SPECIFICATION
| Lubrication method | Forced lubrication | |||
|---|---|---|---|---|
| Oil pump | Pump type | Trochoid type | ||
| Number of teeth | Inner rotor | 9 | ||
| Outer rotor | 10 | |||
| Outer rotor diameter x thickness | 78 x 10 mm (3.07 x 0.39 in) | |||
| Tip clearance between inner and outer rotors | Standard | 0.04 - 0.14 mm (0.0016 - 0.0055 in) | ||
| Side clearance between inner rotor and pump case | Standard | 0.02 - 0.07 mm (0.0008 - 0.0028 in) | ||
| Case clearance between outer rotor and pump case | Standard | 0.10 - 0.175 mm (0.0039 - 0.0069 in) | ||
| Performance (Oil temperature 80°C (176°F)) | 600 rpm | Discharge pressure | 98 kPa (1.0 kgf/cm 2 , 14 psi) | |
| Discharge rate | 4.6 l (4.9 US qt, 4.0 Imp qt)/min. | |||
| 5,000 rpm | Discharge pressure | 294 kPa (3.0 kgf/cm 2 , 43 psi) | ||
| Discharge rate | 47.0 l (49.7 US qt, 41.4 Imp qt)/min. | |||
| Relief valve working pressure | 588 kPa (6.0 kgf/cm 2 , 85 psi) | |||
| Oil filter | Filter type | Full-flow filter type | ||
| Filtration area | Outer diameter: 68 mm (2.68 in) | 800 cm 2 (124 sq in) | ||
| Outer diameter: 65 mm (2.56 in) | 470 cm 2 (73 sq in) | |||
| By-pass valve opening pressure | 160 kPa (1.63 kgf/cm 2 , 23.2 psi) | |||
| Outer diameter x width | Outer diameter: 68 mm (2.68 in) | 68 x 65 mm (2.68 x 2.56 in) | ||
| Outer diameter: 65 mm (2.56 in) | 65 x 74.4 mm (2.56 x 2.93 in) | |||
| Installation screw specifications | M 20 x 1.5 | |||
| Oil pressure switch | Type | Immersed contact point type | ||
| Operating voltage - number of watts | 12 V - 3.4 W or less | |||
| Warning light operating pressure | 14.7 kPa (0.15 kgf/cm 2 , 2.1 psi) | |||
| Proof pressure | 981 kPa (10 kgf/cm 2 , 142 psi) or more | |||
| Engine oil | Capacity (at overhaul) | 5.0 l (5.4 US qt, 4.5 Imp qt) | ||
| When replacing engine oil and oil filter | 4.2 l (4.4 US qt, 3.7 Imp qt) | |||
| When replacing engine oil only | 4.0 l (4.2 US qt, 3.5 Imp qt) | |||
SPECIFICATION CHART
Recommended oil
Those with an API standard SM "Energy Conserving" logo.
ILSAC standard GF-4 "starburst mark" displayed on container top.
Scheme 14
| CAUTION | It is acceptable to fill an engine with oil of another brand when replacing the oil, but make sure to use an oil with an API standard and SAE viscosity number specified by Subaru. |
Note. If the vehicle is used in regions with high temperatures or in other severe environments, use oil with the viscosities shown below. API standard: SM or SL
SAE Viscosity No.: 30, 40, 10W-50, 20W-40, 20W-50
