# Wiring diagram engine performance 2.5l, with low emissions

# Wiring diagram engine performance 2.5l, with low emissions (1 of 4)

Engine performance 2.5l — Wiring diagram engine performance 2.5l, with low emissions — Wiring diagram engine performance 2.5l, with low emissions (1 of 4). Subaru Legacy BL/BP (2003-2006)

Components on the diagram

# Wiring diagram engine performance 2.5l, with low emissions (2 of 4)

Engine performance 2.5l — Wiring diagram engine performance 2.5l, with low emissions — Wiring diagram engine performance 2.5l, with low emissions (2 of 4). Subaru Legacy BL/BP (2003-2006)

Components on the diagram

# Wiring diagram engine performance 2.5l, with low emissions (3 of 4)

Engine performance 2.5l — Wiring diagram engine performance 2.5l, with low emissions — Wiring diagram engine performance 2.5l, with low emissions (3 of 4). Subaru Legacy BL/BP (2003-2006)

Components on the diagram

# Wiring diagram engine performance 2.5l, with low emissions (4 of 4)

Engine performance 2.5l — Wiring diagram engine performance 2.5l, with low emissions — Wiring diagram engine performance 2.5l, with low emissions (4 of 4). Subaru Legacy BL/BP (2003-2006)

Components on the diagram
