Differentials: Overhaul Subaru Legacy BL/BP рестайлинг

DISASSEMBLY

To detect the real cause of trouble, inspect the following items before disassembling.

1. Tooth contact and backlash of hypoid driven gear and drive pinion.
2. Hypoid driven gear runout on its back surface
3. Total preload of drive pinion

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Set the ST on vise and install the differential assembly to ST. ST 398217700 ATTACHMENT SET
2. Drain the gear oil by removing the plug.
3. Remove the air breather cap. NOTE: Do not attempt to replace the air breather cap unless necessary. Whenever the air breather cap is removed, replace it with a new part.
4. Remove the bolts, and then remove the rear cover. NOTE: Remove it by tapping with a plastic hammer.
5. Keep the side bearing retainers separate to make it possible to identify RH and LH sides. Remove the side bearing retainer attaching bolts, set the ST to differential case, and extract the side bearing retainers RH and LH with a puller. NOTE: Each shim, which is installed to adjusted the side bearing preload, should be kept together with its mating retainer. ST 398457700 ATTACHMENT
6. Pull out the differential case assembly from differential carrier. NOTE: Be careful so that the teeth do not hit against the case.
7. When replacing the side bearing, remove the bearing cup from the side bearing retainer using ST. ST 398527700 PULLER ASSY
8. Remove the bearing cone with ST. NOTE: Do not attempt to disassemble the parts unless necessary. Set the puller so that its claws catch the edge of the bearing cone. Store so that the right and left side bearing races and cones are not mixed together. ST 18759AA000 PULLER ASSY
9. Remove the hypoid driven gear by loosening hypoid driven gear bolts.
10. Drive out the pinion shaft lock pin from the hypoid driven gear side. (Model without LSD) NOTE: The lock pin is staked at the pin hole end on the differential carrier. Do not drive it out forcibly before removing the stake. ST 899904100 STRAIGHT PIN REMOVER
11. Draw out the pinion mate shaft and remove pinion mate gears, side gears and thrust washers. (Model without LSD) NOTE: The gears should be marked or kept separated right and left, and front and rear as well as thrust washers.
12. Remove the self-locking nut while holding the companion flange with ST. ST 498427200 FLANGE WRENCH
13. Extract the companion flange with a puller.
14. Press the end of drive pinion shaft and extract it together with rear bearing cone, pinion height adjusting washer and washer. NOTE: Hold the drive pinion so as not to drop it. ST 398467700 DRIFT
15. Remove the rear bearing cone from drive pinion by supporting the cone with ST. NOTE: Place the replacer so that its center-recessed side faces the pinion gear. ST 398517700 REPLACER
16. Remove the front oil seal from differential carrier using ST. ST 398527700 PULLER ASSY
17. Remove the pilot bearing together with the front bearing cone and collar using the ST. ST 398467700 DRIFT
18. When replacing the bearings, hit out the front bearing cup and rear bearing cup in this order using a brass bar.
