STi model
| Drive pinion bearing preload at companion flange bolt hole : N (kgf, lb) | 24.1 - 38.6 (2.5 - 3.9, 5.4 - 8.7) | |||
|---|---|---|---|---|
| Preload adjusting spacer | Part No. | Length mm (in) | ||
| 31454AA130 | 52.2 (2.055) | |||
| 31454AA140 | 52.4 (2.063) | |||
| 31454AA150 | 52.6 (2.071) | |||
| 31454AA160 | 52.8 (2.079) | |||
| 31454AA170 | 53.0 (2.087) | |||
| 31454AA180 | 53.2 (2.094) | |||
| Preload adjusting washer | Part No. | Length mm (in) | ||
| 383705200 | 2.59 (0.1020) | |||
| 383715200 | 2.57 (0.1012) | |||
| 383725200 | 2.55 (0.1004) | |||
| 383735200 | 2.53 (0.0996) | |||
| 383745200 | 2.51 (0.0988) | |||
| 383755200 | 2.49 (0.0980) | |||
| 383765200 | 2.47 (0.0972) | |||
| 383775200 | 2.45 (0.0965) | |||
| 383785200 | 2.43 (0.0957) | |||
| 383795200 | 2.41 (0.0949) | |||
| 383805200 | 2.39 (0.0941) | |||
| 383815200 | 2.37 (0.0933) | |||
| 383825200 | 2.35 (0.0925) | |||
| 383835200 | 2.33 (0.0917) | |||
| 383845200 | 2.31 (0.0909) | |||
| Pinion height adjusting washer | Part No. | Length mm (in) | ||
| 38336AA230 | 3.09 (0.1217) | |||
| 38336AA240 | 3.12 (0.1228) | |||
| 38336AA250 | 3.15 (0.1240) | |||
| 38336AA260 | 3.18 (0.1252) | |||
| 38336AA270 | 3.21 (0.1264) | |||
| 38336AA280 | 3.24 (0.1276) | |||
| 38336AA290 | 3.27 (0.1287) | |||
| 38336AA300 | 3.30 (0.1299) | |||
| 38336AA310 | 3.33 (0.1311) | |||
| 38336AA320 | 3.36 (0.1323) | |||
| 38336AA330 | 3.39 (0.1335) | |||
| 38336AA340 | 3.42 (0.1346) | |||
| 38336AA350 | 3.45 (0.1358) | |||
| 38336AA360 | 3.48 (0.1370) | |||
| 38336AA370 | 3.51 (0.1382) | |||
| 38336AA380 | 3.54 (0.1394) | |||
| 38336AA390 | 3.57 (0.1406) | |||
| 38336AA400 | 3.60 (0.1417) | |||
| 38336AA410 | 3.63 (0.1429) | |||
| 38336AA420 | 3.66 (0.1441) | |||
| Side bearing standard width | Mm (in) | 20.00 (0.7874) | ||
| Side bearing retainer shim | Part No. | Thickness mm (in) | ||
| 383475201 | 0.20 (0.0079) | |||
| 383475202 | 0.25 (0.0098) | |||
| 383475203 | 0.30 (0.0118) | |||
| 383475204 | 0.40 (0.0157) | |||
| 383475205 | 0.50 (0.0197) | |||
| Limit | Mm (in) | Hypoid driven gear to drive pinion backlash | 0.10 - 0.20 (0.0039 - 0.0079) | |
| Hypoid driven gear runout on its back surface | 0.05 (0.0020) | |||
ADJUSTING PARTS SPECIFICATION (STI MODEL)
