UNDER-DASH FUSE/RELAY BOX
Under-dash fuse/relay box is located under the instrument panel behind the fuse box cover on driver's side, see illustration below.
Scheme 1
Scheme 2
| Fuse No. | Fuse Rating | Circuit |
|---|---|---|
| 1 | 20A | Trailer |
| 2 | Empty | |
| 3 | 15A | Door Locking |
| 4 | 10A | Front Wiper Deicer Relay |
| 5 | 10A | Combination meter |
| 6 | 7.5A | Remote controlled rear view mirrors Seat heater relay |
| 7 | 15A | Combination meter Integrated unit |
| 8 | 20A | Stop lights |
| 9 | 15A | Front wiper deicer |
| 10 | 7.5A | Power supply (battery) |
| 11 | 7.5A | Turn signal unit Clock |
| 12 | 15A | Automatic transmission unit Engine control unit Integrated unit |
| 13 | 20A | Accessory power outlet (center console) |
| 14 | 15A | Position lights Tail lights Rear combination lights |
| 15 | Empty (FWD connector for AWD AT vehicles) | |
| 16 | 10A | Illumination |
| 17 | 15A | Seat heaters |
| 18 | 10A | Back-up lights |
| 19 | Empty | |
| 20 | 10a | Accessory power outlet (Instrument panel) |
| 21 | 7.5A | Starter relay |
| 22 | 15A | Air conditioner Rear window defogger relay coil |
| 23 | 15A | Rear wiper Rear window washer |
| 24 | 15A | Audio unit Clock |
| 25 | 15A | SRS airbag system |
| 26 | 7.5A | Power window relay Radiator main fan relay Tail & Illumination relay |
| 27 | 15A | Blower fan |
| 28 | 15A | Blower fan |
| 29 | 15A | Fog lights |
| 30 | 30A | Front wiper |
| 31 | 7.5A | Auto air conditioner unit Integrated unit |
| 32 | Empty | |
| 33 | 7.5A | ABS/Vehicle Dynamics Control Unit |
UNDER-DASH FUSE/RELAY BOX LEGEND
UNDER-HOOD FUSE/RELAY BOX
Under-hood fuse/relay box is located in the engine compartment, see illustration below.
Scheme 3
Scheme 4
| Fuse No. | Fuse Rating | Circuit |
|---|---|---|
| A | Main fuse | |
| 1 | 30A | ABS Vehicle Dynamics Control Unit |
| 2 | 25A | Main fan |
| 3 | 10A | Secondary air combination valve (Turbo models only) |
| 4 | 25A | Sub fan |
| 5 | Empty | |
| 6 | 10A | Audio |
| 7 | 30A | Headlight (Low beam) |
| 8 | 15A | Headlight (High beam) |
| 9 | 20A | Back-up lights |
| 10 | 15A | Horn |
| 11 | 25A | Rear window defogger Mirror heater |
| 12 | 15A | Fuel pump |
| 13 | 10A | Automatic Transmission Control Unit |
| 14 | 7.5A | Engine Control Unit |
| 15 | 15A | Turn & Hazard warning flashers |
| 16 | 15A | Tail & Illumination relay |
| 17 | 7.5A | Alternator |
| 18 | 15A | Headlight (Right side) |
| 19 | 15A | Headlight (Left side) |
UNDER-HOOD FUSE/RELAY BOX LEGEND
