Entertainment (Except Sti): Removal & Installation Subaru Impreza GH

Entertainment Systems 12 illustrations ~431 words

INSTALLATION

Install in the reverse order of removal.

Scheme 24

Scheme 24: REMOVAL
Scheme 24: REMOVAL
  1. Disconnect the ground cable from the battery.
  2. Remove the front door trim. Ref. to «REMOVAL»(ref-357250-S10817427222010031100000) , Door Trim.
  3. Remove the front speaker mounting screws.
  4. Disconnect the harness connector and remove the front speaker.

Install in the reverse order of removal.

REMOVAL

  1. Disconnect the ground cable from battery.
  2. Remove the front door gusset cover. Ref. to «REMOVAL»(ref-357250-S10817427222010031100000) , Door Trim.
  3. Disconnect the harness connector.
  4. Remove the screws and detach the tweeter.

Scheme 25

Scheme 25
Scheme 25

Install in the reverse order of removal.

Scheme 26

Scheme 26: REMOVAL
Scheme 26: REMOVAL
  1. Disconnect the ground cable from the battery.
  2. Remove the rear door trim. Ref. to «REMOVAL»(ref-357250-S10817427222010031100000) , Door Trim.
  3. Remove the rear speaker mounting screws.
  4. Disconnect the harness connector and remove the rear speaker.

Install in the reverse order of removal.

Scheme 27

Scheme 27: REMOVAL
Scheme 27: REMOVAL
  1. Remove the roof trim. Ref. to «REMOVAL»(ref-357250-S27448596662010031100000) , Roof Trim.
  2. Disconnect the harness connectors and terminals and remove the fitting nut (A).
  3. Pull off the antenna from the roof.

Scheme 28

Scheme 28
Scheme 28

Install in the reverse order of removal.

WARNINGBefore servicing, be sure to read the notes in the "AB" section for proper handling of the driver's airbag module. Ref. to CAUTION , General Description.

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Set the front wheels in straight ahead position.
  2. Turn the ignition switch to OFF.
  3. Disconnect the ground cable from battery and wait for at least 20 seconds before starting work.
  4. Using TORX® bit T30 (1), loosen two TORX® bolts which secure the driver's airbag module.
  5. Disconnect the airbag module connector on back of the airbag module. Ref. to «PROCEDURE»(ref-357264-S02716394582010031100000) , Airbag Connector.
  6. Remove the steering wheel. Ref. to «REMOVAL»(ref-357258-S09754233232010031100000) , Steering Wheel.
  7. Remove the screws to remove the lower cover from steering wheel.
  8. Loosen the screws on the backside of the steering wheel and remove the satellite switch.

Scheme 31

Scheme 31
Scheme 31

Install in the reverse order of removal.

Install in the reverse order of removal.

  1. Disconnect the ground cable from battery.
  2. Remove the instrument panel lower. Ref. to «INSTRUMENT PANEL, LOWER»(ref-357250-S37178853122010031100000) , REMOVAL, Center Console.
  3. Disconnect the harness connectors and remove the front accessory power supply socket.

Scheme 32

Scheme 32
Scheme 32

Install in the reverse order of removal.

  1. Disconnect the ground cable from battery.
  2. Remove the console box. Ref. to «REMOVAL»(ref-357250-S06797543912010031100000) , Console Box.
  3. Disconnect the harness connector, and remove the claws (two) in accessory power supply socket.
  4. Pull the accessory power supply socket out to remove.

Scheme 33

Scheme 33
Scheme 33

Install in the reverse order of removal.

  1. Disconnect the ground cable from battery.
  2. Remove the console box. Ref. to «REMOVAL»(ref-357250-S06797543912010031100000) , Console Box.
  3. Disconnect the harness connector.
  4. Disengage four claws, and remove the AUX input terminal by pushing it into the console box.

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Install in the reverse order of removal.
