POWER MIRROR SWITCH
Pry mirror switch from instrument panel using a small screwdriver. Disconnect switch connector. Check continuity between specified terminals of switch connector with switch button in specified position. See POWER MIRROR SWITCH CONTINUITY TEST. (Scheme 2), (Scheme 3) or see scheme 3. Replace switch if continuity is not as specified.
| Switch Position | Wire Color | Terminal No. | |
|---|---|---|---|
| Left Mirror | |||
| Up | GRN/BLK & BLU/BLK | 4 & 7 | |
| Up | BLK & RED | 2 & 1 | |
| Down | RED & BLU/BLK | 2 & 7 | |
| Down | GRN/BLK & RED | 4 & 1 | |
| Left | GRN/BLK & BLK/RED | 4 & 9 | |
| Left | BLK & RED | 2 & 1 | |
| Right | RED & BLK/RED | 2 & 9 | |
| Right | GRN/BLK & RED | 4 & 1 | |
| Right Mirror | |||
| Up | GRN/BLK & BRN | 4 & 6 | |
| Up | BLK & RED | 2 & 1 | |
| Down | BLK & BRN | 2 & 6 | |
| Down | GRN/BLK & RED | 4 & 1 | |
| Left | GRN/BLK & RED/BLU | 4 & 8 | |
| Left | BLK & RED | 2 & 1 | |
| Right | BLK & RED/BLU | 2 & 8 | |
| Right | GRN/BLK & RED | 4 & 1 | |
POWER MIRROR SWITCH CONTINUITY TEST
Scheme 2
POWER MIRROR MOTOR
Remove door panel. Disconnect mirror motor harness connector. Using 12-volt power supply and 2 jumper wires, apply voltage and ground to specified terminal. See POWER MIRROR MOTOR TEST (BOTH MIRRORS). (Scheme 3)
| Movement | Pin No. (+) (Wire Color) | Pin No. (-) (Wire Color) |
|---|---|---|
| Up | 1 (Blue) | 3 (Yellow) |
| Down | 3 (Yellow) | 1 (Blue) |
| Left | 1 (Blue) | 2 (White) |
| Right | 2 (White) | 1 (Blue) |
POWER MIRROR MOTOR TEST (BOTH MIRRORS)
