STARTER SPECIFICATIONS
Note. For additional starter specifications (Scheme 1)
| Application | Specifications | |
|---|---|---|
| Brush Length | ||
| Standard | .59" (15 mm) | |
| Limit | .39" (10 mm) | |
| Brush Spring Force | ||
| Standard (New) | 4 Lbs (19 N) | |
| Limit | 2 Lbs (7 N) | |
| Commutator Run-Out | ||
| Standard | .0008" (.02 mm) or less | |
| Service Limit | Less than .0020" (.05 mm) | |
| Depth Of Segment Mold | ||
| Standard | .024" (.6 mm) | |
| Limit | .008" (.2 mm) | |
STARTER SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
For starter specification for 2002-03 models, see STARTING/CHARGING article in SPECIFICATIONS.
For starter specification for 2004 models, see STARTING article in SPECIFICATIONS.
