Wiring diagram: Headlights — Headlights circuit Subaru Legacy BL/BP facelift
All systems — 34 systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control 2.5l
- Cruise control 2.5l turbo
- Defoggers 3
- Engine performance 2.5l
- Engine performance 2.5l turbo
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems
- Navigation
- Power distribution
- Power door locks
- Power mirrors
- Power seats 2
- Power top/sunroof 2
- Power windows
- Radio
- Shift interlock
- Starting/charging 2
- Starting/charging 2.5l
- Starting/charging 2.5l turbo
- Supplemental restraints
- Transmission 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 30
Click a component to highlight it on every diagram it appears on.
