Specifications & Procedures: Overview Subaru Impreza GD/GC/GG

Front Stabilizer Bar Specification. Scheme 1

Rear Stabilizer Bar Specification. Scheme 2

Front Wheel Alignment Specifications. Scheme 3

Rear Wheel Alignment Specifications. Scheme 4

Note. Front and rear toe-ins and front camber can be adjusted. If toe-in or camber tolerance exceeds specifications, adjust toe-in and camber to the specification. The other items indicated in the specification table cannot be adjusted. If the other items exceeds specifications, check suspension parts and connections for deformities; and replace with new ones as required.

Wheel Alignment Angles. Scheme 5

Identifying Front Suspension Components. Scheme 6

Tightening torque: N.m (kgf-m, ft-lb)

1. T1: 18 (1.8, 13.0)
2. T2: 20 (2.0, 14.5)
3. T3: 25 (2.5, 18.1)
4. T4: 29 (3.0, 21.7)
5. T5: 39 (4, 29)
6. T6: 44 (4.5, 32.5)
7. T7: 49 (5.0, 36)
8. T8: 54 (5.5, 39.8)
9. T9: 98 (10.0, 72)
10. T10: 152 (15.5, 112)
11. T11: 186 (19.0, 137)
12. T12: 245 (25.0, 181)

Identifying Rear Suspension Components. Scheme 7

Tightening torque: N.m (kgf-m, ft-lb)

1. T1: 20 (2.0, 14.5)
2. T2: 25 (2.5, 18.1)
3. T3: 44 (4.5, 32.5)
4. T4: 59 (6.0, 43)
5. T5: 98 (10.0, 72)
6. T6: 98 (10.0, 72)
7. T7: 113 (11.5, 83)
8. T8: 127 (13.0, 94)
9. T9: 137 (14.0, 101)
10. T10: 196 (20.0, 145)
