CAUTION
- Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
- Remove contamination including dirt and corrosion before removal, installation or disassembly.
- Keep the disassembled parts in order and protect them from dust and dirt.
- Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
- Use SUBARU genuine fluid, grease etc. or equivalent. Do not mix fluid, grease, etc. of different grades or manufacturers.
- Be sure to tighten fasteners including bolts and nuts to the specified torque.
- Place shop jacks or rigid racks at the specified points.
- Apply grease onto sliding or revolving surfaces before installation.
- Before installing O-rings or snap rings, apply sufficient amount of fluid to avoid damage and deformation.
- Before securing a part in a vise, place cushioning material such as wood blocks, aluminum plate or cloth between the part and the vise.
- Before disconnecting electrical connectors, be sure to disconnect the negative terminal from battery.
Scheme 184
Scheme 185
Scheme 186
| Item | To connector No. | Terminal No. | Input/Output signal |
|---|---|---|---|
| Measured value and measuring conditions | |||
| Backup power supply | B281 | 1 | 9-16V |
| 2 | |||
| I84 | 7 | ||
| Ignition power supply | B280 | 1 | 10 - 15V when ignition switch is at ON or START. |
| I84 | 24 | 10 - 15V when ignition switch is at ACC. | |
| TCM ("P" range) | B280 | 20 | Pulse signal |
| B280 | 30 | ||
| Stop light switch | B281 | 23 | 9 - 16V when stop light switch is ON. 0 V when stop light switch is OFF. |
| "P" range switch | B281 | 13 | 0 V when select lever is in "P" range. 9 - 16 V when select lever is in other positions than "P" range. |
| Shift lock solenoid signal | I84 | 6 | 8.5 - 16 V when shift lock is released. 0 V when shift lock is operating. |
| Key warning switch signal | B281 | 7 | 9 - 16 V when key is inserted. 0 V when key is removed. |
| Key lock solenoid signal | B280 | 5 | 7.5 - 16 V when ignition switch is turned ON, with select lever in "P" range and brake switch ON. 0 V at other conditions than above. |
| Ground | B280 | 22 | |
| I84 | 21 | ||
| B281 | 8 | ||
| 9 |
ELECTRICAL SPECIFICATION
