LIST
| DTC | Item | Index |
|---|---|---|
| P0011 | Intake Camshaft Position - Timing Over-Advanced or System Performance (Bank 1) | Ref. to DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0014 | Exhaust AVCS System 1 (Range/Performance) | Ref. to DTC P0014 EXHAUST AVCS SYSTEM 1 (RANGE/PERFORMANCE) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0016 | Crankshaft Position - Camshaft Position Correlation (Bank 1) | Ref. to DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0017 | Crank and Cam Timing B System Failure (Bank 1) | Ref. to DTC P0017 CRANK AND CAM TIMING B SYSTEM FAILURE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0018 | Crankshaft Position - Camshaft Position Correlation (Bank 2) | Ref. to DTC P0018 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0019 | Crank and Cam Timing B System Failure (Bank 2) | Ref. to DTC P0019 CRANK AND CAM TIMING B SYSTEM FAILURE (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0021 | Intake Camshaft Position - Timing Over-Advanced or System Performance (Bank 2) | Ref. to DTC P0021 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0024 | Exhaust AVCS System 2 (Range/Performance) | Ref. to DTC P0024 EXHAUST AVCS SYSTEM 2 (RANGE/PERFORMANCE) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0030 | HO2S Heater Control Circuit (Bank 1 Sensor 1) | Ref. to DTC P0030 HO2S HEATER CONTROL CIRCUIT (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0031 | HO2S Heater Control Circuit Low (Bank 1 Sensor 1) | Ref. to DTC P0031 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0032 | HO2S Heater Control Circuit High (Bank 1 Sensor 1) | Ref. to DTC P0032 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0037 | HO2S Heater Control Circuit Low (Bank 1 Sensor 2) | Ref. to DTC P0037 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0038 | HO2S Heater Control Circuit High (Bank 1 Sensor 2) | Ref. to DTC P0038 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0068 | MAP/MAF - Throttle Position Correlation | Ref. to DTC P0068 MAP/MAF - THROTTLE POSITION CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0101 | Mass or Volume Air Flow Circuit Range/Performance | Ref. to DTC P0101 MASS OR VOLUME AIR FLOW CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0102 | Mass or Volume Air Flow Circuit Low Input | Ref. to DTC P0102 MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0103 | Mass or Volume Air Flow Circuit High Input | Ref. to DTC P0103 MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0107 | Manifold Absolute Pressure/Barometric Pressure Circuit Low Input | Ref. to DTC P0107 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0108 | Manifold Absolute Pressure/Barometric Pressure Circuit High Input | Ref. to DTC P0108 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0111 | Intake Air Temperature Sensor 1 Circuit Range/Performance | Ref. to DTC P0111 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0112 | Intake Air Temperature Sensor 1 Circuit Low | Ref. to DTC P0112 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0113 | Intake Air Temperature Sensor 1 Circuit High | Ref. to DTC P0113 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0117 | Engine Coolant Temperature Circuit Low | Ref. to DTC P0117 ENGINE COOLANT TEMPERATURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0118 | Engine Coolant Temperature Circuit High | Ref. to DTC P0118 ENGINE COOLANT TEMPERATURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0122 | Throttle/Pedal Position Sensor/Switch "A" Circuit Low | Ref. to DTC P0122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0123 | Throttle/Pedal Position Sensor/Switch "A" Circuit High | Ref. to DTC P0123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0125 | Insufficient Coolant Temperature for Closed Loop Fuel Control | Ref. to DTC P0125 INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0126 | Insufficient Engine Coolant Temperature for Stable Operation | Ref. to DTC P0126 INSUFFICIENT ENGINE COOLANT TEMPERATURE FOR STABLE OPERATION , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0128 | Coolant Thermostat (Engine Coolant Temperature Below Thermostat Regulating Temperature) | Ref. to DTC P0128 COOLANT THERMOSTAT (ENGINE COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0131 | O2 Sensor Circuit Low Voltage (Bank 1 Sensor 1) | Ref. to DTC P0131 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0132 | O2 Sensor Circuit High Voltage (Bank 1 Sensor 1) | Ref. to DTC P0132 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0133 | O2 Sensor Circuit Slow Response (Bank 1 Sensor 1) | Ref. to DTC P0133 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0134 | O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 1) | Ref. to DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0137 | O2 Sensor Circuit Low Voltage (Bank 1 Sensor 2) | Ref. to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0138 | O2 Sensor Circuit High Voltage (Bank 1 Sensor 2) | Ref. to DTC P0138 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0139 | O2 Sensor Circuit Slow Response (Bank 1 Sensor 2) | Ref. to DTC P0139 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0140 | O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 2) | Ref. to DTC P0140 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0141 | O2 Sensor Heater Circuit (Bank 1 Sensor 2) | Ref. to DTC P0141 O2 SENSOR HEATER CIRCUIT (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0171 | System Too Lean (Bank 1) | Ref. to DTC P0171 SYSTEM TOO LEAN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0172 | System Too Rich (Bank 1) | Ref. to DTC P0172 SYSTEM TOO RICH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0181 | Fuel Temperature Sensor "A" Circuit Range/Performance | Ref. to DTC P0181 FUEL TEMPERATURE SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0182 | Fuel Temperature Sensor "A" Circuit Low Input | Ref. to DTC P0182 FUEL TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0183 | Fuel Temperature Sensor "A" Circuit High Input | Ref. to DTC P0183 FUEL TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0222 | Throttle/Pedal Position Sensor/Switch "B" Circuit Low | Ref. to DTC P0222 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0223 | Throttle/Pedal Position Sensor/Switch "B" Circuit High | Ref. to DTC P0223 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0230 | Fuel Pump Primary Circuit | Ref. to DTC P0230 FUEL PUMP PRIMARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0244 | Turbo/Super Charger Wastegate Solenoid "A" Range/Performance | Ref. to DTC P0244 TURBO/SUPER CHARGER WASTEGATE SOLENOID "A" RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0245 | Turbo/Super Charger Wastegate Solenoid "A" Low | Ref. to DTC P0245 TURBO/SUPER CHARGER WASTEGATE SOLENOID "A" LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0246 | Turbo/Super Charger Wastegate Solenoid "A" High | Ref. to DTC P0246 TURBO/SUPER CHARGER WASTEGATE SOLENOID "A" HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0301 | Cylinder 1 Misfire Detected | Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0302 | Cylinder 2 Misfire Detected | Ref. to DTC P0302 CYLINDER 2 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0303 | Cylinder 3 Misfire Detected | Ref. to DTC P0303 CYLINDER 3 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0304 | Cylinder 4 Misfire Detected | Ref. to DTC P0304 CYLINDER 4 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0327 | Knock Sensor 1 Circuit Low (Bank 1 or Single Sensor) | Ref. to DTC P0327 KNOCK SENSOR 1 CIRCUIT LOW (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0328 | Knock Sensor 1 Circuit High (Bank 1 or Single Sensor) | Ref. to DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0335 | Crankshaft Position Sensor "A" Circuit | Ref. to DTC P0335 CRANKSHAFT POSITION SENSOR "A" CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0336 | Crankshaft Position Sensor "A" Circuit Range/Performance | Ref. to DTC P0336 CRANKSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0340 | Camshaft Position Sensor "A" Circuit (Bank 1 or Single Sensor) | Ref. to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0345 | Camshaft Position Sensor "A" Circuit (Bank 2) | Ref. to DTC P0345 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0365 | Camshaft Position Sensor "B" Circuit (Bank 1) | Ref. to DTC P0365 CAMSHAFT POSITION SENSOR "B" CIRCUIT (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0390 | Camshaft Position Sensor "B" Circuit (Bank 2) | Ref. to DTC P0390 CAMSHAFT POSITION SENSOR "B" CIRCUIT (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0420 | Catalyst System Efficiency Below Threshold (Bank 1) | Ref. to DTC P0420 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0442 | Evaporative Emission Control System Leak Detected (Small Leak) | Ref. to DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0447 | Evaporative Emission Control System Vent Control Circuit Open | Ref. to DTC P0447 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT OPEN , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0448 | Evaporative Emission Control System Vent Control Circuit Shorted | Ref. to DTC P0448 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT SHORTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0451 | Evaporative Emission Control System Pressure Sensor | Ref. to DTC P0451 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0452 | Evaporative Emission Control System Pressure Sensor Low Input | Ref. to DTC P0452 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0453 | Evaporative Emission Control System Pressure Sensor High Input | Ref. to DTC P0453 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0456 | Evaporative Emission Control System Leak Detected (Very Small Leak) | Ref. to DTC P0456 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (VERY SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0457 | Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off) | Ref. to DTC P0457 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (FUEL CAP LOOSE/OFF) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0458 | Evaporative Emission System Purge Control Valve Circuit Low | Ref. to DTC P0458 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0459 | Evaporative Emission System Purge Control Valve Circuit High | Ref. to DTC P0459 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0461 | Fuel Level Sensor "A" Circuit Range/Performance | Ref. to DTC P0461 FUEL LEVEL SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0462 | Fuel Level Sensor "A" Circuit Low | Ref. to DTC P0462 FUEL LEVEL SENSOR "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0463 | Fuel Level Sensor "A" Circuit High | Ref. to DTC P0463 FUEL LEVEL SENSOR "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0464 | Fuel Level Sensor Circuit Intermittent | Ref. to DTC P0464 FUEL LEVEL SENSOR CIRCUIT INTERMITTENT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0500 | Vehicle Speed Sensor "A" | Ref. to DTC P0500 VEHICLE SPEED SENSOR "A" , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0506 | Idle Air Control System RPM Lower Than Expected | Ref. to DTC P0506 IDLE AIR CONTROL SYSTEM RPM LOWER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0507 | Idle Air Control System RPM Higher Than Expected | Ref. to DTC P0507 IDLE AIR CONTROL SYSTEM RPM HIGHER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0512 | Starter Request Circuit | Ref. to DTC P0512 STARTER REQUEST CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0513 | Incorrect Immobilizer Key | Ref. to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0604 | Internal Control Module Random Access Memory (RAM) Error | Ref. to DTC P0604 INTERNAL CONTROL MODULE RANDOM ACCESS MEMORY (RAM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0605 | Internal Control Module Read Only Memory (ROM) Error | Ref. to DTC P0605 INTERNAL CONTROL MODULE READ ONLY MEMORY (ROM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0607 | Throttle Control System Circuit Range/Performance | Ref. to DTC P0607 THROTTLE CONTROL SYSTEM CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0638 | Throttle Actuator Control Range/Performance(Bank 1) | Ref. to DTC P0638 THROTTLE ACTUATOR CONTROL RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0851 | Neutral Switch Input Circuit Low (MT Model) | Ref. to DTC P0851 NEUTRAL SWITCH INPUT CIRCUIT LOW (MT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P0852 | Neutral Switch Input Circuit High (MT Model) | Ref. to DTC P0852 NEUTRAL SWITCH INPUT CIRCUIT HIGH (MT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1152 | O2 Sensor Circuit Range/Performance (Low) (Bank 1 Sensor 1) | Ref. to DTC P1152 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (LOW) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1153 | O2 Sensor Circuit Range/Performance (High) (Bank 1 Sensor 1) | Ref. to DTC P1153 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (HIGH) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1160 | Return Spring Failure | Ref. to DTC P1160 RETURN SPRING FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1400 | Fuel Tank Pressure Control Solenoid Valve Circuit Low | Ref. to DTC P1400 FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1420 | Fuel Tank Pressure Control Sol. Valve Circuit High | Ref. to DTC P1420 FUEL TANK PRESSURE CONTROL SOL. VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1443 | Vent Control Solenoid Valve Function Problem | Ref. to DTC P1443 VENT CONTROL SOLENOID VALVE FUNCTION PROBLEM , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1518 | Starter Switch Circuit Low Input | Ref. to DTC P1518 STARTER SWITCH CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1560 | Back-Up Voltage Circuit Malfunction | Ref. to DTC P1560 BACK-UP VOLTAGE CIRCUIT MALFUNCTION , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1570 | Antenna | Ref. to DTC P1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1571 | Reference Code Incompatibility | Ref. to DTC P1571 REFERENCE CODE INCOMPATIBILITY , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1572 | IMM Circuit Failure | Ref. to DTC P1572 IMM CIRCUIT FAILURE (EXCEPT ANTENNA CIRCUIT) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1574 | Key Communication Failure | Ref. to DTC P1574 KEY COMMUNICATION FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1576 | EGI Control Module EEPROM | Ref. to DTC P1576 EGI CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1577 | IMM Control Module EEPROM | Ref. to DTC P1577 IMM CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1578 | Meter Failure | Ref. to DTC P1578 METER FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P1602 | Control Module Programming Error | Ref. to DTC P1602 CONTROL MODULE PROGRAMMING ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2004 | Intake Manifold Runner Control Stuck Open (Bank 1) | Ref. to DTC P2004 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2005 | Intake Manifold Runner Control Stuck Open (Bank 2) | Ref. to DTC P2005 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2006 | Intake Manifold Runner Control Stuck Closed (Bank 1) | Ref. to DTC P2006 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2007 | Intake Manifold Runner Control Stuck Closed (Bank 2) | Ref. to DTC P2007 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2008 | Intake Manifold Runner Control Circuit/Open (Bank 1) | Ref. to DTC P2008 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT/OPEN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2009 | Intake Manifold Runner Control Circuit Low (Bank 1) | Ref. to DTC P2009 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2011 | Intake Manifold Runner Control Circuit/Open (Bank 2) | Ref. to DTC P2011 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT/OPEN (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2012 | Intake Manifold Runner Control Circuit Low (Bank 2) | Ref. to DTC P2012 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2016 | Intake Manifold Runner Position Sensor/Switch Circuit Low (Bank 1) | Ref. to DTC P2016 INTAKE MANIFOLD RUNNER POSITION SENSOR/SWITCH CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2017 | Intake Manifold Runner Position Sensor/Switch Circuit High (Bank 1) | Ref. to DTC P2017 INTAKE MANIFOLD RUNNER POSITION SENSOR/SWITCH CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2021 | Intake Manifold Runner Position Sensor/Switch Circuit Low (Bank 2) | Ref. to DTC P2021 INTAKE MANIFOLD RUNNER POSITION SENSOR/SWITCH CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2022 | Intake Manifold Runner Position Sensor/Switch Circuit High (Bank 2) | Ref. to DTC P2022 INTAKE MANIFOLD RUNNER POSITION SENSOR/SWITCH CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2088 | Intake Camshaft Position Actuator Control Circuit Low (Bank 1) | Ref. to DTC P2088 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2089 | Intake Camshaft Position Actuator Control Circuit High (Bank 1) | Ref. to DTC P2089 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2090 | Exhaust Camshaft Position Actuator Control Circuit Low (Bank 1) | Ref. to DTC P2090 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2091 | Exhaust Camshaft Position Actuator Control Circuit High (Bank 1) | Ref. to DTC P2091 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2092 | Intake Camshaft Position Actuator Control Circuit Low (Bank 2) | Ref. to DTC P2092 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2093 | Intake Camshaft Position Actuator Control Circuit High (Bank 2) | Ref. to DTC P2093 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2094 | Exhaust Camshaft Position Actuator Control Circuit Low (Bank 2) | Ref. to DTC P2094 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2095 | Exhaust Camshaft Position Actuator Control Circuit High (Bank 2) | Ref. to DTC P2095 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2096 | Post Catalyst Fuel Trim System Too Lean (Bank 1) | Ref. to DTC P2096 POST CATALYST FUEL TRIM SYSTEM TOO LEAN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2097 | Post Catalyst Fuel Trim System Too Rich (Bank 1) | Ref. to DTC P2097 POST CATALYST FUEL TRIM SYSTEM TOO RICH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2101 | Throttle Actuator Control Motor Circuit Range/Performance | Ref. to DTC P2101 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2102 | Throttle Actuator Control Motor Circuit Low | Ref. to DTC P2102 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2103 | Throttle Actuator Control Motor Circuit High | Ref. to DTC P2103 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2109 | Throttle/Pedal Position Sensor "A" Minimum Stop Performance | Ref. to DTC P2109 THROTTLE/PEDAL POSITION SENSOR "A" MINIMUM STOP PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2122 | Throttle/Pedal Position Sensor/Switch "D" Circuit Low Input | Ref. to DTC P2122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2123 | Throttle/Pedal Position Sensor/Switch "D" Circuit High Input | Ref. to DTC P2123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2127 | Throttle/Pedal Position Sensor/Switch "E" Circuit Low Input | Ref. to DTC P2127 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2128 | Throttle/Pedal Position Sensor/Switch "E" Circuit High Input | Ref. to DTC P2128 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2135 | Throttle/Pedal Position Sensor/Switch "A"/"B" Voltage Correlation | Ref. to DTC P2135 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A"/"B" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2138 | Throttle/Pedal Position Sensor/Switch "D"/"E" Voltage Correlation | Ref. to DTC P2138 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D"/"E" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2227 | Atmospheric Pressure Sensor Range/Performance | Ref. to DTC P2227 BAROMETRIC PRESSURE CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2228 | Barometric Pressure Circuit Low | Ref. to DTC P2228 BAROMETRIC PRESSURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2229 | Barometric Pressure Circuit High | Ref. to DTC P2229 BAROMETRIC PRESSURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2419 | Evaporative Emission System Switching Valve Control Circuit Low | Ref. to DTC P2419 EVAPORATIVE EMISSION SYSTEM SWITCHING VALVE CONTROL CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| P2420 | Evaporative Emission System Switching Valve Control Circuit High | Ref. to DTC P2420 EVAPORATIVE EMISSION SYSTEM SWITCHING VALVE CONTROL CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0073 | CAN Failure, Bus 'OFF' Detection | Ref. to DTC U0073 CAN FAILURE , BUS 'OFF' DETECTION, Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0101 | CAN (TCU) Data not Loaded | Ref. to DTC U0101 CAN (TCU) DATA NOT LOADED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0122 | CAN (VDC) Data not Loaded | Ref. to DTC U0122 CAN (VDC) DATA NOT LOADED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0140 | CAN (BCU) Data not Loaded | Ref. to DTC U0140 CAN (BCU) DATA NOT LOADED , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0402 | CAN (TCU) Data Abnormal | Ref. to DTC U0402 CAN (TCU) DATA ABNORMAL , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0416 | CAN (VDC) Data Abnormal | Ref. to DTC U0416 CAN (VDC) DATA ABNORMAL , Diagnostic Trouble Code (DTC) Detecting Criteria. |
| U0422 | CAN (BCU) Data Abnormal | Ref. to DTC U0422 CAN (BCU) DATA ABNORMAL , Diagnostic Trouble Code (DTC) Detecting Criteria. |
DIAGNOSTIC TROUBLE CODE CHART
ENABLE CONDITION
| Secondary Parameters | Enable Conditions |
|---|---|
| Time of establishing all secondary parameter conditions | > or = 3000 ms |
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 1500 RPM |
| Engine coolant temperature | > or = 20 °C (68 °F) |
| AVCS control | Operation |
| Target timing advance change amount (per 64 ms) | < 1.07°CA |
ENABLE CONDITION
GENERAL DRIVING CYCLE
Perform the diagnosis continuously after warming up when the engine speed increases and AVCS operates.
ENABLE CONDITIONS
| Secondary Parameters | Enable Conditions |
|---|---|
| Time of establishing all secondary parameter conditions | > or = 3000 ms |
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 1500 RPM |
| Engine coolant temperature | > or = 20 °C (68 °F) |
| Exhaust AVCS control | Operation |
| Target timing advance change amount (per 64 ms) | < 1.07°CA |
ENABLE CONDITIONS
Perform the diagnosis continuously after warming up when the engine speed increases and exhaust AVCS operates.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 600 RPM |
| And | |
| < 975 RPM | |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| AVCS control | Not in operation |
| Target timing advance | 0°CA |
ENABLE CONDITION
Perform the diagnosis continuously after starting engine and while AVCS is not operating.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 600 RPM |
| And | |
| < 975 RPM | |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Exhaust AVCS control | Not in operation |
| Target timing advance | 0°CA |
ENABLE CONDITIONS
Perform the diagnosis continuously while the exhaust AVCS is not operating after warming up.
| Secondary Parameters | Enable Conditions |
|---|---|
| Condition established time | > or = 42000 ms |
| Battery voltage | > or = 10.9 V |
| Heater current | Permitted |
| Control duty > or = 35 % | Experienced |
| After fuel cut | > or = 20000 ms |
ENABLE CONDITION
Perform the diagnosis continuously after 42000 ms seconds or more have passed since the engine started.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Engine speed | < 8000 RPM |
ENABLE CONDITION
After starting the engine, perform the diagnosis continuously when engine is low speed.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Engine speed | < 8000 RPM |
ENABLE CONDITION
After starting the engine, perform the diagnosis continuously when engine is low speed.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine coolant temperature | > or = 72°C (161.6°F) |
ENABLE CONDITION
Perform the diagnosis continuously after idling.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine coolant temperature | > or = 72°C (161.6°F) |
ENABLE CONDITION
Perform the diagnosis continuously after idling.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine coolant temperature at engine starting | < 35 °C (95 °F) |
| Battery voltage | > or = 10.9 V |
| Continuous time when the vehicle speed is less than 140 km/h (87 MPH) | > or = 610 s |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Intake air amount sum value | > or = Value of Map 1 |
| Number of experiences under conditions below | > or = 3 time(s) |
| Continuous time when vehicle speed is less than 4 km/h (2.5 MPH) | > or = Value from Map 2 |
| Continuous time when vehicle speed is 40 km/h (24.9 MPH) or more | > or = 15 s |
| And | |
| Establishing time of 1, 2 | > or = 15 s |
| 1. Intake air amount | > or = 15 g/s (0.53 oz/s) |
| 2. Vehicle speed | > or = 4 km/h (2.5 MPH) |
ENABLE CONDITION
Map 1
| Engine coolant temperature °C (°F) | 20 (-4) | 10 (14) | 0 (32) | 10 (50) | 20 (68) |
|---|---|---|---|---|---|
| Intake air amount sum value (g (oz)/s) | 76000 (2680.52) | 8880 (313.2) | 8153 (287.56) | 7427 (261.95) | 6009 (211.94) |
ENGINE COOLANT TEMPERATURE CHART
Map 2
| Engine coolant temperature °C (°F) | 20 (-4) | 10 (14) | 5 (41) | 20 (68) |
|---|---|---|---|---|
| Continuous time (s) when vehicle speed is less than 4 km/h (2.5 MPH) | 250 | 40 | 32 | 24 |
ENGINE COOLANT TEMPERATURE CHART
Perform the diagnosis when the vehicle speed condition is met after warming up from a cold condition.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine speed | > or = Value from Map |
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Map
| Engine coolant temperature °C (°F) | 40 (-40) | 30 (-22) | 20 (-4) | 10 (14) | 0 (32) | 10 (50) | 20 (68) | 30 (86) |
|---|---|---|---|---|---|---|---|---|
| Engine speed RPM | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
ENGINE COOLANT TEMPERATURE CHART
| Engine coolant temperature °C (°F) | 40 (104) | 50 (122) | 60 (140) | 70 (158) | 80 (176) | 90 (194) | 100 (212) | 110 (230) |
|---|---|---|---|---|---|---|---|---|
| Engine speed RPM | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
ENGINE COOLANT TEMPERATURE CHART
Perform the diagnosis only once after engine start.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Refueling from the last engine stop till the current engine start | None |
| Fuel level | > or = 15 l (3.96 US gal, 3.3 lmp gal) |
| Engine coolant temperature at the last engine stop | > or = 72°C (161.6°F) |
ENABLE CONDITION
Perform the diagnosis only once after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 1024 ms |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > 75 kPa (563 mmHg, 22.2 inHg) |
| Closed loop control with main feedback | Operation |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Elapsed time after starting the engine | > or = 120000 ms |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Engine speed | 1000 RPM - 3200 RPM |
| Vehicle speed | 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) |
| Amount of intake air | 10 g/s - 31 g/s (0.35 oz/s - 1.09 oz/s) |
| Engine load | < 0.02 g/rev (0 oz/rev) |
| Learning value of EVAP cone, during purge | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
ENABLE CONDITION
Perform diagnosis only once at a constant speed of 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) 120000 ms or more after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
Used for abnormality judgment
| Secondary Parameters | Enable Conditions |
|---|---|
| High | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Low (1) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Amount of intake air | > or = 10g/s (0.35 oz/s) |
| Low (2) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Amount of intake air | < 10 g/s (0.35 oz/s) |
| Current continuation time of the rear oxygen sensor heater | > or = 25000 ms |
| Low (3) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Amount of intake air | < 10 g/s (0.35 oz/s) |
| Current continuation time of the rear oxygen sensor heater | > or = 25000 ms |
| Fuel cut | Experienced |
ENABLE CONDITION
Used for normality judgment
| Secondary Parameters | Enable Conditions |
|---|---|
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 72°C (161.6°F) |
ENABLE CONDITIONS
After starting the engine, continuously perform the diagnosis with the same engine condition.
Rich --> lean diagnosis response
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| A/F main feedback control condition | Complete |
| Deceleration fuel cut time of 5000 ms or more (intermediate) | Experienced |
| Deceleration fuel cut time of 5000 ms or more (wide) | |
| After fuel cut | > or = 2000 ms (Intermediate) |
| > or = 2000 ms (Wide) | |
| Estimated temperature of the rear oxygen sensor element | > or = 450 °C (842 °F) (Intermediate) > or = 450 °C (842 °F) (Wide) |
| Number of deceleration fuel cut | > or = 1 time(s) |
ENABLE CONDITION
Perform diagnosis once during deceleration fuel cut from a constant and high speed driving, when rear oxygen sensor is warmed up sufficiently. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)
Lean --> rich response diagnosis
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| A/F main feedback control condition | Complete |
| Deceleration fuel cut time is 6000 ms or more. | Experienced |
| After fuel cut | > or = 2000 ms |
| Number of deceleration fuel cut | > or = 1 time(s) |
ENABLE CONDITION
Perform diagnosis once during deceleration fuel cut from a constant and high speed driving, when rear oxygen sensor is warmed up sufficiently. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)
ENABLE CONDITION (USED ONLY FOR MALFUNCTION JUDGMENT)
| Secondary Parameters | Enable Conditions |
|---|---|
| Closed loop control at the rear oxygen sensor | In operation |
| Target output voltage of rear oxygen sensor | > or = 0.55 V + 0.05 V |
| Amount of intake air | > or = 10 g/s (0.35 oz/s) |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Misfire detection every 200 rotations | < 5 time(s) |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Deceleration fuel cut of 5000 ms or more. | Experienced |
ENABLE CONDITION
Perform the diagnosis once after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1000 ms |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| A/F sensor element impedance | < or = 50 ohms |
| A/F sensor heater control duty | < or = 75 % |
| Rear oxygen sensor heater control duty | < 70 % |
ENABLE CONDITION
Perform the diagnosis continuously after 1000 ms seconds or more have passed since the engine started.
| Secondary Parameters | Enable Conditions |
|---|---|
| A/F main learning system | In operation |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Engine load change | < 0.02 g/rev (0 oz/rev) |
| Engine load | > or = Value of Map 1 |
ENABLE CONDITION
Map 1
| Engine speed (RPM) | Idling | 700 | 1200 | 1600 | 2000 | 2400 | 2800 | 3200 | 3600 | 4000 | 4400 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Measured value (g (oz)/rev) | Na | 0.230 (0.01) | 0.217 (0.01) | 0.213 (0.01) | 0.210 (0.01) | 0.210 (0.01) | 0.220 (0.01) | 0.223 (0.01) | 0.240 (0.01) | 0.252 (0.01) | 0.261 (0.01) |
TEMPERATURE CHART
Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| A/F main learning system | In operation |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Engine load change | < or = 0.02 g/rev (0 oz/rev) |
| Learning value of EVAP cone. | < 0.1 |
| Cumulative time of canister purge after engine start | > or = 20 s |
| Continuous period after canister purge starting | > or = 29884 ms |
| Engine load | > or = Value of Map 1 |
ENABLE CONDITION
Map 1
| Engine speed (RPM) | Idling | 700 | 1200 | 1600 | 2000 | 2400 | 2800 | 3200 | 3600 | 4000 | 4400 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Measured value (g (oz)/rev) | Na | 0.230 (0.01) | 0.217 (0.01) | 0.213 (0.01) | 0.210 (0.01) | 0.210 (0.01) | 0.220 (0.01) | 0.223 (0.01) | 0.240 (0.01) | 0.252 (0.01) | 0.261 (0.01) |
ENGINE SPEED SPECIFICATION
Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.
Always perform the diagnosis continuously.
Perform the diagnosis continuously 20 seconds after starting engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| All secondary parameters enable conditions | > or = 1024 ms |
| 180°Intake manifold pressure change at CA | < Value of Map 1 |
| Throttle position variation for 16 ms | < 14° |
| Fuel shut-off function | Not in operation |
| Fuel level | > or = 10.5 l (2.77 US gal, 2.31 lmp gal) |
| Vehicle dynamic control or AT torque control | Not in operation |
| Evaporative system leak check | Not in operation |
| Engine speed | 550 RPM - 6700 RPM |
| Intake manifold pressure | > or = Value from Map 2 |
| Battery voltage | > or = 8 V |
| Fuel parameter determination | Not extremely low volatility |
| Elapsed time after starting the engine | > or = 0 ms |
| Engine speed variation for 32 ms | < 1000 RPM |
ENABLE CONDITION
Map 1
| RPM | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) |
ENGINE SPEED VARIATION CHART
Map 2
- Tumble generator valve open
Vehicle speed < 64 km/h (39.8 MPH)
| RPM | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 28.8 (216, 8.5) | 24.9 (187, 7.4) | 21.1 (158, 6.2) | 21.7 (163, 6.4) | 22.3 (167, 6.6) | 23.1 (173, 6.8) | 28.5 (214, 8.4) | 28.4 (213, 8.4) | 31.6 (237, 9.3) | 32.5 (244, 9.6) | 37.1 (278, 10.9) | 41.9 (314, 12.4) | 46.9 (352, 13.9) | 51.1 (383, 15.1) |
VEHICLE SPEED SPECIFICATION
Vehicle speed > or = 68 km/h (42.3 MPH)
| RPM | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 25.1 (188, 7.4) | 24.8 (186, 7.3) | 31.6 (237, 9.3) | 33.1 (248, 9.8) | 32.1 (241, 9.5) | 31.6 (237, 9.3) | 36.7 (275, 10.8) | 35.1 (263, 10.4) | 38.3 (287, 11.3) | 39.2 (294, 11.6) | 43.7 (328, 12.9) | 48.5 (364, 14.3) | 53.6 (402, 15.8) | 54.7 (410, 16.1) |
VEHICLE SPEED SPECIFICATION
- Tumble generator valve closed
Vehicle speed < 64 km/h (39.8 MPH)
| RPM | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 28.8 (216, 8.5) | 24.9 (187, 7.4) | 21.1 (158, 6.2) | 21.7 (163, 6.4) | 22.3 (167, 6.6) | 23.1 (173, 6.8) | 28.5 (214, 8.4) | 28.4 (213, 8.4) | 31.6 (237, 9.3) | 32.5 (244, 9.6) | 37.1 (278, 10.9) | 41.9 (314, 12.4) | 46.9 (352, 13.9) | 51.1 (383, 15.1) |
VEHICLE SPEED SPECIFICATION
Vehicle speed > or = 68 km/h (42.3 MPH)
| RPM | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 25.1 (188, 7.4) | 24.8 (186, 7.3) | 31.6 (237, 9.3) | 33.1 (248, 9.8) | 32.1 (241, 9.5) | 31.6 (237, 9.3) | 36.7 (275, 10.8) | 35.1 (263, 10.4) | 38.3 (287, 11.3) | 39.2 (294, 11.6) | 43.7 (328, 12.9) | 48.5 (364, 14.3) | 53.6 (402, 15.8) | 54.7 (410, 16.1) |
VEHICLE SPEED SPECIFICATION
- If conditions are met, it is possible to detect the misfires from idling to high engine speed. However, to avoid excessive load or harm to the engine, perform diagnosis at idle.
- Perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 8 V |
| Engine speed | < 3000 RPM |
ENABLE CONDITION
Perform the diagnosis continuously under 3000 RPM engine speed.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 8 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 8 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Estimated catalyst temperature | > or = 540 °C (1004 °F) |
| Misfire detection every 200 rotations | < 5 time(s) |
| Learning value of evaporation gas density | < 0.2 |
| Sub feedback | In operation |
| Evaporative system diagnosis | Not in operation |
| Time of difference (< 0.10) between actual lambda and target lambda | > or = 1000 ms |
| Vehicle speed | > 60 km/h (37.3 MPH) |
| Amount of intake air | > or = 6.5 g/s (0.23 oz/s) |
| And | |
| < 50 g/s (1.76 oz/s) | |
| Engine load change every 0.5 engine revs. | < 0.02 g/rev (0 oz/rev) |
| Rear oxygen output change from 660 mV or less to 660 mV or more | Experienced after fuel cut |
| Elapsed time after starting the engine | > or = 230 second |
| Purge execution calculated time | > or = 5 s |
ENABLE CONDITION
Perform the diagnosis only once at a constant speed of 60 km/h (37.3 MPH) or higher.
Pressure control solenoid valve
PCV controls the fuel tank pressure to be equal to the atmospheric air pressure. Normally, the solenoid is set to OFF. The valve opens and closes mechanically in accordance with the pressure difference between tank and atmospheric air, or tank and canister.
The valve is forcibly opened by setting the solenoid to ON at the time of diagnosis.
Scheme 281
Purpose of Mode Z
When performing the leakage diagnosis of EVAP system, the purge control solenoid valve must operate normally. Therefore, mode Z is used to diagnose the purge control solenoid valve stuck open condition. Note that if a purge control solenoid valve stuck open fault is detected, the EVAP system leakage diagnosis is cancelled.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Elapsed time after starting the engine | > or = 60 s |
| Fuel level | > or = 10.5 l (2.77 US gal, 2.31 lmp gal) |
| Fuel temperature | < 35 °C (95 °F) |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
ENABLE CONDITION
- Perform the diagnosis continuously after 60 s have passed since the engine started.
- Pay attention to the fuel level and temperature.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 5000 ms |
| Vehicle speed | > or = 2 km/h (1.2 MPH) |
| All conditions of EVAP canister purge | Complete |
| Learning value of evaporation gas concentration (left and right) | < 0.08 |
| Main feedback compensation coefficient (left and right) | > or = 0.9 |
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Perform the diagnosis when purging enable conditions are met without idling.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine speed | > or = 500 RPM |
| Elapsed time after starting the engine | > or = 1 second |
| Battery voltage | > or = 10.9 V |
| Idle switch | ON |
| Fuel level | > or = 10.5 l (2.77 US gal, 2.31 lmp gal) |
| And | |
| < 59.5 l (15.72 US gal, 13.09 lmp gal) | |
| Vehicle speed = 0 km/h (0 MPH) | > or = 10000 ms |
ENABLE CONDITION
- Always perform the diagnosis continuously at idle speed.
- Pay attention to the fuel level.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 2000 ms |
ENABLE CONDITION
Always perform diagnosis more than 2000 ms after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Fuel level | > or = 10.5 l (2.77 US gal, 2.31 lmp gal) |
| Elapsed time after starting the engine | > or = 10.49 s |
| Feedback of ISC | In operation |
| Lambda value (left and right) | > or = 0.9 |
| And | |
| < 1.1 | |
| After switching air conditioner to ON/OFF | > or = 5.1 s |
| After intake manifold pressure changes by 4 kPa (30 mmHg, 1.2 inHg) or more. | > 5.1 s |
| Elapsed time after switching neutral position switch to ON/OFF | > 5.1 s |
| Vehicle speed | 0 km/h (0 MPH) |
ENABLE CONDITION
Perform the diagnosis continuously at idling after warming up engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine coolant temperature | > or = 72°C (161.6°F) |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Fuel level | > or = 10.5 l (2.77 US gal, 2.31 lmp gal) |
| Elapsed time after starting the engine | > or = 10.49 s |
| Feedback of ISC | In operation |
| Lambda value (left and right) | > or = 0.9 |
| And | |
| < 1.1 | |
| After switching air conditioner to ON/OFF | > or = 5.1 s |
| After intake manifold pressure changes by 4 kPa (30 mmHg, 1.2 inHg) or more. | > 5.1 s |
| Elapsed time after switching neutral position switch to ON/OFF | > 5.1 s |
| Vehicle speed | 0 km/h (0 MPH) |
ENABLE CONDITION
Perform the diagnosis continuously at idling after warming up engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
When starting the engine.
Perform the diagnosis only after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Diagnosis with the initial routine.
Perform the diagnosis as soon as the ignition switch is turned to ON.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| (1) Battery voltage | > or = 6 V |
| (2) Ignition switch | ON |
| (2) Battery voltage | > or = 6 V |
| (3) Ignition switch | ON |
| (3) ETC control | Permitted |
| (4) Ignition switch | ON |
| (4) Battery voltage | > or = 6 V |
| (5) Starter switch | OFF |
| (5) Battery voltage | > 6 V |
| (6) Ignition switch | ON |
| (6) Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Normal operation of electronic throttle control | ON |
ENABLE CONDITION
Always perform the diagnosis continuously when the electronic throttle control is operating.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITION
Perform the diagnosis continuously in 2 seconds after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITION
Perform the diagnosis continuously in 2 seconds after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 4096 ms |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Rear oxygen sensor sub feedback | Execution |
| Rear oxygen sensor output voltage - Feedback target voltage | 0.2 V - 0.1 V |
| Or rear oxygen sensor sub feedback compensation coefficient | On Min. |
| Or rear oxygen sensor sub feedback compensation coefficient | On Max. |
| Elapsed time after starting the engine | > or = 60000 ms |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Vehicle speed | > or = 20 km/h (12.4 MPH) |
| Amount of intake air | > or = 6 g/s (0.21 oz/s) |
| 180° Load change at CA | < 0.02 g/rev (0 oz/rev) |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Learning value of evaporation gas density | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
| Targeted lambda value load compensation coefficient | 1 - 1 |
ENABLE CONDITION
Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.
| Secondary Parameters | Enable Conditions |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 4096 ms |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Rear oxygen sensor sub feedback | Execution |
| Rear oxygen sensor output voltage - Feedback target voltage | 0.2 V - 0.1 V |
| Or rear oxygen sensor sub feedback compensation coefficient | On Min. |
| Or rear oxygen sensor sub feedback compensation coefficient | On Max. |
| Elapsed time after starting the engine | > or = 60000 ms |
| Engine coolant temperature | > or = 72 °C (161.6 °F) |
| Vehicle speed | > or = 20 km/h (12.4 MPH) |
| Amount of intake air | > or = 6 g/s (0.21 oz/s) |
| 180° Load change at CA | < 0.02 g/rev (0 oz/rev) |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Learning value of evaporation gas density | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
| Targeted lambda value load compensation coefficient | 1 - 1 |
ENABLE CONDITION
Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 6 V |
| Throttle position sensor | Normal |
ENABLE CONDITION
- Ignition switch ON --> OFF
- Ignition switch OFF --> ON (Only after clearing memory)
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
| Secondary Parameters | Enable Conditions |
|---|---|
| Drain valve | Open |
| Battery voltage | > or = 10.9 V |
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Tank pressure when starter is OFF --> ON | 0.7 kPa (-5 mmHg, -0.2 inHg) |
| And | |
| 1.4 kPa (10.7 mmHg, 0.4 inHg) |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Atmospheric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Battery voltage | > or = 10.9 V |
| Cold start diagnosis | Incomplete |
| Vehicle speed | < 3 km/h (1.9 MPH) |
| Misfire in 200 engine revs. | < 5 |
| Elapsed time after starting the engine | = 14 s |
ENABLE CONDITION
Perform the diagnosis at cold start.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30 °C (-22 °F) |
| Ambient air temperature | > or = -30 °C (-22 °F) |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30 °C (-22 °F) |
| Ambient air temperature | > or = -30°C (-22°F) |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30 °C (-22 °F) |
| Ambient air temperature | > or = -30 °C (-22 °F) |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30 °C (-22 °F) |
| Ambient air temperature | > or = -30 °C (-22 °F) |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Conditions for carrying out the sub feedback learning | Complete |
| Continuous time when all conditions are established. | > or = 1 s |
ENABLE CONDITION
Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.
| Secondary Parameters | Enable Conditions |
|---|---|
| Conditions for carrying out the sub feedback learning | Complete |
| Continuous time when all conditions are established. | > or = 1 S |
ENABLE CONDITION
Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.
| Secondary Parameters | Enable Conditions |
|---|---|
| Under control of electronic throttle control | ON |
| CPU communication line sub --> main normal judgment | Normal |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 11 V |
| Electronic throttle control relay output | ON |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 6 V |
| Electronic throttle control relay output | OFF |
ENABLE CONDITION
- When ignition switch ON --> OFF
- Ignition switch OFF --> ON (Only after clearing memory)
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON --> OFF |
| Ignition switch (only after clear memory) | OFF --> ON |
ENABLE CONDITION
Perform the diagnosis at full closed point learning.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| Engine speed | < 300 RPM |
| Vehicle speed | < 1 km/h (0.6 MPH) |
ENABLE CONDITION
Perform the diagnosis once at ignition switch ON.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
