CAUTION
- Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
- Remove contamination including dirt and corrosion before removal or installation.
- Keep the parts in order and protect them from dust and dirt.
- Before removal or installation, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
- Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
- Be sure to tighten fasteners including bolts and nuts to the specified torque.
- Place shop jacks or rigid racks at the specified points.
- Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring voltage. |
GENERAL TOOL SPECIFICATION
Scheme 11
Scheme 12
- Disconnect the ground cable from battery.
- Disconnect the connector (A).
- Remove the nut (B) securing accelerator pedal assembly, and remove the accelerator pedal assembly.
ACCELERATOR PEDAL SENSOR (METHOD WITH SUBARU SELECT MONITOR)
- Turn the ignition switch to ON. (engine OFF)
- Read the accelerator pedal opening angle signal and voltage of accelerator pedal sensor using Subaru Select Monitor. Ref. to «READ CURRENT DATA FOR ENGINE (NORMAL MODE)»(ref-357088-S16053884052010030800000) , OPERATION, Subaru Select Monitor. STANDARD SPECIFICATION Accelerator pedal sensor Accelerator pedal opening angle signal Standard Main 0.0 % 0.4 - 1.0 V 100.0% 2.4 - 3.7 V Sub 0.0 % 0.3 - 1.1 V 100.0% 2.3 - 3.8 V
