INSTALLATION
To install, reverse the removal sequence.
Scheme 47
Scheme 48
- Install the air breather cap tapping with a plastic hammer. CAUTION: Be sure to install new air breather cap.
- Position front member on body by passing it under parking brake cable and securing to rear differential. NOTE: When installing rear differential front member, do not confuse the installation sequence of the upper and lower stoppers.
- Install DOJ of rear drive shaft into rear differential. See «REPLACEMENT»(ref-177243-S24786067012005052500000), Rear Differential Side Oil Seal. ST 28099PA090 SIDE OIL SEAL PROTECTOR (Scheme 47): Installing DOJ Of Rear Drive Shaft Into Rear Differential
- Installing procedure hereafter is in the reverse order of removal.
- After installation, fill differential carrier with gear oil to the upper plug level. CAUTION: Apply fluid packing to plug. Fluid packing: THREE BOND 1105 or equivalent Oil capacity: 0.8 l (0.8 US qt, 0.7 lmp qt) Tightening torque: 49.0 N.m (5.0 kgf-m, 36.2 ft-lb) (Scheme 48): Identifying Rear Differential Fill Plug
To install, reverse the removal sequence.
Scheme 49
Scheme 50
- Position front member on body by passing it under parking brake cable and securing to rear differential. NOTE: When installing rear differential front member, do not confuse the installation sequence of the upper and lower stoppers.
- Install DOJ of rear drive shaft into rear differential. See «REPLACEMENT»(ref-177243-S24786067012005052500000), Rear Differential Side Oil Seal. ST 28099PA090 SIDE OIL SEAL PROTECTOR see scheme 99: Installing DOJ Of Rear Drive Shaft Into Rear Differential
- Installing procedure hereafter is in the reverse order of removal.
- After installation, fill differential carrier with gear oil to the upper plug level. CAUTION: Use a new aluminum gasket when installing the plug. Oil capacity: 0.8 l (0.8 US qt, 0.7 lmp qt) Tightening torque: 34 N.m (3.5 kgf-m, 25.3 ft-lb) see scheme 100: Filling Differential Carrier With Gear Oil To The Upper Plug Level
