STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Carbon Brushes | ||
| Minimum Length | .35" (9.0 mm) | |
| Standard Length | .55" (14.0 mm) | |
| Commutator Runout | ||
| Limit | .0020" (.050 mm) | |
| Standard | .0008" (.020 mm) | |
| Commutator Outside Diameter | ||
| Limit | 1.14" (29.0 mm) | |
| Standard | 1.18" (30.0 mm) | |
| Commutator Mica Depth | ||
| Limit | .008" (.20 mm) | |
| Standard | .020-.031" (.50-.80 mm) | |
| Load Test | ||
| Load | 7 Ft. Lbs. (10 N.m) | |
| Maximum Amps (A/T) | 370 Amps | |
| Maximum Amps (M/T) | 280 Amps | |
| Minimum RPM (A/T) | 880 RPM | |
| Minimum RPM (M/T) | 900 RPM | |
| Voltage Drop (Minimum) | 8 Volts | |
| Lock Test | ||
| Minimum Voltage | 5 Volts | |
| Maximum Amps (A/T) | 1050 Amps | |
| Maximum Amps (M/T) | 800 Amps | |
| Minimum Torque | 20 Ft. Lbs. (27 N.m) | |
| No-Load Test | ||
| Maximum Amps | 90 Amps | |
| Minimum RPM (A/T) | 2900 RPM | |
| Minimum RPM (M/T) | 3000 RPM | |
| Voltage Drop (Minimum) | 11 Volts | |
