Engine Ignition System - Ignition (H6DO - 3.6L DOHC): Removal & Installation Subaru Legacy BM/BR

REMOVAL

Spark plug: Ref. to SPECIFICATION , General Description.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Lift up (A) in two positions at the rear. Moving (B) in two positions at the front toward the vehicle, lift them up.
2. Disconnect the ground cable from battery.
3. Remove the air cleaner case. Ref. to «REMOVAL»(ref-371896-S07012520272010091900000) , Air Cleaner Case.
4. Remove the bracket (A).
5. Disconnect the connector (B) from ignition coil.
6. Remove the ignition coil. NOTE: Turn the #5 ignition coil to remove it.
7. Remove the spark plug with a spark plug socket.

Scheme 27

Scheme 28

Scheme 29

1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Lift up (A) in two positions at the rear. Moving (B) in two positions at the front toward the vehicle, lift them up.
2. Remove the battery and battery carrier. Ref. to «REMOVAL»(ref-371915-S38323050542010091900000) , Battery.
3. Remove the bracket (A).
4. Disconnect the connector (B) from ignition coil.
5. Remove the ignition coil. NOTE: Turn the #6 ignition coil to remove it.
6. Remove the spark plug with a spark plug socket.

Direct ignition type has been adopted. Refer to "Spark Plug" for removal procedure. Ref. to REMOVAL , Spark Plug.

INSTALLATION

Install in the reverse order of removal.

Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)
