SPECIAL TOOL
| ILLUSTRATION | TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|---|
| (Scheme 23) | 398477701 | HANDLE | Used for installing front and rear bearing cone. |
| (Scheme 24) | 398477702 | DRIFT | Used press-fitting the bearing cone of differential carrier (rear). |
| (Scheme 25) | 398217700 | ATTACHMENT SET | Stand for rear differential carrier disassembly and assembly. |
| (Scheme 26) | 498447120 | INSTALLER | Used for installing front oil seal. |
| (Scheme 27) | 498427200 | FLANGE WRENCH | Used for stopping rotation of companion flange when loosening and tightening self-locking nut. For except STi model. |
| (Scheme 28) | 398467700 | DRIFT | Used for removing pinion, pilot bearing and front bearing cone. |
| (Scheme 29) | 399780104 | WEIGHT | Used for installing front bearing cone, pilot bearing companion flange. |
| (Scheme 30) | 899580100 | INSTALLER | Used for press-fitting the front bearing cone, pilot bearing. |
| (Scheme 31) | 899904100 | STRAIGHT PIN REMOVER | Used for driving out differential pinion shaft lock pin. |
| (Scheme 32) | 498247001 | MAGNET BASE | Used for measuring backlash between side gear and pinion, and hypoid gear. Used with DIAL GAUGE (498247100). |
| (Scheme 33) | 498247100 | DIAL GAUGE | Used measuring backlash between side gear and pinion, hypoid gear. Used with MAGNET BASE (498247001). |
| (Scheme 34) | 398507704 | BLOCK | Used for adjusting pinion height and preload. |
| (Scheme 35) | 398457700 | INSTALLER | Used for installing gear bearing cone. |
| (Scheme 36) | 398457700 | ATTACHMENT | Used for removing side bearing retainer. |
| (Scheme 37) | 398477703 | DRIFT2 | Used for press-fitting the bearing race (rear) of differential carrier. |
| (Scheme 38) | 398437700 | DRIFT | Used for installing side oil seal. |
| (Scheme 39) | 398507702 | DUMMY SHAFT | Used for adjusting pinion height and preload. |
| (Scheme 40) | 398507703 | DUMMY COLLAR | Used for adjusting pinion height and preload. |
| (Scheme 41) | 398517700 | REPLACER | Used for removing rear bearing cone. |
| (Scheme 42) | 398487700 | DRIFT | Used for press-fitting the side bearing cone. |
| (Scheme 43) | 398507701 | DIFFERENTIAL CARRIER GAUGE | Used for adjusting pinion height. |
| (Scheme 44) | 398527700 | PULLER ASSY | Used for removing front oil seal. Used for removing side bearing cup. |
| (Scheme 45) | 398227700 | WEIGHT | Used for installing side bearing. |
| (Scheme 46) | 28099PA090 | OIL SEAL PROTECTOR | Used for installing rear drive shaft into rear differential. For protecting oil seal. |
| (Scheme 47) | 398237700 | GAUGE | Used for installing side bearing. |
| (Scheme 48) | 28099PA100 | DRIVE SHAFT REMOVER | Used for removing rear drive shaft from rear differential. |
| (Scheme 49) | 399703600 | PULLER ASSY | Used for removing companion flange. |
| (Scheme 50) | 899874100 | INSTALLER | Used for installing companion flange. |
| (Scheme 51) | 18759AA000 (Newly adopted tool) | PULLER ASSY | Used for removing side bearing cone of differential. |
| (Scheme 52) | 498937110 | HOLDER DRIVE PINION (This special tool is used for current automatic transmission.) | Used for installing pilot bearing. For STi model. |
| (Scheme 53) | 18674AA000 (Newly adopted tool) | INSTALLER | Used for installing rear bearing cone. For STi model. |
| (Scheme 54) | 398417700 | DRIFT (This special tool was prepared for the vehicles of 92MY and before.) | Used for installing side bearing race. For STi model. |
| (Scheme 55) | 18633AA000 (Newly adopted tool) | WRENCH COMPL | Used for stopping rotating of companion flange when loosening and tightening self-locking nut. For STi model. |
