INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article for when you are familiar with an adjustment procedure and only need a specification.
BATTERY SPECIFICATIONS
| Application | Amp Hr. Rating |
|---|---|
| 1.2L | 52 |
BATTERY SPECIFICATIONS
FLUID CAPACITIES
| Application | Quantity | |
|---|---|---|
| Cooling System (Including Heater) | 4.5 qts. (4.3L) | |
| Crankcase (Includes Filter) | 3.0 qts. (2.8L) | |
| ECVT Transaxle (Dexron II) | 3.6 qts. (3.4L) | |
| Manual Transaxle (SAE 85W-90) | ||
| 2WD | 2.4 qts. (2.3L) | |
| 4WD | 3.5 qts. (3.3L) | |
| Power Steering | 1.5 pts. (.7L) | |
FLUID CAPACITIES
SERVICE INTERVALS & SPECIFICATIONS
| Component | Interval (Miles) |
|---|---|
| Air Filter | 30,000 |
| Camshaft Timing Belt | 60,000 |
| Coolant (Radiator) | 30,000 |
| ECVT Fluid | 30,000 |
| Fuel Filter | 30,000 |
| Oil & Filter | 7500 |
| Spark Plugs | 30,000 |
REPLACEMENT INTERVALS
BELT ADJUSTMENT SPECIFICATIONS
| Application | Deflection In. (mm) |
|---|---|
| Alternator Belt | .35-.39 (9-10) |
| Power Steering Belt | .35-.43 (9-11) |
| A/C Belt | .43-.47 (11-12) |
| A/C & P/S Equipped Models | .30-.33 (7.5-8.5) |
BELT ADJUSTMENT
ENGINE COMPRESSION
| Application | Specification |
|---|---|
| Compression Ratio | 9.1:1 |
| Compression Pressure | 135-156 psi (9.5-11.0 kg/cm 2 ) |
| Maximum Variation Between Cylinders | 28 psi (2.0 kg/cm 2 ) |
COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
| Application | (1) Clearance In. (mm) |
|---|---|
| Intake | .006 (.15) |
| Exhaust | .010 (.25) |
| (1) Adjust valves with engine cold. | |
| (1) | Adjust valves with engine cold. |
VALVE CLEARANCE SPECIFICATIONS
VALVE ARRANGEMENT
Note. Right and left sides refer to engine, as viewed from flywheel.
Right Side
All intake.
Left Side
All exhaust.
IGNITION COIL
| Application | Primary | Secondary |
|---|---|---|
| 1.2L | .81-.99 | 8500-11,000 |
IGNITION COIL RESISTANCE - OHMS @ 68°F (20°C)
DISTRIBUTOR SENSORS
Note. Information on distributor sensors is not available from manufacturer. See IGNITION CHECKS in appropriate BASIC TESTING article in the ENGINE PERFORMANCE Section for test procedures.
HIGH TENSION WIRE RESISTANCE
| Application | Ohms |
|---|---|
| No. 1 | 458-10,680 |
| No. 2 | 411-959 |
| No. 3 | 290-676 |
| Coil | 459-10,710 |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | NGK | Nippondenso |
|---|---|---|
| 1.2L | (1) BPR6ES-11 | (2) W20EPR-U11 |
| (1) Spark Plug No. BPR5ES-11 or BPR7ES-11 may also be used. (2) Spark Plug No. W16EPR-U11 or W22EPR-U11 may also be used. | ||
| (1) | Spark Plug No. BPR5ES-11 or BPR7ES-11 may also be used. |
| (2) | Spark Plug No. W16EPR-U11 or W22EPR-U11 may also be used. |
SPARK PLUG TYPE
| Application | Gap: In. (mm) | Torque: Ft. Lbs. (N.m) |
|---|---|---|
| All Engines | .039-.043 (1.0-1.1) | 15 (20) |
SPARK PLUG SPECIFICATIONS
IGNITION TIMING
| Application | Manual Transmission | Automatic Transmission |
|---|---|---|
| 1.2L | (1) 5 @ 800 | (1) 5 @ 850 |
| (1) With test mode connector connected. | ||
| (1) | With test mode connector connected. |
IGNITION TIMING (Degrees BTDC @ RPM)
3-Cylinder Firing Order & Distributor Rotation. Scheme 1
Scheme 2
DISTRIBUTOR SPECIFICATIONS
Note. All models use electronic ignition with spark timing controlled by emission system control unit.
| Application | In. (mm) |
|---|---|
| 1.2L | .008-.016 (0.2-0.4) |
PICK-UP COIL AIR GAP
FUEL PUMP
Note. Fuel pump performance is a measurement of fuel pressure and volume availability, not regulated fuel pressure.
| Application | Pressure: psi (kg/cm 2 ) | Min. Vol. @ 30 sec.: Pts. (L) |
|---|---|---|
| 1.2L 2-Bbl. | 1.3-2.0 (.09-.14) | .35 (.17) |
| 1.2L PFI | (1) | (1) |
| (1) Information not available from manufacturer. | ||
| (1) | Information not available from manufacturer. |
FUEL PUMP PERFORMANCE
| Application | At Idle: psi (kg/cm 2 ) |
|---|---|
| PFI | 26-30 (1.8-2.1) |
REGULATED FUEL PRESSURE
INJECTOR RESISTANCE
| Application | Ohms |
|---|---|
| 1.2L | 10.0-18.0 |
INJECTOR RESISTANCE SPECIFICATIONS
IDLE SPEED & MIXTURE
| Application | RPM | |
|---|---|---|
| 1.2L (1) | ||
| 2-Bbl. | 750-850 | |
| PFI | 650-750 | |
| (1) With test mode & read memory connector connected. | ||
| (1) | With test mode & read memory connector connected. |
IDLE SPEED SPECIFICATIONS
FAST IDLE SPEED - CARBURETED
Note. Fast idle speed is not available from manufacturer. See REMOVE/INSTALL/OVERHAUL article in the ENGINE PERFORMANCE Section for FAST IDLE ADJUSTMENT procedure.
THROTTLE POSITION SWITCH
| Terminal No. | Ohms | |
|---|---|---|
| No. 2 & 3 | ||
| Throttle Fully Closed | Less Than One | |
| Throttle Fully Open | Infinite | |
THROTTLE POSITION SWITCH RESISTANCE
