GENERAL TOOL Subaru Legacy BM/BR рестайлинг

GENERAL TOOL

Scheme 171

Scheme 172

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock (A). While holding down the lock (A), disconnect the connector.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 173

1. How to disconnect: Push the lock lever plate (A). While holding down the lock lever plate (A), pull the lever toward you.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Insert the connector and push the lock lever in securely.

Scheme 174

Scheme 175

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the slide lock (A) in the direction of arrow. With the slide lock pushed, disconnect the connector.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 176

Scheme 177

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the slide lock (A) in the direction of arrow. With the slide lock pushed, disconnect the connector.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 178

Scheme 179

1. How to disconnect: Using a flat tip screwdriver, pry the push lock upward to unlock. Pull the connector to disconnect from the driver's airbag module assembly or the retractor assembly.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Be sure to push the push lock in securely. Then pull it gently to make sure that it is locked. Connect the connector in the reverse order of disconnecting. At this time, be sure to insert it until a clicking sound is heard.

Scheme 180

Scheme 181

Scheme 182

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock arm. Holding outer part, pull it one step in the direction of arrow. Push the lock arm again. Holding outer part, pull it in the direction of arrow to disconnect the connector.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 183

Scheme 184

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Holding outer part (A), pull it in the direction of arrow.
2. How to connect: CAUTION: Do not touch the outer side section or else the outer side (A) will move back. Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 185

Scheme 186

Scheme 187

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock arm. Holding outer part, pull it one step in the direction of arrow. Push the lock arm again. Holding outer part, pull it in the direction of arrow to disconnect the connector.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 188

Scheme 189

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A) in place, pull the connector (B) to the direction of arrow.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 190

Scheme 191

1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A), pull the connector (B) in the direction of arrow.
2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.
