Engine Controls - Service & Adjustment Specifications: Adjustments Subaru Impreza GD/GC/GG facelift

Specifications 1 illustration

Drive Belt Adjustment

Application (1)Deflection - In. (mm)
New Belt
A/C.30-.34 (7.5-8.5)
Alternator & P/S.28-.35 (7.0-9.0)
Reused Belt
A/C.35-.39 (9.0-10.0)
Alternator & P/S.35-.43 (9.0-11.0)
(1) For Outback 3.0L, replace if automatic tensioner indicator is not within service limit range. (Scheme 1)
(1)For Outback 3.0L, replace if automatic tensioner indicator is not within service limit range. (Scheme 1)

BELT ADJUSTMENT

Scheme 1

Scheme 1
Scheme 1
