Airbag System (Diagnostics) (Except Sti): Component Locations Subaru Impreza GH

SPECIAL TOOL

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system

Scheme 267

1. TEST HARNESS H

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and satellite safing sensor

Scheme 268

1. TEST HARNESS N

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module and seat belt pretensioner

Scheme 269

1. TEST HARNESS P

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of driver's airbag module harness

Scheme 270

Scheme 271

1. TEST HARNESS Q

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module

Scheme 272

1. TEST HARNESS AG

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module

Scheme 273

Scheme 274

1. TEST HARNESS AJ

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness

Scheme 275

1. TEST HARNESS V

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor

Scheme 276

1. TEST HARNESS AB

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA000 TEST HARNESS AB Used when measuring voltage and resistance of occupant detection system

Scheme 277

Scheme 278

1. AIRBAG RESISTOR

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two ST are required for diagnosis of two-stage inflator type airbag module

Scheme 279

1. TEST HARNESS Al

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS Al Used when diagnosing the side airbag sensor and curtain airbag sensor. Used together with test harness V

Scheme 280
