SPECIFICATION
| Model | 2.5 i | 2.5 i-LTD, OUTBACK 2.5 i,-LTD, OUTBACK 3.0 R,-LTD, -LLB | 2.5 GT, -LTD, OUTBACK 2.5 GT | ||
|---|---|---|---|---|---|
| Front disc brake | Size | With 15" Wheel | With 16" Wheel | With 17" Wheel | |
| Type | Disc (Floating type, ventilated) | ||||
| Effective disc diameter | Mm (in) | 228 (8.98) | 244 (4.61) | 261 (10.28) | |
| Disc thickness x Outer diameter | Mm (in) | 24 x 277 (0.94 x 10.91) | 24 x 294 (0.94 x 11.57) | 30 x 316 (1.18 x 12.44) | |
| Effective cylinder diameter | 42.8 (1.685) x 2 | ||||
| Pad dimensions (length x width x thickness) | Mm (in) | 117.8 x 50.5 x 11.0 (4.638 x 1.988 x 0.433) | 130.0 x 53.5 x 11.0 (5.118 x 2.106 x 0.433) | ||
| Clearance adjustment | Automatic adjustment | ||||
| Rear disc brake | Size | With 15" Wheel | |||
| Type | Disc (Floating type, solid) | Disc (Floating type, ventilated) | |||
| Effective disc diameter | Mm (in) | 238 (9.37) | 254 (10.0) | ||
| Disc thickness x Outer diameter | Mm (in) | 10 x 274 (0.39 x 10.79) | 18 x 290 (0.71 x 11.42) | ||
| Effective cylinder diameter | Mm (in) | 38.1 (1.500) | |||
| Pad dimensions (length x width x thickness | Mm (in)) | 92.0 x 33.0 x 9.0 (3.622 x 1.299 x 0.354) | 82.4 x 33.7 x 9.0 (3.244 x 1.327 x 0.354) | ||
| Clearance adjustment | Automatic adjustment | ||||
| Master cylinder | Type | Tandem | |||
| Effective diameter | Mm (in) | 23.8 (15/16) | |||
| Reservoir type | Sealed type | ||||
| Brake fluid reservoir capacity | Cm 3 (cu in) | 205 (12.51) | |||
| Brake booster | Type | Vacuum suspended | |||
| Effective diameter | Mm (in) | 208 + 229(8.19 + 9.02) | |||
| Brake line | Dual circuit system | ||||
| Brake fluid CAUTION: Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling brake fluid, be careful not to allow any dust into the reservoir. Use fresh brake fluid when replacing or refilling the fluid. | FMVSS No. 116, DOT3 | ||||
| CAUTION |
|---|
| Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling brake fluid, be careful not to allow any dust into the reservoir. Use fresh brake fluid when replacing or refilling the fluid. |
BRAKES GENERAL SPECIFICATIONS
Note. For parking brake specifications, < Ref. to SPECIFICATION , General Description. >
| Item | Standard value | Limit | ||||
|---|---|---|---|---|---|---|
| Front brake | Pad thickness | Mm (in) | Except With 17" Wheel | 11 (0.43) | 1.5 (0.059) | |
| With 17" Wheel | 11 (0.43) | 1.5 (0.059) | ||||
| Disc thickness | Mm (in) | Except With 17" Wheel | 24 (0.94) | 22 (0.87) | ||
| With 17" Wheel | 30 (1.18) | 28 (1.10) | ||||
| Disc runout | Mm (in) | 0.05 (0.0020) | ||||
| Rear brake (Disc type) | Pad thickness | Mm (in) | Solid disc | 9.0 (0.354) | 1.5 (0.059) | |
| Ventilated disc | 9.0 (0.354) | 1.5 (0.059) | ||||
| Disc thickness | Mm (in) | Solid disc | 10 (0.39) | 8.5 (0.335) | ||
| Ventilated disc | 18 (0.71) | 16 (0.63) | ||||
| Disc runout | Mm (in) | 0.05 (0.0020) | ||||
| Parking brake | Inside diameter | Mm (in) | 170 (6.69) | 171 (6.73) | ||
| Lining thickness | Mm (in) | 3.2 (0.126) | 1.5 (0.059) | |||
| Lever stroke | 5 - 6 notches/200 N (20 kgf, 45 lb) | |||||
BRAKES GENERAL SPECIFICATIONS
| Brake pedal force N (kgf, lb) | Fluid pressure kPa (kg/cm 2 , psi) | ||||
|---|---|---|---|---|---|
| With 15" Wheel | With 16" Wheel | With 17" Wheel | |||
| Brake Booster | Brake fluid pressure without engine running | 147 (15,33) | 545 (6, 79) | ||
| 294 (30, 66) | 1,564 (16,227) | ||||
| Brake fluid pressure with engine running and vacuuming at 66.7 kPa (500 mmHg, 19.69 inHg) | 147 (15,33) | 6,003 (61,871) | 5,381 (55, 780) | 4,963 (51,720) | |
| 294 (30, 66) | 11,273 (115, 1, 635) | 10,982 (112, 1, 593) | 10,055 (103, 1, 458) | ||
BRAKE BOOSTER GENERAL SPECIFICATIONS
| Brake pedal | Free play | Mm (in) | 0.5 - 2(0.02 - 0.08) [When pulling the brake pedal upward with a force of less than 10 N (1 kgf, 2 lb). |
BRAKE PEDAL GENERAL SPECIFICATIONS
