Wiper System & Washer System (Except Sti): Adjustments Subaru Impreza GH

Wiper/washer Systems 11 illustrations ~349 words

ADJUSTMENT

Operate the wiper once. Align the wiper blade to ceramic print point mark (A) of front window panel.

Scheme 55

Scheme 55: REMOVAL
Scheme 55: REMOVAL
  1. Disconnect the ground cable from the battery.
  2. Remove the cowl panel. Ref. to «REMOVAL»(ref-357250-S32825845852010031100000) , Cowl Panel.
  3. Disconnect the connector of motor.
  4. Remove the bolt, and then remove the wiper link.
  5. Remove the bolts and nuts and remove the motor.

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57: INSTALLATION
Scheme 57: INSTALLATION
  1. Connect the ground cable to battery.
  2. To confirm that the motor is at the auto stop position, connect the harness to the motor and turn the wiper switch to ON/OFF once.
  3. Disconnect the ground cable from battery.
  4. Tighten the nut where rod (A) and link plate (B) is aligned in a straight line.
  5. Install in the reverse order of removal.

Tightening torque

FRONT WIPER, COMPONENT, General Description.>

Scheme 58

Scheme 58: INSPECTION
Scheme 58: INSPECTION

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61
  1. When the battery is connected to the terminal of connectors as shown in the figure, confirm that the motor operates at low speed.
  2. When the battery is connected to the terminal of connectors as shown in the figure, confirm that the wiper motor operates at high speed.
  3. Connect the battery to terminals of the connector, and remove the terminal connection with motor rotating at low speed, and stop the wiper motor in mid-operation.
  4. Connect the battery and confirm that the motor stops at the automatic stop position after the motor operates at low speed again.
  1. Turn the wiper switch to OFF position.
  2. While the vehicle is at a standstill, adjust the washer injection position as shown in the figure.

Spray position

A: 250 mm (9.84 in)

B: 315 mm (12.4 in)

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL
  1. Detach the wiper arm cover (A).
  2. Remove the nut and remove the wiper arm.

Scheme 64

Scheme 64
Scheme 64
  1. Operate the rear wiper once.
  2. Align the blade with the marking (A) of the glass.
  1. Turn the wiper switch to OFF position.
  2. While the vehicle is at a standstill, adjust the washer injection position as shown in the figure.

Spray position

A: 140 mm (5.5 in)

B: 70°

Scheme 65

Scheme 65
Scheme 65
