Electrical Component Locator Subaru Justy I

Electrical Component Locations 14 illustrations ~167 words

BUZZERS, RELAYS & TIMERS

ComponentLocation
Headlight RelayBehind instrument cluster.
Intermittent Wiper UnitAn integral part of wiper washer switch.
Seat Belt Warning TimerBelow right side of dash, on right kick panel. (Scheme 1)
Warning ChimeBehind instrument cluster, to right of steering column. (Scheme 2)

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

ComponentLocation
Fuse BlockOn left side of dash, to left of steering column. (Scheme 3)
Fusible LinksAttached to left strut tower, next to brake master cylinder. (Scheme 4)

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

ComponentLocation
Electronic Control Module (ECM)Behind instrument cluster, on driver's side kick panel. (Scheme 5)

CONTROL UNITS LOCATION

SENDING UNITS & SENSORS

ComponentLocation
Brake Fluid Level SensorPart of brake fluid reservoir cap. (Scheme 4)
Fuel Gauge Sending UnitIn fuel tank.
Oxygen SensorOn exhaust manifold.
Revolution (RPM) SensorBehind right side of dash, on right kick panel. (Scheme 1)
ThermosensorOn intake manifold, below thermostat housing. (Scheme 12)
Vacuum SensorOn right front fender, near strut tower. (Scheme 11)& (Scheme 13).

SENDING UNITS & SENSORS LOCATION

MOTORS

ComponentLocation
Front & Rear Washer PumpsOn left front fender, in wiper washer reservoir. (Scheme 6)
Fuel PumpAttached to underside of body, near left rear tire. (Scheme 7)
Heater Blower MotorUnder dash, on bottom of heater housing. (Scheme 8)& (Scheme 9).
Tailgate Wiper MotorIn center of tailgate assembly. (Scheme 10)
Windshield Wiper MotorBelow windshield, between cowl and firewall. (Scheme 9)& (Scheme 11).

MOTORS LOCATION

SOLENOIDS & SOLENOID VALVES

ComponentLocation
Air/Fuel Mixture (Duty) SolenoidOn carburetor throttle body.
Canister Purge SolenoidOn right front fender, near vapor canister. (Scheme 13)
Float Chamber Ventilation (FCV) SolenoidOn right front fender, near strut tower. (Scheme 13)
High Altitude Compensation (HAC) SolenoidsOn right front fender, near strut tower. (Scheme 13)
Idle-Up SolenoidOn left side of firewall, to right of brake master cylinder. (Scheme 13)
Slow-Cut ValveAttached to carburetor.
Vacuum Line Charging (VLC) SolenoidOn right front fender, near strut tower. (Scheme 11)& (Scheme 13).

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

ComponentLocation
Anti-Dieseling SwitchOn carburetor.
Back-Up Light SwitchOn top of transaxle case, above left drive axle. (Scheme 14)
Cooling Fan SwitchOn intake manifold, below thermostat housing. (Scheme 12)
Clutch SwitchAttached to clutch pedal bracket.
Oil Pressure SwitchOn side of crankcase.
Parking Brake SwitchAt base of parking brake lever.
Seat Belt SwitchPart of driver's seat belt assembly.
Stoplight SwitchAttached to brake pedal bracket.
Tailgate SwitchIn tailgate latch assembly.

SWITCHES LOCATION

MISCELLANEOUS

ComponentLocation
Diagnostic Connectors
Engine CompartmentOn right front fender, near strut tower. (Scheme 11)
Passenger CompartmentOn driver's side kick panel.
Heater Blower Motor ResistorAttached to A/C-heater blower motor housing. (Scheme 9)
Wiring Harness DiodeOn right side of dash, behind glove box.

MISCELLANEOUS LOCATION

COMPONENT LOCATION GRAPHICS

Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.

Component Locations (1 Of 14). Scheme 1

Scheme 1: Component Locations (1 Of 14)

Component Locations (2 Of 14). Scheme 2

Scheme 2: Component Locations (2 Of 14)

Component Locations (3 Of 14). Scheme 3

Scheme 3: Component Locations (3 Of 14)

Component Locations (4 Of 14). Scheme 4

Scheme 4: Component Locations (4 Of 14)

Component Locations (5 Of 14). Scheme 5

Scheme 5: Component Locations (5 Of 14)

Component Locations (6 Of 14). Scheme 6

Scheme 6: Component Locations (6 Of 14)

Component Locations (7 Of 14). Scheme 7

Scheme 7: Component Locations (7 Of 14)

Component Locations (8 Of 14). Scheme 8

Scheme 8: Component Locations (8 Of 14)

Component Locations (9 Of 14). Scheme 9

Scheme 9: Component Locations (9 Of 14)

Component Locations (10 Of 14). Scheme 10

Scheme 10: Component Locations (10 Of 14)

Component Locations (11 Of 14). Scheme 11

Scheme 11: Component Locations (11 Of 14)

Component Locations (12 Of 14). Scheme 12

Scheme 12: Component Locations (12 Of 14)

Component Locations (13 Of 14). Scheme 13

Scheme 13: Component Locations (13 Of 14)

Component Locations (14 Of 14). Scheme 14

Scheme 14: Component Locations (14 Of 14)
