from secondary speed sensor signal | Front Wheel Speed | Km/h or MPH |
| Lock-up duty solenoid set duty ratio | Lock Up Duty Ratio | % |
| AWD solenoid set duty ratio | Transfer Duty Ratio | % |
| Turbine speed sensor signal | Turbine Revolution Speed | Rpm |
| ATF temperature sensor signal | ATF Temp. | °C or °F |
| Secondary speed sensor signal | Secondary Rev Speed | Rpm |
| Secondary fluid pressure sensor signal | Actual Secondary Pressure | MPa |
| Secondary solenoid indicator current | Secondary Set Current | MA |
| Secondary solenoid actual current | Secondary Actual Current | MA |
| Gear ratio | Actual Gear Ratio | |
| Shift step in manual mode | Shift Step in Manual Mode | |
| Primary UP solenoid set duty ratio | Primary UP Duty | % |
| Primary DOWN solenoid set duty ratio | Primary DOWN Duty | % |
| F&R solenoid indicator current | F&R Linear Solenoid Set Current | MA |
| F&R solenoid actual current | F&R Linear Solenoid Actual Current | MA |
| Primary speed sensor signal | Primary Rev Speed | Rpm |
| Manual mode switch signal | Tiptronic Mode Switch | ON or OFF |
| Manual mode down switch signal | Down Switch | ON or OFF |
| Stop light switch signal | Stop Light Switch | ON or OFF |
| Manual mode up switch signal | Up Switch | ON or OFF |
| Drive range signal | D Range Signal | ON or OFF |
| Reverse range signal | R Range Signal | ON or OFF |
| AT OIL TEMP light 2 Hz blink condition | Diagnosis Lamp | ON or OFF |
| AT OIL TEMP light ON condition | ATF Temperature Lamp | ON or OFF |
| Parking range signal | P Range | ON or OFF |
| Neutral range signal | N Range | ON or OFF |
| Secondary fluid pressure A/D converted value | Secondary pressure sensor voltage. | V |
| ATF temperature sensor voltage | ATF Temp sensor voltage. | V |
| AT learning mode condition | AT learning | Completed or Not Completed |
READ FREEZE FRAME DATA
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
| Item | Display | Unit of measure |
|---|---|---|
| Relative time since detection | Relative time since detection | Ms |
| Engine speed signal | Engine Speed | Rpm |
| Battery voltage | ECU ACC | V |
| Accelerator position sensor | Accel. Opening Angle | % |
| Vehicle speed converted from secondary speed sensor signal | Front Wheel Speed | Km/h or MPH |
| Lock-up duty solenoid set duty ratio | Lock Up Duty Ratio | % |
| AWD solenoid set duty ratio | Transfer Duty Ratio | % |
| Turbine speed sensor signal | Turbine Revolution Speed | Rpm |
| ATF temperature sensor signal | ATF Temp. | °C or °F |
| Secondary speed sensor signal | Secondary Rev Speed | Rpm |
| Secondary fluid pressure sensor signal | Actual Secondary Pressure | MPa |
| Secondary solenoid indicator current | Secondary Set Current | MA |
| Secondary solenoid actual current | Secondary Actual Current | MA |
| Gear ratio | Actual Gear Ratio | |
| Shift step in manual mode | Shift Step in Manual Mode | |
| Primary UP solenoid set duty ratio | Primary UP Duty | % |
| Primary DOWN solenoid set duty ratio | Primary DOWN Duty | % |
| F&R solenoid indicator current | F&R Linear Solenoid Set Current | MA |
| F&R solenoid actual current | F&R Linear Solenoid Actual Current | MA |
| Primary speed sensor signal | Primary Rev Speed | Rpm |
| Manual mode switch signal | Tiptronic Mode Switch | ON or OFF |
| Manual mode down switch signal | Down Switch | ON or OFF |
| Stop light switch signal | Stop Light Switch | ON or OFF |
| Manual mode up switch signal | Up Switch | ON or OFF |
| Drive range signal | D Range Signal | ON or OFF |
| Reverse range signal | R Range Signal | ON or OFF |
| AT OIL TEMP light 2 Hz blink condition | Diagnosis Lamp | ON or OFF |
| AT OIL TEMP light ON condition | ATF Temperature Lamp | ON or OFF |
| Parking range signal | P Range | ON or OFF |
| Neutral range signal | N Range | ON or OFF |
| Secondary fluid pressure A/D converted value | Secondary pressure sensor voltage. | V |
| ATF temperature sensor voltage | ATF Temp sensor voltage. | V |
Refer to ROAD TEST .
PREPARATION FOR LEARNING
- Warm up or cool down until the ATF temperature displayed on the Subaru Select Monitor is 40 - 65°C (104 - 149°F).
- After stopping the vehicle, shift the select lever to "P" range.
- Apply the electronic parking brake.
- Lift up the vehicle. CAUTION: While working, be sure to keep the lower edge of the tires 30 cm or more above the ground as vehicle will vibrate.
- Connect the Subaru Select Monitor to data link connector.
- Turn the ignition switch to ON.
- Turn off all switches causing an electrical load, such as headlights, A/C, seat heater and rear defogger, etc.
SIMPLE LEARNING
Note. Simple learning is performed with the vehicle lifted, without actually running the vehicle.
| CAUTION | Do not turn the power of the Subaru Select Monitor OFF during work, and do not disconnect the data link connector. |
- Select {Work Support} in the «Transmission Diagnosis» display screen of the Subaru Select Monitor.
- Select {Compulsory learning mode} in the «Work Support» display screen of the Subaru Select Monitor.
- Follow the messages displayed on the Subaru Select Monitor screen when working. NOTE: During AT learning in progress, AT OIL TEMP light in the combination meter starts flashing at 2 Hz and the learning operation starts. The following message is displayed on the screen when the AT OIL TEMP light which was flashing at 2 Hz turns off.
- When «AT learning normally ended.» is displayed, simple AT learning is completed. NOTE: If communication error occurs during learning, retry the "AT learning mode" from the beginning. If the message «Execute AT learning again after fixing troubles of the vehicle» appears during learning, select [OK] and display the DTC list. After repairing the locations indicated by the DTC, start the "AT learning mode" over from the beginning. When communication error occurs during learning, select lever does not shift occasionally. If select lever does not shift, turn the ignition switch to OFF before operating the select lever. If the message «AT learning ended abnormally.» is displayed, start the "AT learning mode" over from the beginning. Message Main causes for abnormal termination «AT learning ended abnormally.» Fault is detected during AT learning. The accelerator pedal is depressed during AT learning. An unspecified operation was performed during AT learning ATF temperature becomes out of specification during AT learning. Battery voltage is low. Malfunction indicator light illuminates. Electric parking brake not applied strongly enough Brake pedal is not fully depressed. Abnormal idle speed increase, etc. For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
LIST
| DTC | Item | Content of diagnosis | Reference |
|---|---|---|---|
| P0705 | Transmission Range Sensor Circuit (PRNDL Input) | Inhibitor switch malfunction or short circuit | Refer to DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT) . |
| P0708 | AT Range Switch Not Inputted | Inhibitor switch malfunction or open circuit | Refer to DTC P0708 AT RANGE SWITCH NOT INPUTTED . |
| P0712 | Transmission Fluid Temperature Sensor Circuit Low Input | ATF temperature sensor is faulty or input signal circuit is shorted. | Refer to DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUT . |
| P0713 | Transmission Fluid Temperature Sensor Circuit High Input | ATF temperature sensor is faulty or input signal circuit is open or shorted. | Refer to DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUT . |
| P0716 | Torque Converter Turbine Speed | Turbine speed sensor is faulty or input signal circuit is open or shorted. | Refer to DTC P0716 TORQUE CONVERTER TURBINE SPEED . |
| P0719 | Brake Switch Circuit Low | Brake switch is faulty or input signal circuit is open or shorted. | Refer to DTC P0719 BRAKE SWITCH CIRCUIT LOW . |
| P0724 | Brake Switch Circuit High | Brake switch is faulty or input signal circuit is shorted. | Refer to DTC P0724 BRAKE SWITCH CIRCUIT HIGH . |
| P0730 | Gearshift Control Performance Abnormal | Primary speed sensor, secondary speed sensor, control valve, or chain is faulty. | Refer to DTC P0730 GEARSHIFT CONTROL PERFORMANCE ABNORMAL . |
| P0801 | Reverse Inhibit Control Circuit | Shift lock solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT . |
| P0841 | Secondary Oil Pressure Sensor Performance | Secondary pressure sensor or control valve is faulty | Refer to DTC P0841 SECONDARY OIL PRESSURE SENSOR PERFORMANCE . |
| P0842 | Secondary Oil Pressure Sensor Circuit (Low) | Secondary pressure sensor is faulty or input signal circuit is open or shorted. | Refer to DTC P0842 SECONDARY OIL PRESSURE SENSOR CIRCUIT (LOW) . |
| P0843 | Secondary Oil Pressure Sensor Circuit (High) | Secondary pressure sensor is faulty or input signal circuit is shorted. | Refer to DTC P0843 SECONDARY OIL PRESSURE SENSOR CIRCUIT (HIGH) . |
| P0890 | AT Self-Shut Relay Diagnosis (Low) | Self-shut relay is faulty or input signal circuit is open or shorted. | Refer to DTC P0890 AT SELF-SHUT RELAY DIAGNOSIS (LOW) . |
| P0951 | Manual Switch | Manual mode switch is faulty or input signal circuit is open or shorted. | Refer to DTC P0951 MANUAL SWITCH . |
| P0962 | Secondary Solenoid Circuit (Low) | Secondary solenoid is faulty or output signal circuit is shorted. | Refer to DTC P0962 SECONDARY SOLENOID CIRCUIT (LOW) . |
| P0963 | Secondary Solenoid Circuit (High) | Secondary solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0963 SECONDARY SOLENOID CIRCUIT (HIGH) . |
| P0965 | Forward & Reverse Solenoid Function | F&R solenoid, forward clutch or control valve is faulty. | Refer to DTC P0965 FORWARD & REVERSE SOLENOID FUNCTION . |
| P0966 | Forward & Reverse Solenoid Circuit (Low) | F&R solenoid is faulty or output signal circuit is shorted. | Refer to DTC P0966 FORWARD & REVERSE SOLENOID CIRCUIT (LOW) . |
| P0967 | Forward & Reverse Linear Solenoid Circuit (High) | F&R solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0967 FORWARD & REVERSE LINEAR SOLENOID CIRCUIT (HIGH) . |
| P0970 | Transfer Solenoid Circuit (Low) | AWD solenoid is faulty or output signal circuit is shorted. | Refer to DTC P0970 TRANSFER SOLENOID CIRCUIT (LOW) . |
| P0971 | Transfer Solenoid Circuit (High) | AWD solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0971 TRANSFER SOLENOID CIRCUIT (HIGH) . |
| P0973 | Primary Solenoid System A Circuit (Low) | Primary UP solenoid is faulty or output signal circuit is shorted. | Refer to DTC P0973 PRIMARY SOLENOID SYSTEM A CIRCUIT (LOW) . |
| P0974 | Primary Solenoid System A Circuit (High) | Primary UP solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0974 PRIMARY SOLENOID SYSTEM A CIRCUIT (HIGH) . |
| P0976 | Primary Solenoid System B Circuit (Low) | Primary DOWN solenoid is faulty or output signal circuit is shorted. | Refer to DTC P0976 PRIMARY SOLENOID SYSTEM B CIRCUIT (LOW) . |
| P0977 | Primary Solenoid System B Circuit (High) | Primary DOWN solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P0977 PRIMARY SOLENOID SYSTEM B CIRCUIT (HIGH) . |
| P1724 | AT EEPROM Error | TCM EEPROM malfunction | Refer to DTC P1724 AT EEPROM ERROR . |
| P2746 | Primary Pulley Revolution Speed Sensor Circuit | Primary speed sensor is faulty or input signal circuit is open or shorted. | Refer to DTC P2746 PRIMARY PULLEY REVOLUTION SPEED SENSOR CIRCUIT . |
| P2750 | Sec. Pulley Revolution Speed Sensor Circuit | Secondary speed sensor is faulty or input signal circuit is open or shorted. | Refer to DTC P2750 SEC. PULLEY REVOLUTION SPEED SENSOR CIRCUIT . |
| P2762 | Lock-Up Duty Solenoid Malfunction | Lock-up duty solenoid, lock-up clutch or control valve is faulty | Refer to DTC P2762 LOCK-UP DUTY SOLENOID MALFUNCTION . |
| P2763 | Lock-Up Duty Solenoid Circuit (High) | Lock-up duty solenoid is faulty or output signal circuit is open or shorted. | Refer to DTC P2763 LOCK-UP DUTY SOLENOID CIRCUIT (HIGH) . |
| P2764 | Lock-Up Duty Solenoid Circuit (Low) | Lock-up duty solenoid is faulty or output signal circuit is shorted. | Refer to DTC P2764 LOCK-UP DUTY SOLENOID CIRCUIT (LOW) . |
| U0073 | Control Module Communication Bus "A" Off | CAN bus is shorted or communication error. | Refer to DTC U0073 CONTROL MODULE COMMUNICATION BUS "A" OFF . |
| U0100 | Lost Communication With ECM/PCM "A" | Detected that the engine data has not yet arrived. | Refer to DTC U0100 LOST COMMUNICATION WITH ECM/PCM "A" . |
| U0122 | Lost Communication With Vehicle Dynamics Control Module | Detected that the VDC data has not yet arrived. | Refer to DTC U0122 LOST COMMUNICATION WITH VEHICLE DYNAMICS CONTROL MODULE . |
| U0140 | Lost Communication With Body Control Module | Detected that the body integrated unit data has not yet arrived. | Refer to DTC U0140 LOST COMMUNICATION WITH BODY CONTROL MODULE . |
| U0155 | Lost Communication With Instrument Panel Cluster (IPC) Control Module | Detected that the meter data has not yet arrived. | Refer to DTC U0155 LOST COMMUNICATION WITH INSTRUMENT PANEL CLUSTER (IPC) CONTROL MODULE . |
| U0401 | Invalid Data Received From ECM/PCM "A" | Detected abnormality of the engine data. | Refer to DTC U0401 INVALID DATA RECEIVED FROM ECM/PCM "A" . |
| U0416 | Invalid Data Received From Vehicle Dynamics Control Module | Detected abnormality of the VDC data. | Refer to DTC U0416 INVALID DATA RECEIVED FROM VEHICLE DYNAMICS CONTROL MODULE . |
| U0422 | Invalid Data Received From Body Control Module | Detected abnormality of the body integrated unit data. | Refer to DTC U0422 INVALID DATA RECEIVED FROM BODY CONTROL MODULE . |
| U0423 | Invalid Data Received From Instrument Panel Cluster Control Module | Detected abnormality of the meter data. | Refer to DTC U0423 INVALID DATA RECEIVED FROM INSTRUMENT PANEL CLUSTER CONTROL MODULE . DTC Item Content of diagnosis Reference |
