INSTALLATION
Install in the reverse order of removal.
Note. Fasten with a clip after inserting the lower tab of case.
Scheme 457
Install in the reverse order of removal.
Tightening torque
Bolt (A): 6.0 N.m (0.6 kgf-m, 4.4 ft-lb)
Nut (B): 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Note. Fasten with a clip after inserting the lower tab of case.
Install in the reverse order of removal.
Tightening torque
Clamp (A), (B)
3.0 N.m (0.3 kgf-m, 2.2 ft-lb)
Bolt (C)
6.5 N.m (0.66 kgf-m, 4.8 ft-lb)
Scheme 458
Install in the reverse order of removal.
REMOVAL
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to " AIR CLEANER CASE " for the removal procedure. < Ref. to REMOVAL , Air Cleaner Case. >
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to " AIR CLEANER CASE " for the installation procedure. < Ref. to INSTALLATION , Air Cleaner Case. >
