GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance and voltage. |
| Oscilloscope | Used for inspecting the waveform of each sensor. |
GENERAL TOOL CHART
Scheme 238
Scheme 239
Scheme 240
- Set the vehicle on a lift.
- Disconnect the ground cable from battery.
- Lift up the vehicle.
- Remove the under cover.
- Drain approximately 3.0 l (3.2 US qt, 2.6 lmp qt) of coolant. Ref. to «DRAINING OF ENGINE COOLANT»(ref-357080-S30342819572010030800000) , REPLACEMENT, Engine Coolant.
- Remove the intercooler. Ref. to «REMOVAL»(ref-357076-S27886545212010030800000) , Intercooler.
- Disconnect the connector from the throttle position sensor (A), and the manifold pressure sensor (B).
- Disconnect the engine coolant hose from throttle body.
- Remove the bolts which secure the throttle body to the intake manifold and remove the throttle body.
