LIST
| DTC | Item | Index |
|---|---|---|
| P0011 | Intake Camshaft Position - Timing Over-Advanced Or System Performance (Bank 1) | DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0016 | Crankshaft Position - Camshaft Position Correlation (Bank 1) | DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0018 | Crankshaft Position - Camshaft Position Correlation (Bank 2) | DTC P0018 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0021 | Intake Camshaft Position - Timing Over-Advanced or System Performance (Bank 2) | DTC P0021 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0030 | HO2S Heater Control Circuit (Bank 1 Sensor 1) | DTC P0030 HO2S HEATER CONTROL CIRCUIT (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0031 | HO2S Heater Control Circuit Low (Bank 1 Sensor 1) | DTC P0031 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0032 | HO2S Heater Control Circuit High (Bank 1 Sensor 1) | DTC P0032 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0037 | HO2S Heater Control Circuit Low (Bank 1 Sensor 2) | DTC P0037 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0038 | HO2S Heater Control Circuit High (Bank 1 Sensor 2) | DTC P0038 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0068 | MAP/MAF - Throttle Position Correlation | DTC P0068 MAP/MAF - THROTTLE POSITION CORRELATION, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0101 | Mass or Volume Air Flow Circuit Range/Performance | DTC P0101 MASS OR VOLUME AIR FLOW CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0102 | Mass or Volume Air Flow Circuit Low Input | DTC P0102 MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0103 | Mass or Volume Air Flow Circuit High Input | DTC P0103 MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0107 | Manifold Absolute Pressure/Barometric Pressure Circuit Low Input | DTC P0107 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0108 | Manifold Absolute Pressure/Barometric Pressure Circuit High Input | DTC P0108 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0111 | Intake Air Temperature Sensor 1 Circuit Range/Performance | DTC P0111 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0112 | Intake Air Temperature Sensor 1 Circuit Low | DTC P0112 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0113 | Intake Air Temperature Sensor 1 Circuit High | DTC P0113 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0117 | Engine Coolant Temperature Circuit Low | DTC P0117 ENGINE COOLANT TEMPERATURE CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0118 | Engine Coolant Temperature Circuit High | DTC P0118 ENGINE COOLANT TEMPERATURE CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0122 | Throttle/Pedal Position Sensor/Switch "A" Circuit Low | DTC P0122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0123 | Throttle/Pedal Position Sensor/Switch "A" Circuit High | DTC P0123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0125 | Insufficient Coolant Temperature for Closed Loop Fuel Control | DTC P0125 INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0126 | Insufficient Engine Coolant Temperature for Stable Operation | DTC P0126 INSUFFICIENT ENGINE COOLANT TEMPERATURE FOR STABLE OPERATION, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0128 | Coolant Thermostat (Engine Coolant Temperature Below Thermostat Regulating Temperature) | DTC P0128 COOLANT THERMOSTAT (ENGINE COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0131 | O2 Sensor Circuit Low Voltage (Bank 1 Sensor 1) | DTC P0131 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0132 | O2 Sensor Circuit High Voltage (Bank 1 Sensor 1) | DTC P0132 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0133 | O2 Sensor Circuit Slow Response (Bank 1 Sensor 1) | DTC P0133 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0134 | O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 1) | DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0137 | O2 Sensor Circuit Low Voltage (Bank 1 Sensor 2) | DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0138 | O2 Sensor Circuit High Voltage (Bank 1 Sensor 2) | DTC P0138 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0139 | O2 Sensor Circuit Slow Response (Bank 1 Sensor 2) | DTC P0139 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0140 | O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 2) | DTC P0140 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0171 | System Too Lean (Bank 1) | DTC P0171 SYSTEM TOO LEAN (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0172 | System Too Rich (Bank 1) | DTC P0172 SYSTEM TOO RICH (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0181 | Fuel Temperature Sensor "A" Circuit Range/Performance | DTC P0181 FUEL TEMPERATURE SENSOR "A" CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0182 | Fuel Temperature Sensor "A" Circuit Low Input | DTC P0182 FUEL TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0183 | Fuel Temperature Sensor "A" Circuit High Input | DTC P0183 FUEL TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0222 | Throttle/Pedal Position Sensor/Switch "B" Circuit Low | DTC P0222 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0223 | Throttle/Pedal Position Sensor/Switch "B" Circuit High | DTC P0223 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0230 | Fuel Pump Primary Circuit | DTC P0230 FUEL PUMP PRIMARY CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0244 | Turbo/Super Charger Wastegate Solenoid "A" Range/Performance | DTC P0244 TURBO/SUPER CHARGER WASTE-GATE SOLENOID "A" RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0245 | Turbo/Super Charger Wastegate Solenoid "A" Low | DTC P0245 TURBO/SUPER CHARGER WASTE-GATE SOLENOID "A" LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0246 | Turbo/Super Charger Wastegate Solenoid "A" High | DTC P0246 TURBO/SUPER CHARGER WASTE-GATE SOLENOID "A" HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0301 | Cylinder 1 Misfire Detected | DTC P0301 CYLINDER 1 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0302 | Cylinder 2 Misfire Detected | DTC P0302 CYLINDER 2 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0303 | Cylinder 3 Misfire Detected | DTC P0303 CYLINDER 3 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0304 | Cylinder 4 Misfire Detected | DTC P0304 CYLINDER 4 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0327 | Knock Sensor 1 Circuit Low (Bank 1 or Single Sensor) | DTC P0327 KNOCK SENSOR 1 CIRCUIT LOW (BANK 1 OR SINGLE SENSOR), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0328 | Knock Sensor 1 Circuit High (Bank 1 or Single Sensor) | DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH (BANK 1 OR SINGLE SENSOR), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0335 | Crankshaft Position Sensor "A" Circuit | DTC P0335 CRANKSHAFT POSITION SENSOR "A" CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0336 | Crankshaft Position Sensor "A" Circuit Range/Performance | DTC P0336 CRANKSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0340 | Camshaft Position Sensor "A" Circuit (Bank 1 or Single Sensor) | DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0345 | Camshaft Position Sensor "A" Circuit (Bank 2) | DTC P0345 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0410 | Secondary Air Injection System | DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0411 | Secondary Air Injection System Incorrect Flow Detected | DTC P0411 SECONDARY AIR INJECTION SYSTEM INCORRECT FLOW DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0413 | Secondary Air Injection System Switching Valve "A" Circuit Open | DTC P0413 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "A" CIRCUIT OPEN, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0414 | Secondary Air Injection System Switching Valve "A" Circuit Shorted | DTC P0414 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "A" CIRCUIT SHORTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0416 | Secondary Air Injection System Switching Valve "B" Circuit Open | DTC P0416 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "B" CIRCUIT OPEN, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0417 | Secondary Air Injection System Switching Valve "B" Circuit Shorted | DTC P0417 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "B" CIRCUIT SHORTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0418 | Secondary Air Injection System Control "A" Circuit | DTC P0418 SECONDARY AIR INJECTION SYSTEM CONTROL "A" CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0420 | Catalyst System Efficiency Below Threshold (Bank 1) | DTC P0420 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0441 | Evaporative Emission System Incorrect Purge Flow | DTC P0441 EVAPORATIVE EMISSION SYSTEM INCORRECT PURGE FLOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0442 | Evaporative Emission Control System Leak Detected (Small Leak) | DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0447 | Evaporative Emission Control System Vent Control Circuit Open | DTC P0447 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT OPEN, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0448 | Evaporative Emission Control System Vent Control Circuit Shorted | DTC P0448 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT SHORTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0451 | Evaporative Emission Control System Pressure Sensor | DTC P0451 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0452 | Evaporative Emission Control System Pressure Sensor Low Input | DTC P0452 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0453 | Evaporative Emission Control System Pressure Sensor High Input | DTC P0453 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0456 | Evaporative Emission Control System Leak Detected (Very Small Leak) | DTC P0456 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (VERY SMALL LEAK), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0457 | Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off) | DTC P0457 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (FUEL CAP LOOSE/OFF), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0458 | Evaporative Emission System Purge Control Valve Circuit Low | DTC P0458 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0459 | Evaporative Emission System Purge Control Valve Circuit High | DTC P0459 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0461 | Fuel Level Sensor "A" Circuit Range/Performance | DTC P0461 FUEL LEVEL SENSOR "A" CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0462 | Fuel Level Sensor "A" Circuit Low | DTC P0462 FUEL LEVEL SENSOR "A" CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0463 | Fuel Level Sensor "A" Circuit High | DTC P0463 FUEL LEVEL SENSOR "A" CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0464 | Fuel Level Sensor Circuit Intermittent | DTC P0464 FUEL LEVEL SENSOR CIRCUIT INTERMITTENT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0500 | Vehicle Speed Sensor "A" | DTC P0500 VEHICLE SPEED SENSOR "A", Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0512 | Starter Request Circuit | DTC P0512 STARTER REQUEST CIRCUIT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0513 | Incorrect Immobilizer Key | DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0600 | Serial Communication Link | DTC P0600 SERIAL COMMUNICATION LINK, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0604 | Internal Control Module Random Access Memory (RAM) Error | DTC P0604 INTERNAL CONTROL MODULE RANDOM ACCESS MEMORY (RAM) ERROR, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0605 | Internal Control Module Read Only Memory (ROM) Error | DTC P0605 INTERNAL CONTROL MODULE READ ONLY MEMORY (ROM) ERROR, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0607 | Control Module Performance | DTC P0607 CONTROL MODULE PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0638 | Throttle Actuator Control Range/Performance (Bank 1) | DTC P0638 THROTTLE ACTUATOR CONTROL RANGE/PERFORMANCE (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0700 | Transmission Control System (MIL Request) | DTC P0700 TRANSMISSION CONTROL SYSTEM (MIL REQUEST), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0851 | Park/Neutral Switch Input Circuit Low (AT Model) | DTC P0851 PARK/NEUTRAL SWITCH INPUT CIRCUIT LOW (AT MODEL), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0851 | Neutral Switch Input Circuit Low (MT Model) | DTC P0851 NEUTRAL SWITCH INPUT CIRCUIT LOW (MT MODEL), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0852 | Park/Neutral Switch Input Circuit High (AT Model) | DTC P0852 PARK/NEUTRAL SWITCH INPUT CIRCUIT HIGH (AT MODEL), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P0852 | Neutral Switch Input Circuit High (MT Model) | DTC P0852 NEUTRAL SWITCH INPUT CIRCUIT HIGH (MT MODEL), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1152 | O2 Sensor Circuit Range/Performance (Low) (Bank 1 Sensor 1) | DTC P1152 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (LOW) (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1153 | O2 Sensor Circuit Range/Performance (High) (Bank 1 Sensor 1) | DTC P1153 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (HIGH) (BANK 1 SENSOR 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1160 | Return Spring Failure | DTC P1160 RETURN SPRING FAILURE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1400 | Fuel Tank Pressure Control Solenoid Valve Circuit Low | DTC P1400 FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1410 | Secondary Air Injection System Switching Valve Stuck Open | DTC P1410 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE STUCK OPEN, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1418 | Secondary Air Injection System Control "A" Circuit Shorted | DTC P1418 SECONDARY AIR INJECTION SYSTEM CONTROL "A" CIRCUIT SHORTED, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1420 | Fuel Tank Pressure Control Sol. Valve Circuit High | DTC P1420 FUEL TANK PRESSURE CONTROL SOL. VALVE CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1443 | Vent Control Solenoid Valve Function Problem | DTC P1443 VENT CONTROL SOLENOID VALVE FUNCTION PROBLEM, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1491 | Positive Crankcase Ventilation (Blow-by) Function Problem | DTC P1491 POSITIVE CRANKCASE VENTILATION (BLOW-BY) FUNCTION PROBLEM, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1560 | Back-up Voltage Circuit Malfunction | DTC P1560 BACK-UP VOLTAGE CIRCUIT MALFUNCTION, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1570 | Antenna | DTC P1570 ANTENNA, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1571 | Reference Code Incompatibility | DTC P1571 REFERENCE CODE INCOMPATIBILITY, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1572 | IMM Circuit Failure (Except Antenna Circuit) | DTC P1572 IMM CIRCUIT FAILURE (EXCEPT ANTENNA CIRCUIT), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1574 | Key Communication Failure | DTC P1574 KEY COMMUNICATION FAILURE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1576 | EGI Control Module EEPROM | DTC P1576 EGI CONTROL MODULE EEPROM, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1577 | IMM Control Module EEPROM | DTC P1577 IMM CONTROL MODULE EEPROM, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1578 | Meter Failure | DTC P1578 METER FAILURE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P1602 | Control Module Programming Error | DTC P1602 CONTROL MODULE PROGRAMMING ERROR, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2004 | Intake Manifold Runner Control Stuck Open (Bank 1) | DTC P2004 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2005 | Intake Manifold Runner Control Stuck Open (Bank 2) | DTC P2005 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2006 | Intake Manifold Runner Control Stuck Closed (Bank 1) | DTC P2006 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2007 | Intake Manifold Runner Control Stuck Closed (Bank 2) | DTC P2007 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2008 | Intake Manifold Runner Control Circuit/Open (Bank 1) | DTC P2008 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT / OPEN (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2009 | Intake Manifold Runner Control Circuit Low (Bank 1) | DTC P2009 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT LOW (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2011 | Intake Manifold Runner Control Circuit / Open (Bank 2) | DTC P2011 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT/OPEN (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2012 | Intake Manifold Runner Control Circuit Low (Bank 2) | DTC P2012 INTAKE MANIFOLD RUNNER CONTROL CIRCUIT LOW (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2016 | Intake Manifold Runner Position Sensor/Switch Circuit Low (Bank 1) | DTC P2016 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT LOW (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2017 | Intake Manifold Runner Position Sensor/Switch Circuit High (Bank 1) | DTC P2017 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT HIGH (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2021 | Intake Manifold Runner Position Sensor / Switch Circuit Low (Bank 2) | DTC P2021 INTAKE MANIFOLD RUNNER POSITION SENSOR/SWITCH CIRCUIT LOW (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2022 | Intake Manifold Runner Position Sensor/Switch Circuit High (Bank 2) | DTC P2022 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT HIGH (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2088 | Intake Camshaft Position Actuator Control Circuit Low (Bank 1) | DTC P2088 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2089 | Intake Camshaft Position Actuator Control Circuit High (Bank 1) | DTC P2089 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2092 | Intake Camshaft Position Actuator Control Circuit Low (Bank 2) | DTC P2092 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2093 | Intake Camshaft Position Actuator Control Circuit High (Bank 2) | DTC P2093 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2096 | Post Catalyst Fuel Trim System Too Lean Bank 1 | DTC P2096 POST CATALYST FUEL TRIM SYSTEM TOO LEAN BANK 1, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2097 | Post Catalyst Fuel Trim System Too Rich Bank 1 | DTC P2097 POST CATALYST FUEL TRIM SYSTEM TOO RICH BANK 1, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2101 | Throttle Actuator Control Motor Circuit Range/Performance | DTC P2101 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2102 | Throttle Actuator Control Motor Circuit Low | DTC P2102 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2103 | Throttle Actuator Control Motor Circuit High | DTC P2103 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2109 | Throttle/Pedal Position Sensor "A" Minimum Stop Performance | DTC P2109 THROTTLE/PEDAL POSITION SENSOR "A" MINIMUM STOP PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2122 | Throttle/Pedal Position Sensor/Switch "D" Circuit Low Input | DTC P2122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2123 | Throttle/Pedal Position Sensor/Switch "D" Circuit High Input | DTC P2123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2127 | Throttle/Pedal Position Sensor/Switch "E" Circuit Low Input | DTC P2127 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2128 | Throttle/Pedal Position Sensor/Switch "E" Circuit High Input | DTC P2128 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2135 | Throttle/Pedal Position Sensor/Switch "A"/"B" Voltage Correlation | DTC P2135 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A"/"B" VOLTAGE CORRELATION, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2138 | Throttle/Pedal Position Sensor/Switch "D"/"E" Voltage Correlation | DTC P2138 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D"/"E" VOLTAGE CORRELATION, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2419 | Evaporative Emission System Switching Valve Control Circuit Low | DTC P2419 EVAPORATIVE EMISSION SYSTEM SWITCHING VALVE CONTROL CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2420 | Evaporative Emission System Switching Valve Control Circuit High | DTC P2420 EVAPORATIVE EMISSION SYSTEM SWITCHING VALVE CONTROL CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2431 | Secondary Air Injection System Air Flow/Pressure Sensor Circuit Range/Performance | DTC P2431 SECONDARY AIR INJECTION SYSTEM AIR FLOW/PRESSURE SENSOR CIRCUIT RANGE/PERFORMANCE, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2432 | Secondary Air Injection System Air Flow/Pressure Sensor Circuit Low | DTC P2432 SECONDARY AIR INJECTION SYSTEM AIR FLOW/PRESSURE SENSOR CIRCUIT LOW, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2433 | Secondary Air Injection System Air Flow/Pressure Sensor Circuit High | DTC P2433 SECONDARY AIR INJECTION SYSTEM AIR FLOW/PRESSURE SENSOR CIRCUIT HIGH, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2440 | Secondary Air Injection System Switching Valve Stuck Open (Bank 1) | DTC P2440 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE STUCK OPEN (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2441 | Secondary Air Injection System Switching Valve Stuck Closed (Bank 1) | DTC P2441 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE STUCK CLOSED (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2442 | Secondary Air Injection System Switching Valve Stuck Open (Bank 2) | DTC P2442 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE STUCK OPEN (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2443 | Secondary Air Injection System Switching Valve Stuck Closed (Bank 2) | DTC P2443 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE STUCK CLOSED (BANK 2), Diagnostic Trouble Code (DTC) Detecting Criteria. > |
| P2444 | Secondary Air Injection System Pump Stuck On | DTC P2444 SECONDARY AIR INJECTION SYSTEM PUMP STUCK ON, Diagnostic Trouble Code (DTC) Detecting Criteria. > |
DIAGNOSTIC TROUBLE CODE
OUTLINE OF DIAGNOSIS
Detect the AVCS system malfunction.
Judge NG when the amount of AVCS actual timing advance does not approach to the amount of AVCS target timing advance.
Scheme 219
ENABLE CONDITIONS
| Secondary Parameters | Enable Condition |
|---|---|
| Time of establishing all secondary parameter conditions | > or = 3000 ms |
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 1300 rpm |
| Engine coolant temperature | > or = 60°C (140°F) |
| AVCS control | Operation |
| Target timing advance change amount (per 64 ms) | <1.07°CA |
ENABLE CONDITIONS
GENERAL DRIVING CYCLE
Perform the diagnosis continuously after warming up when the engine speed increases and AVCS operates.
DIAGNOSTIC METHOD
- When the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues for certain amount of time.
- When the differences of target timing advance amount and actual timing advance amount is calculated during AVCS control, and the difference per predetermined time is the specified value or larger.
- Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum (Target position - Actual position) | > 8000°CA (AT model) (Bank 1) |
| > 8000°CA (AT model) (Bank 2) | |
| > 5300°CA (MT model) (Bank 1) | |
| > 5300°CA (MT model) (Bank 2) | |
| Or | |
| Sum (Target position - Actual position) | < -8000°CA (AT model) (Bank 1) |
| < -8000°CA (AT model) (Bank 2) | |
| < -5300°CA (MT model) (Bank 1) | |
| < -5300°CA (MT model) (Bank 2) |
JUDGMENT VALUE
Time Needed for Diagnosis
- AT model: 30000 ms
- MT model: 20000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established within the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum (Target position - Actual position) | < or = 8000°CA (AT model) (Bank 1) |
| < or = 8000°CA (AT model) (Bank 2) | |
| < or = 5300°CA (MT model) (Bank 1) | |
| < or = 5300°CA (MT model) (Bank 2) and | |
| > or = -8000°CA (AT model) (Bank 1) | |
| > or = -8000°CA (AT model) (Bank 2) | |
| > or = -5300°CA (MT model) (Bank 1) | |
| < or = -5300°CA (MT model) (Bank 2) |
JUDGMENT VALUE
Time Needed for Diagnosis
- AT model: 30000 ms
- MT model: 20000 ms
DTC CLEAR CONDITION
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
MALFUNCTION INDICATOR LIGHT CLEAR CONDITIONS
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
FAIL SAFE
- Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment from abnormality judgment, and then make the whole learning incomplete.
- Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of the partial learning zone when making a normality judgment --> abnormality judgment.
- AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
- ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Determine the OCV Driving Duty is the given value (9.36%).
ECM OPERATION AT DTC SETTING
Memorize the freeze frame data. (For test mode $02)
Detect the AVCS system malfunction.
Judge as NG when the timing advance is outside the normal range.
Scheme 220
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine speed | > or = 500 rpm |
| Engine coolant temperature | > or = 60°C (140°F) |
| AVCS control | Not in operation |
| Target timing advance | 0°CA |
ENABLE CONDITIONS
Perform the diagnosis continuously after starting engine and while AVCS is not operating.
Judge as NG when the camshaft sensor input position is not within the normal range.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft input position | < BTDC 17°CA (Bank 1) |
| < BTDC 17°CA (Bank 2) | |
| Or | |
| > BTDC 55°CA (Bank 1) | |
| > BTDC 55°CA (Bank 2) |
JUDGMENT VALUE
Time Needed for Diagnosis: 20000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft input position | > or = BTDC 17°CA (Bank 1) |
| > or = BTDC 17°CA (Bank 2) | |
| And | |
| < or = BTDC 55°CA (Bank 1) | |
| < or = BTDC 55°CA (Bank 2) |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment from abnormality judgment, and then make the whole learning incomplete.
- Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of the partial learning zone when making a normality judgment --> abnormality judgment.
- AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
- ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Determine the OCV Driving Duty is the given value (9.36%).
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0016. DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0011. DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect functional errors of the front oxygen (A/F) sensor heater.
Judge as NG when it is determined that the front oxygen (A/F) sensor impedance is large when looking at engine status such as deceleration fuel cut.
Scheme 221
| Secondary Parameters | Enable Condition |
|---|---|
| Condition established time | > or = 42000 ms |
| Battery voltage | > or = 10.9 V |
| Heater current | Permitted |
| Control duty > or = 35 % | Experienced |
| After fuel cut | > or = 20000 ms |
ENABLE CONDITIONS
Perform the diagnosis continuously after 42000 ms seconds or more have passed since the engine started.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | > 50 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | < or = 50 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
- Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 222
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Front oxygen (A/F) sensor heater control duty | < 87.5 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 250 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
- A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
- Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 223
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Front oxygen (A/F) sensor heater control duty | > or = 12.5% |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 500 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
- A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
- Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 224
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after engine starting | > or = 1 second |
| Engine speed | < 8000 rpm |
ENABLE CONDITIONS
After starting the engine, perform the diagnosis continuously when engine is low speed.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Rear oxygen sensor heater control duty | < 75 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms x 320 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Sub feedback control: Not allowed
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 225
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after engine starting | > or = 1 second |
| Engine speed | < 8000 rpm |
ENABLE CONDITIONS
After starting the engine, perform the diagnosis continuously when engine is low speed.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Rear oxygen sensor heater control duty | > or = 25 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms x 320 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Sub feedback control: Not allowed
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect problems in the intake manifold pressure sensor output properties.
Judge as NG when the intake air pressure AD value is Low whereas it seemed to be High from the viewpoint of engine condition, or when it is High whereas it seemed to be Low from the engine condition.
Scheme 226
| Secondary Parameters | Enable Condition |
|---|---|
| Engine coolant temperature | > or = 70°C (158°F) |
ENABLE CONDITIONS
Perform the diagnosis continuously after idling.
- Abnormality Judgment
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2500 rpm |
| Throttle position | > or = 10° |
| Output voltage | < 1 V |
| Engine load | > 1.356 g/rev (0.05 oz/rev) |
| High | |
| Engine speed | 600 rpm - 900 rpm |
| Throttle position | < 2.75° |
| Output voltage | > or = 2.36 V |
| Engine load | < 0.4 g/rev (0.01 oz/rev) |
JUDGMENT VALUE
Time Needed for Diagnosis
Low side: 3000 ms
High side: 3000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when both Low side and High side become OK.
If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2500 rpm |
| Throttle position | > or = 10° |
| Output voltage | > or = 1 V |
| Engine load | > 1.356 g/rev (0.05 oz/rev) |
| High | |
| Engine speed | 600 rpm - 900 rpm |
| Throttle position | < 2.75° |
| Output voltage | < 2.36 V |
| Engine load | < 0.4 g/rev (0.01 oz/rev) |
JUDGMENT VALUE
Time Needed for Diagnosis
Low side: Less than 1 second
High side: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Intake manifold pressure sensor process: Estimate the pressure from engine load.
- ISC feedback: Not allowed to calculate the amount of feedback.
- Heavy fuel judgment: Not allowed to carry out the heavy judgment.
- Fuel cut control: Not allowed to cut the over pressure charged fuel.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of air flow sensor output properties.
Judge as a low side NG when the air flow voltage indicates a small value regardless of running in a state where the air flow voltage increases. Judge as a high side NG when the air flow voltage indicates a large value regardless of running in a state where the air flow voltage decreases. Judge air flow sensor property NG when the Low side or High side becomes NG.
Scheme 227
| Secondary Parameters | Enable Condition |
|---|---|
| Engine coolant temperature | > or = 70°C (158°F) |
ENABLE CONDITIONS
Perform the diagnosis continuously after idling.
- Abnormality Judgment
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | < 1.5 V |
| Engine speed | > or = 2500 rpm |
| Throttle opening angle | > or = 15° |
| Intake manifold pressure | > or = 53.3 kPa (400 mmHg, 15.7 inHg) |
| High (1) | |
| Output voltage | > or = 1.95 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 4.1° |
| Intake manifold pressure | < 52.7 kPa (395 mmHg, 15.6 inHg) |
| High (2) | |
| Output voltage | > or = 1.70 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 4.1° |
| Intake manifold pressure | < 52.7 kPa (395 mmHg, 15.6 inHg) |
| Fuel system diagnosis | Rich side malfunction |
JUDGMENT VALUE
Time Needed for Diagnosis
Low: 3000 ms
High: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when both Low side and High side become OK.
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | > or = 1.5 V |
| Engine speed | > or = 2500 rpm |
| Throttle opening angle | > or = 15° |
| Intake manifold pressure | > or = 53.3 kPa (400 mmHg, 15.7 inHg) |
| High | |
| Output voltage | < 1.95 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 4.1° |
| Intake manifold pressure | < 52.7 kPa (395 mmHg, 15.6 inHg) |
| Fuel system diagnosis | Rich side normal |
JUDGMENT VALUE
Time Needed for Diagnosis
Low: Less than 1 second
High: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuits of the air flow sensor.
Judge as NG if out of specification.
Scheme 228
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < or = 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
- EVAP cone, learning (fuel): Not allowed to learn.
- Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value When normal: Knock compensation value = Fixed at 0°CA Failure: Knock compensation value * Fixed at 0°CA (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed Portional learning zone compensation value calculation not allowed
- ISC control: Open loop compensation is set to (1 g (0.04 oz)/s). Stop calculation of throttle sensor temperature compensation (hold previous value)
- Purge control: Not allowed to purge.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuits of the air flow sensor.
Judge as NG if out of specification.
Scheme 229
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.98 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.98 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
- EVAP cone, learning (fuel): Not allowed to learn.
- Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value When normal: Knock compensation value = Fixed at 0°CA Failure: Knock compensation value * Fixed at 0°CA (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed Portional learning zone compensation value calculation not allowed
- ISC control: Open loop compensation is set to (1 g (0.04 oz)/s). Stop calculation of throttle sensor temperature compensation (hold previous value)
- Purge control: Not allowed to purge.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 230
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < or = 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Intake manifold pressure sensor process: Estimate the pressure from engine load.
- ISC feedback: Not allowed to calculate the amount of feedback.
- Heavy fuel judgment: Not allowed to carry out the heavy judgment.
- Fuel cut control: Not allowed to cut the over pressure charged fuel.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 231
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.596499186 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.596499186 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Intake manifold pressure sensor process: Estimate the pressure from engine load.
- ISC feedback: Not allowed to calculate the amount of feedback.
- Heavy fuel judgment: Not allowed to carry out the heavy judgment.
- Fuel cut control: Not allowed to cut the over pressure charged fuel.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of intake air temperature sensor output property.
Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.
Scheme 232
| Secondary Parameters | Enable Condition |
|---|---|
| Engine coolant temperature at engine starting | < 30°C (86°F) |
| Engine coolant temperature | > or = 95°C (203°F) |
| Battery voltage | > or = 10.9 V |
| Continuous time when the vehicle speed is less than 60 km/h (37.3 MPH) | > or = 600 s |
ENABLE CONDITIONS
Perform the diagnosis when the vehicle speed condition is met after warming up from a cold condition.
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | < 0.02 V(Equivalent to approximately 0.5°C (0.9°F) near 25°C) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | > or = 0.02 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 233
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.230975449 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.230975449 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 234
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 235
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.264738528 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.264738528 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F)
- ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
- ISC learning: Not allowed to learn.
- Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
- Air conditioner control: Not allowed to turn the air conditioner to ON.
- Radiator fan control: Both main and sub fan are in High driving.
- High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
- AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
- Tumble generator valve control: Open the tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 236
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F)
- ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
- ISC learning: Not allowed to learn.
- Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
- Air conditioner control: Not allowed to turn the air conditioner to ON.
- Radiator fan control: Both main and sub fan are in High driving.
- High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
- AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
- Tumble generator valve control: Open the tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 237
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < or = 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 238
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of engine coolant temperature output property.
Judge as NG when the engine coolant temperature does not rise in driving conditions where it should.
Scheme 239
| Secondary Parameters | Enable Condition |
|---|---|
| Engine speed | > or = Value from Map |
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Map
| Engine coolant temperature °C (°F) | 40 (-40) | 30 (-22) | 20 (-4) | 10 (14) | 0 (32) | 10 (50) | 20 (68) | 30 (86) |
|---|---|---|---|---|---|---|---|---|
| Engine speed rpm | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
ENGINE SPEED REFERENCE
| Engine coolant temperature °C (°F) | 40 (104) | 50 (122) | 60 (140) | 70 (158) | 80 (176) | 90 (194) | 100 (212) | 110 (230) |
|---|---|---|---|---|---|---|---|---|
| Engine speed rpm | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
ENGINE SPEED REFERENCE
Perform the diagnosis only once after engine start.
- Abnormality Judgment
Judge as NG if the criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | < 20°C (68 °F) |
| Timer for diagnosis after engine start | > or = Judgment value of timer after engine start |
JUDGMENT VALUE
Timer for diagnosis after engine start
- Timer stop at fuel cut
- During the driving conditions except a) above, timer counts up as follows.
64 milliseconds + TWCNT milliseconds (the time of at 64 milliseconds)
TWCNT is defined as follows
TWCNT = 0 at idle switch ON
TWCNT show on the following table at idle switch OFF.
| Vehicle speed km/h (MPH) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0 (0) | 8 (5) | 16 (9.9) | 24 (14.9) | 32 (19.9) | 40 (24.9) | 48 (29.8) | 56 (34.8) | ||
| Temperature °C (°F) | 20 (-4) | 0 ms | 37.136 ms | 74.272 ms | 111.41 ms | 126.66 ms | 141.91 ms | 163.59 ms | 185.26 ms |
| 10(14) | 0 ms | 27.391 ms | 54.782 ms | 82.173 ms | 99.65 ms | 117.13 ms | 135.96 ms | 154.8 ms | |
| 0 (32) | 0 ms | 17.646 ms | 35.292 ms | 52.938 ms | 72.64 ms | 92.341 ms | 108.34 ms | 124.33 ms | |
| 10 (50) | 0 ms | 7.9012 ms | 15.802 ms | 23.704 ms | 45.63 ms | 67.556 ms | 80.711 ms | 93.867 ms | |
| 20 (68) | 0 ms | 7.9012 ms | 15.802 ms | 23.704 ms | 45.63 ms | 67.556 ms | 80.711 ms | 93.867 ms | |
VEHICLE SPEED REFERENCE
Judgment value of timer after engine starting
t = 451056 ms - 25870 ms x Ti
Ti: The lowest coolant temperature after engine start
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | > or = 20°C (68 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F)
- ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
- ISC learning: Not allowed to learn.
- Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
- Air conditioner control: Not allowed to turn the air conditioner to ON.
- Radiator fan control: Both main and sub fan are in High driving.
- High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
- AVCS Control: Oil flow control solenoid valve drive output duty = 0 %.
- Tumble generator valve control: Open the tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of the engine coolant temperature sensor characteristics.
Memorize the engine coolant temperature and fuel temperature at the last engine stop, and use them to judge as NG when the engine coolant temperature does not decrease when it should.
Scheme 240
ENABLE CONDITION
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Refueling from the last engine stop till the current engine start | None |
| Fuel level | > or = 15 l (3.96 US gal, 3.3 lmp gal) |
| Engine coolant temperature at the last engine stop | > or = 70°C (158°F) |
ENABLE CONDITION
Perform the diagnosis only once after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature at the last engine stop - Minimum engine coolant temperature after the engine start | < 2.5 °C (36.5 °F) |
| Fuel temperature at the last engine stop - Fuel temperature | > or = 5 °C (41 °F) |
| Intake air temperature - Fuel temperature | < 2.5 °C (36.5 °F) |
| Fuel temperature | < 35 °C (95 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature at the last engine stop - Minimum engine coolant temperature after the engine start | > or = 2.5 °C (36.5 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect malfunctions of the thermostat function.
Judge as NG when the engine coolant temperature is lower than the estimated engine coolant temperature and the difference between them is large. Judge as OK when the engine coolant temperature becomes to 75°C (167°F), and the difference is small, before judging NG.
Scheme 241
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Estimate ambient temperature | > or = -7°C (19.4°F) |
| Thermostat malfunction diagnosis | Incomplete |
| Engine coolant temperature at engine starting | < 55 °C (131 °F) |
| Estimated coolant temperature | > or = 70°C (158°F) |
| Engine coolant temperature | < or = 70°C (158°F) |
| (Estimated - measured) Engine coolant temperature | > or = 30°C (86 °F) |
| Vehicle speed | > or = 30km/h (18.6MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 64 ms x 3 time x 152 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Estimate ambient temperature | > or = -7°C (19.4°F) |
| Thermostat malfunction diagnosis | Incomplete |
| Engine coolant temperature at engine starting | < 55°C (131 °F) |
| Engine coolant temperature | > or = 70°C (158°F) |
| (Estimated - measured) Engine coolant temperature | < or = 30°C (86 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 242
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | < 1.128 V |
| Or | |
| Input voltage (-) | < 0.23 V |
| Or | |
| Input voltage (+) - Input voltage (-) | < 0.644 V |
JUDGMENT VALUE
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Input voltage (+) - Input voltage (-)|: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | > or = 1.128 V |
| Input voltage (-) | > or = 0.23 V |
| Input voltage (+) - Input voltage (-) | > or = 0.644 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
- A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
- Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 243
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | > or = 3.589 V |
| Or | |
| Input voltage (-) | > 3.541 V |
JUDGMENT VALUE
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | < or = 3.589 V |
| Input voltage (-) | < or = 3.541 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
- A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
- Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect the slow response of front oxygen (A/F) sensor.
Front oxygen (A/F) sensor cover has some ventilation holes for exhaust gas. Clogged ventilation holes are diagnosed.
When the holes are clogged, the A/F output variation becomes slow comparing with the actual A/F variation because oxygen which reaches the zirconia layer is insufficient. Therefore, if the sensor cover holes are clogged, the rich to lean judgment in the ECM is delayed when the actual change from rich to lean occurs. Judge as NG when the actual movement in comparison to the ECM control amount is slow.
Scheme 244
Scheme 245
| Secondary Parameters | Enable Condition |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 1024 ms |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Closed loop control with main feedback | Operation |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Elapsed time after starting the engine | > or = 120000 ms |
| Engine coolant temperature | > or = 70°C (158°F) |
| Engine speed | 1000 rpm - 3200 rpm |
| Vehicle speed | 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) |
| Amount of intake air | 10g/s - 31 g/s(0.35 oz/s - 1.09 oz/s) |
| Engine load | < 0.02 g/rev (0 oz/rev) |
| Learning value of EVAP cone, during purge | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
ENABLE CONDITIONS
Perform diagnosis only once at a constant speed of 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) 120000 ms or more after starting the engine.
Calculate faf difference every 32ms x 4, and the lambda, value difference. Calculate the diagnosis value after calculating 820 time.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Parafca = td2faf/td2lmd | > 0.644 (AT model) |
| > or = 0.444 (MT model) | |
| Where, td2faf (N) = td2faf (n-1) + |d2faf (n)| td2lmd (N) = td2lmd (n-1) + |d2lmd (n)| add up to 32 ms x 4 x 820 time. d2faf (n) = (faf (n) - faf (n-1)) - (faf (n-1) - faf (n-2)) d2lmd (n) = (lmd (n) - lmd (n-1)) - (lmd (n-1) - lmd(n-2)) faf = main feedback compensation coefficient every 128 milliseconds lmd = output lambda every 128 milliseconds |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms x 4 x 820 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Parafca = td2faf/td2lmd | < or = 0.644 (AT model) |
| < or = 0.444 (MT model) | |
| Where, td2faf (N) = td2faf (n-1) + |d2faf (n)| td2lmd (N) = td2lmd (n-1) + |d2lmd (n)| add up to 32 ms x 4 x 820 time. d2faf (n) = (faf (n) - faf (n-1)) - (faf (n-1) - faf (n-2)) d2lmd (n) = (lmd (n) - lmd (n-1)) - (lmd (n-1) - lmd (n-2)) faf = main feedback compensation coefficient every 128 milliseconds lmd = output lambda every 128 milliseconds |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms x 4 x 820 time
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
- Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect open circuits of the sensor.
Judge as NG when the impedance of the element is large.
Scheme 246
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Time of heater control duty at 70 % or more | > or = 36000 ms |
| Front oxygen (A/F) sensor impedance. | > 500 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 5000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Front oxygen (A/F) sensor impedance. | < or = 500 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
- A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
- Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
- Purge control: Not allowed to purge.
Memorize the freeze frame data. (For test mode $02)
Detect continuity NG of the oxygen sensor. If the oxygen sensor voltage reading is not within the probable range considering the operating conditions, judge as NG.
Scheme 247
Used for abnormality judgment
| Secondary Parameters | Enable Condition |
|---|---|
| High | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 70°C (158°F) |
| Low (1) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 70°C (158°F) |
| Amount of intake air | > or = 10g/s (0.35 oz/s) |
| Low (2) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 70°C (158°F) |
| Amount of intake air | < 10g/s (0.35 oz/s) |
| Current continuation time of the rear oxygen sensor heater | > or = 25000 ms |
| Low (3) | |
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 70°C (158°F) |
| Amount of intake air | < 10g/s(0.35 oz/s) |
| Current continuation time of the rear oxygen sensor heater | > or = 25000 ms |
| Fuel cut | Experienced |
ENABLE CONDITION
Used for normality judgment
| Secondary Parameters | Enable Condition |
|---|---|
| Secondary air system | Not in operation |
| Closed loop control at the oxygen sensor | In operation |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = 70°C (158°F) |
ENABLE CONDITION
After starting the engine, continuously perform the diagnosis with the same engine condition.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | > 1.2 V | |
| Low | P0137 | |
| Sensor output voltage | < 0.03 V |
JUDGMENT VALUE
Time Needed for Diagnosis
High: 2500 ms
Low (1): 20000 ms
Low (2): 150000 ms
Low (3): Value from Map
Map
| Fuel Cut Time (Second) | 0 | 2000 | 10000 |
|---|---|---|---|
| Time needed for diagnosis (second) | 150000 | 150000 | 150000 |
JUDGMENT VALUE
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | < or = 1.2 V | |
| Low | P0137 | |
| Sensor output voltage | > or = 0.03 V |
JUDGMENT VALUE
Time Needed for Diagnosis
High: Less than 1 second
Low (1): Less than 1 second
Low (2): Less than 1 second
Low (3): Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Sub feedback control: Not allowed
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Note. For the detection standard, refer to DTC P0137. DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the slow response of the oxygen sensor.
Judge as NG if either of the rich to lean response diagnosis or lean to rich response diagnosis is NG, and Judge as OK if both are OK.
[Rich --> lean diagnosis response]
- Measure the response time for oxygen sensor output changes when the A/F ratio changes to rich to lean. If the measured response time is larger than the threshold value, it is NG. If it is smaller, it is OK.
- Judge as NG when the oxygen sensor voltage is large (rich) when recovering from a deceleration fuel cut. [Lean --> rich diagnosis response]
- Measure the response time for oxygen sensor output changes when the A/F ratio changes to lean to rich. If the measured response time is larger than the threshold value, it is NG.
- Judge as NG when the oxygen sensor voltage remains small when recovering from a deceleration fuel cut.
Measure the response time of the output change of the oxygen sensor when the A/F ratio changes to rich to lean. And Judge as NG when the measured response time is larger than the threshold value.
Scheme 248
Rich --> lean diagnosis response
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| A/F main feedback control condition | Completed |
| Deceleration fuel cut time is 5000 ms or more. | Experienced |
| After fuel cut | > or = 2000 ms |
| Current calculation time of the rear oxygen sensor heater | > or = 60000 ms |
| Current continuation time of the rear oxygen sensor heater | > or = 30000 ms |
| Estimated catalyst temperature | > or = 400°C (752 °F) |
| Number of deceleration fuel cut | > or = 1 time |
ENABLE CONDITIONS
Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)
When the oxygen sensor output voltage changes from 0.55 V (rich) to 0.15 V (lean), calculate the minimum response time for output change between 0.5 V and 0.2 V for the judgment criteria.
Scheme 249
- Abnormality Judgment
- Judge as NG when the judgment value is larger than the threshold value after deceleration fuel cut. Response time (diagnosis value) > threshold value --> abnormal NOTE: Variation time of rear oxygen sensor output voltage is short during fuel cut in deceleration. NG judgment should be performed after deceleration fuel cut. Even without deceleration fuel cut, judge as OK if the value is below the threshold. When the deceleration fuel cut time is 5000 ms or more, judge as NG if the following criteria are met 2000 ms after recovering from the deceleration fuel cut.
- Judge as NG when the oxygen sensor voltage at recovery from a deceleration fuel cut is large.
If the fuel cut time in a deceleration fuel cut is long (5000 ms or more), and even after recovering from a deceleration fuel cut, the oxygen sensor voltage is high (0.55 V or more), judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from rich (0.5 V O 2 output) to lean (0.2 V) when voltage reduces from 0.55 V to 0.15 V | > 837 ms |
| Or | |
| Longest time over 0.55 V | > or = 2000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
- Regardless of a deceleration fuel cut, if the response time (diagnosis value) when the oxygen sensor voltage has changed from rich to lean is shorter than the threshold value (judgment value), judge as a normal condition. Response time (diagnosis value) < or = threshold value --> normal
- Do not judge as a normal condition.
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from rich (0.5 V O 2 output) to lean (0.2 V) when voltage reduces from 0.55 V to 0.15 V | < or = 837 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Sub feedback control: Not allowed
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Lean --> rich response diagnosis
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| A/F main feedback control condition | Completed |
| Deceleration fuel cut time is 6000 ms or more. | Experienced |
| After fuel cut | > or = 2000 ms |
| Current calculation time of the rear oxygen sensor heater | > or = 0 ms |
| Current continuation time of the rear oxygen sensor heater | > or = 0 ms |
| Estimated catalyst temperature | > or = 0°C (32 °F) |
| Number of deceleration fuel cut | > or = 1 time |
ENABLE CONDITIONS
Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)
When the oxygen sensor output voltage changes from 0.25 V (lean) to 0.55 V (rich), calculate the minimum response time for output change between 0.3 V and 0.5 V for the judgment criteria.
Scheme 250
- Abnormality Judgment
- Judge as NG when the judgment value is larger than the threshold value after deceleration fuel cut. Response time (diagnosis value) > threshold value --> abnormal
- If the oxygen sensor voltage is small after recovering from a deceleration fuel cut, and remains small, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from lean (0.3 V O 2 output) to rich (0.5 V) when voltage changes from 0.25 V to 0.55 V | > 4000 ms |
| Or | |
| Longest time under 0.25 V | > or = 120000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
- Regardless of a deceleration fuel cut, if the response time (diagnosis value) when the oxygen sensor voltage has changed from rich to lean is shorter than the threshold value (judgment value), judge as a normal condition. Response time (diagnosis value) < or = threshold value --> normal
- Do not judge as a normal condition.
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from lean (0.3 V O 2 output) to rich (0.5 V) when voltage changes from 0.25 V to 0.55 V | < or = 4000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Sub feedback control: Not allowed
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect the rear oxygen sensor open or short circuit. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal considering conditions such as intake air amount, engine coolant temperature, main feedback control and deceleration fuel cut.
Scheme 251
ENABLE CONDITION (USED ONLY FOR MALFUNCTION JUDGMENT)
| Secondary Parameters | Enable Condition |
|---|---|
| Closed loop control at the rear oxygen sensor | In operation |
| Target output voltage of rear oxygen sensor | > or = 0.55 V + 0.05 V |
| Amount of intake air | > or = 10g/s (0.35 oz/s) |
| Engine coolant temperature | > or = 70°C (158°F) |
| Misfire detection every 200 rotations | < 5 time |
| Front oxygen (A/F) sensor compensation coefficient | Not in limit value |
| Battery voltage | > or = 10.9 V |
| Deceleration fuel cut of 5000 ms or more. | Experienced |
ENABLE CONDITION
Perform the diagnosis once after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Minimum output voltage | > or = 0.15 V |
| Or | |
| Maximum output voltage | < 0.55 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 200000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Diagnosis of the rear oxygen sensor voltage low side | Incomplete |
| Minimum output voltage | < or = 0.15 V |
| Maximum output voltage | > or = 0.55 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect fuel system malfunction by the amount of main feedback control.
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
| Secondary Parameters | Enable Condition |
|---|---|
| A/F main learning system | In operation |
| Engine coolant temperature | > or = 70°C (158°F) |
| Engine load change | < 0.02 g/rev (0 oz/rev) |
| Engine load | > or = Value of Map 1 |
ENABLE CONDITIONS
Map1
| Engine speed (rpm) | Idling | 800 | 1200 | 1600 | 2000 | 2400 | 2800 | 3200 | 3600 | 4000 | 4400 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Measured value (g(oz)/rev) | Na | 0.228 (0.01) | 0.22 (0.01) | 0.22 (0.01) | 0.22 (0.01) | 0.228 (0.01) | 0.23 (0.01) | 0.234 (0.01) | 0.242 (0.01) | 0.25 (0.01) | 0.25 (0.01) |
ENGINE SPEED REFERENCE
Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.
- Abnormality Judgment
Compare the diagnosed value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time or more, judge that there is a fault in the fuel system.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient every 64 milliseconds flaf = main feedback learning compensation coefficient | > or = Value of Map 2 |
JUDGMENT VALUE
Map2
| Amount of air (g (oz)/s) | 0 (0) | 2.34375 (0.08) | 4.6875 (0.17) | 7.03125 (0.25) | 9.375 (0.33) | 11.7187 5(0.41) | 14.0625 (0.5) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 1.4 | 1.4 | 1.368623 | 1.319185 | 1.26975 | 1.265 | 1.265 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s x 5 time
Malfunction Indicator Light Illumination: illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | < 1.2 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When similar driving conditions are repeated 3 times and the result is OK.
- When "Clear Memory" is performed
Rich side malfunction
- Purge control solenoid valve control: Not allowed to purge.
- Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
Memorize the freeze frame data. (For test mode $02)
Detect fuel system malfunction by the amount of main feedback control.
Diagnostic method
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
| Secondary Parameters | Enable Condition |
|---|---|
| A/F main learning system | In operation |
| Engine coolant temperature | > or = 70°C (158°F) |
| Engine load change | < or = 0.02 g/rev (0 oz/rev) |
| Learning value of EVAP cone. | < 0.1 |
| Cumulative time of canister purge after engine start | > or = 20 s |
| Continuous period after canister purge starting | > or = 29884 ms |
| Engine load | > or = Value of Map 1 |
ENABLE CONDITIONS
Map1
| Engine speed (rpm) | Idling | 800 | 1200 | 1600 | 2000 | 2400 | 2800 | 3200 | 3600 | 4000 | 4400 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Measured value (g(oz)/rev) | Na | 0.228 (0.01) | 0.22 (0.01) | 0.22 (0.01) | 0.22 (0.01) | 0.228 (0.01) | 0.23 (0.01) | 0.234 (0.01) | 0.242 (0.01) | 0.25 (0.01) | 0.25 (0.01) |
ENGINE SPEED REFERENCE
Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.
- Abnormality Judgment
Compare the diagnosed value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time or more, judge that there is a fault in the fuel system.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient every 64 milliseconds flaf = main feedback learning compensation coefficient | < Value of Map 2 |
JUDGMENT VALUE
Map2
| Amount of air (g (cays) | 0 (0) | 2.34375 (0.08) | 4.6875 (0.17) | 7.03125 (0.25) | 9.375 (0.33) | 11.7187 5(0.41) | 14.0625 (0.5) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 0.6 | 0.6 | 0.63137 | 0.68082 | 0.71025 | 0.72525 | 0.73025 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s x 5 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK when the malfunction criteria below continues for 10 seconds.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | > or = 0.8 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When similar driving conditions are repeated 3 times and the result is OK.
- When "Clear Memory" is performed
Rich side malfunction
- Purge control solenoid valve control: Not allowed to purge.
- Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
Memorize the freeze frame data. (For test mode $02)
Detect faults in the fuel temperature sensor output properties.
Diagnosis is performed in two methods (drift diagnosis and stack diagnosis). If either is NG, judge as NG. If both are OK, Judge as OK and clear the NG.
DRIFT DIAGNOSIS
Normally fuel temperature is lower than engine coolant temperature. When the fuel temperature becomes higher than the engine coolant temperature, the range is considered to be shifted, and judged as NG.
STUCK DIAGNOSIS
As the engine warms up (cumulative amount of intake air after starting is large), if the fuel temperature which should rise does not, determine as being stuck and NG.
Scheme 252
DRIFT DIAGNOSIS
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Elapsed time after starting the engine | > or = 20s |
| Engine coolant temperature - Engine coolant temperature at engine start | > or = 10°C (50°F) |
| Fuel temperature - Engine coolant temperature | > or = 10°C (50°F) |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 120 s
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Elapsed time after starting the engine | > or = 20 s |
| Engine coolant temperature - Engine coolant temperature at engine start | > 10°C (50°F) |
| Fuel temperature - Engine coolant temperature | < 10°C (50°F) |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | < 70°C (158°F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
STUCK DIAGNOSIS
| Secondary Parameters | Enable Condition |
|---|---|
| Elapsed time after starting the engine | > or = 20000 ms |
| Battery voltage | > or = 10.9 V |
ENABLE CONDITION
Always perform diagnosis after 20 seconds have passed since the engine started.
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 551043 g (19435.29 oz) |
| Fuel temperature difference between Max. and Min. | < 2 °C (35.6 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel temperature difference between Max. and Min. | > or = 2 °C (35.6 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of fuel temperature sensor.
Judge as NG if out of specification.
Scheme 253
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.343951474 V |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.343951474 V |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of fuel temperature sensor.
Judge as NG if out of specification.
Scheme 254
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 255
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < or = 0.926256 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > 0.926256 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 256
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of fuel pump control unit.
Judge as NG when the NG signal is sent through a diagnostic line coming from the fuel pump control unit. Fuel pump control unit detects the open or short circuit malfunction for each line, and then sends NG signals if one of them is found NG.
Scheme 257
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Elapsed time after starting the engine | > or = 180000 ms |
| Fuel pump control | ON |
| Fuel pump control unit output diagnosis signal | Low |
| Fuel level | > or = 10 l (2.64 US gal, 2.2 lmp gal) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Elapsed time after starting the engine | > or = 180000 ms |
| Fuel pump control | ON |
| Fuel pump control unit output diagnosis signal | High |
| Fuel level | > or = 10 l (2.64 US gal, 2.2 lmp gal) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
OFF setting may be needed depending on the NG portion.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of wastegate control solenoid valve function.
Judge as NG when becoming high wastegate pressure.
Scheme 258
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Intake manifold pressure | > or = Value from Map |
JUDGMENT VALUE
Map
| Barometric pressure (kPa (mmHg, inHg)) | |||||||
|---|---|---|---|---|---|---|---|
| 58.7 (440, 17.3) | 77.3 (580, 22.8) | 89.3 (670, 26.4) | 96 (720, 28.3) | 98.6 (740,29.1) | 101.3 (760, 29.9) | ||
| Engine speed (rpm) | 1000 | 113.4 (851, 33.5) | 132.2 (992, 39.1) | 144 (1080, 42.5) | 144 (1080, 42.5) | 144 (1080, 42.5) | 144 (1080, 42.5) |
| 2000 | 159.8 (1199, 47.2) | 188.6 (1415, 55.7) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | |
| 3000 | 159.8 (1199, 47.2) | 188.6 (1415, 55.7) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | |
| 4000 | 159.8 (1199, 47.2) | 188.6 (1415, 55.7) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | 206.6 (1550, 61) | |
| 5000 | 133.4 (1001, 39.4) | 160.1 (1201, 47.3) | 179.7 (1348, 53.1) | 186.9 (1402, 55.2) | 204.6 (1535, 60.4) | 204.6 (1535, 60.4) | |
| 6000 | 123.4 (926, 36.5) | 147.7 (1108, 43.6) | 165.4 (1241, 48.9) | 171.8 (1289, 50.7) | 188 (1410, 55.5) | 188 (1410, 55.5) | |
| KPa (mmHg, inHg) | |||||||
ENGINE SPEED REFERENCE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Intake manifold pressure | < Value from Map - 22.4 kPa (168 mmHg, 6.6 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the wastegate control solenoid valve.
Judge as NG when the terminal output voltage remains Low during outputting the duty signal.
Scheme 259
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | Low |
| Duty ratio of wastegate control | < 75% |
JUDGMENT VALUE
Time Needed for Diagnosis: 640 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the wastegate control solenoid valve.
Judge as NG when the terminal output voltage remains Low or High during outputting the duty signal.
Scheme 260
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | High |
| Duty ratio of wastegate control | > or = 25% |
JUDGMENT VALUE
Time Needed for Diagnosis: 640 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the presence of misfire occurrence. (Revolution fluctuation method)
Monitoring Misfire which influences exhaust deterioration (1.5 times of FTP) and catalyst damage is made obligatory by the law. Misfire affecting these two has two patterns below.
- Intermittent misfire (The same cylinder misfires in random, or different cylinders misfire in random.): FTP 1.5 times misfire
- Every time misfire (The same cylinder misfires every time.): FTP 1.5 times misfire, Catalyst damage misfire
The following detecting methods are adopted for these detection.
- Intermittent misfire: FTP 1.5 times misfire 180° Interval Difference Method (MT: 1,800 rpm or less, AT: None) 360° Interval Difference Method (whole range) 720° Interval Difference Method (3,000 rpm or more)
- Misfire every time: FTP 1.5 times misfire, Catalyst damage misfire
- 360° Interval Difference Method
| Secondary Parameters | Enable Condition |
|---|---|
| All secondary parameters enable conditions | > or = 1024 ms |
| Intake manifold pressure change at 180°CA | < Value of Map 1 |
| Throttle position change during 16 milliseconds | < 14° |
| Fuel shut-off function | Not in operation |
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Vehicle dynamic control or AT torque control | Not in operation |
| Evaporative system leak check | Not in operation |
| Engine speed | 500 rpm - 6650 rpm |
| Intake manifold pressure | > or = Value of Map 2 |
| Battery voltage | > or = 8 V |
| Fuel parameter determination | Not extremely low volatility |
| Elapsed time after starting the engine | > or = 0 ms |
| Engine load change during 32 milliseconds | < 1000 rpm |
ENABLE CONDITIONS
Map1
- AT model
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) |
ENGINE SPEED REFERENCE
- MT model
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) | 13.3 (100, 3.9) |
ENGINE SPEED REFERENCE
Map2
- AT model (Tumble generator valve open)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 29.3 (220, 8.7) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 27.3 (205, 8.1) | 28 (210, 8.3) | 29.5 (221.5, 8.7) | 31.3 (235, 9.3) | 32.7 (245.5, 9.7) | 34.1 (256, 10.1) | 38.2 (286.5, 11.3) | 44 (330, 13) | 49.5 (371.5, 14.6) | 53.3 (400, 15.7) |
ENGINE SPEED REFERENCE
- AT model (Tumble generator valve closed)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 29.3 (220, 8.7) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 26.7 (200, 7.9) | 27.3 (205, 8.1) | 28 (210, 8.3) | 29.5 (221.5, 8.7) | 31.3 (235, 9.3) | 32.7 (245.5, 9.7) | 34.1 (256, 10.1) | 38.2 (286.5, 11.3) | 44 (330, 13) | 49.5 (371.5, 14.6) | 53.3 (400, 15.7) |
ENGINE SPEED REFERENCE
- MT model (Tumble generator valve open)
Vehicle speed < 64 km/h (39.8 MPH)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 27.3 (205, 8.1) | 23.3 (175, 6.9) | 23.6 (177, 7) | 23.3 (175, 6.9) | 24 (180, 7.1) | 24.4 (183, 7.2) | 28.8 (216, 8.5) | 30 (225, 8.9) | 31.6 (237, 9.3) | 32.5 (244, 9.6) | 37.1 (278, 10.9) | 41.9 (314, 12.4) | 46.9 (352, 13.9) | 51.1 (383, 15.1) |
ENGINE SPEED REFERENCE
Vehicle speed > or = 68 km/h (42.3 MPH)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 25.1 (188, 7.4) | 24.8 (186, 7.3) | 25.6 (192, 7.6) | 40 (300, 11.8) | 40.8 (306, 12) | 42.1 (316, 12.4) | 44 (330, 13) | 44.5 (334, 13.1) | 47.3 (355, 14) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) |
VEHICLE SPEED REFERENCE
- MT model (Tumble generator valve closed)
Vehicle speed < 64 km/h (39.8 MPH)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 27.3 (205, 8.1) | 23.3 (175, 6.9) | 23.6 (177, 7) | 23.3 (175, 6.9) | 24 (180, 7.1) | 24.4 (183, 7.2) | 28.8 (216, 8.5) | 30 (225, 8.9) | 31.6 (237, 9.3) | 32.5 (244, 9.6) | 37.1 (278, 10.9) | 41.9 (314, 12.4) | 46.9 (352, 13.9) | 51.1 (383, 15.1) |
VEHICLE SPEED REFERENCE
Vehicle speed > or = 68 km/h (42.3 MPH)
| Rpm | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 | 6700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KPa (mmHg, inHg) | 25.1 (188, 7.4) | 24.8 (186, 7.3) | 25.6 (192, 7.6) | 40 (300, 11.8) | 40.8 (306, 12) | 42.1 (316, 12.4) | 44 (330, 13) | 44.5 (334, 13.1) | 47.3 (355, 14) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) | 54.7 (410, 16.1) |
VEHICLE SPEED REFERENCE
- If conditions are met, it is possible to detect the misfires from idling to high engine speed. However, in case any engine load or breakage occurs, perform with the engine at idle.
- Perform the diagnosis continuously.
When a misfire occurs, the engine speed will decreased and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgment value. Count the number of misfires. If the misfire ratio is higher during 1000 revs, or 200 revs., judge corresponding cylinders as NG.
| Diagnostic value calculation (Calculate from crankshaft position speed) | > | Misfire detection every single ignition (Compare diagnostic value with judgment value) | > | NG judgment (Misfire occurrence judgment required by the law) (Compare number of misfire with judgment) |
|---|---|---|---|---|
| 180° Interval Difference Method 360° Interval Difference Method 720° Interval Difference Method | FTP 1.5 times misfire NG judgment Catalyst damage misfire NG judgment |
VALUE CALCULATION REFERENCE
As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.
Scheme 261
180° Interval Difference Method
| Diagnostic value | Domg 180 = (omg 1 - omg 0) - (omg 5 - omg 1 )/4 |
|---|---|
| Judge as a misfire in the following cases. domg 180 > judgment value of positive side domg 180 < or = judgment value of negative side (Judgment value before 180°CA) | |
THRESHOLD VALUE POSITION REFERENCE
Scheme 262
360° Interval Difference Method
| Diagnostic value | Domg 360 = (omg 1 - omg 0) - (omg 3 - omg 2) |
|---|---|
| Misfire judgment | Domg 360 > Judgment value --> Judge as misfire |
THRESHOLD VALUE POSITION REFERENCE
Scheme 263
720° Interval Difference Method
| Diagnostic value | Domg 720 = (omg 1 - omg 0) - (omg 5 - omg 4) |
|---|---|
| Misfire judgment | Domg 720 > Judgment value --> Judge as misfire |
THRESHOLD VALUE POSITION REFERENCE
Scheme 264
- FTP 1.5 times misfire (Misfire occurrence level which influences exhaust gas)
- Abnormality Judgment
Judgment Value (Judge that malfunction occurs when the misfire ratio is high in 1000 engine revs.)
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission judgment value | > or = 20 x 100/2000% in 1000 revs. |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission judgment value | < 20 x 100/2000% in 1000 revs. |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 engine revs.
- Catalyst damage misfire (Misfire occurrence level damaging catalyst)
- Abnormality Judgment
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire judgment value | > or = Value from Map 3 |
JUDGMENT VALUE
Map 3
| Intake air (g(oz)/rev) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.2 (0.01) | 0.4 (0.01) | 0.6 (0.02) | 0.8 (0.03) | 1 (0.04) | 1.2(0.04) | 1.4 (0.05) | 1.6 (0.06) | 1.8 (0.06) | 2 (0.07) | ||
| Engine speed (rpm) | 700 | 148 | 128 | 116 | 106 | 100 | 90 | 90 | 90 | 90 | 90 |
| 1000 | 148 | 128 | 114 | 104 | 92 | 85 | 85 | 85 | 85 | 85 | |
| 1500 | 140 | 118 | 102 | 90 | 85 | 85 | 85 | 72 | 72 | 72 | |
| 2000 | 128 | 90 | 90 | 73 | 58 | 43 | 40 | 36 | 32 | 20 | |
| 2500 | 116 | 87 | 57 | 45 | 39 | 36 | 34 | 32 | 30 | 20 | |
| 3000 | 108 | 87 | 58 | 39 | 36 | 36 | 32 | 30 | 28 | 20 | |
| 3500 | 98 | 74 | 43 | 27 | 23 | 22 | 20 | 20 | 20 | 20 | |
| 4000 | 69 | 61 | 40 | 27 | 22 | 20 | 20 | 20 | 20 | 20 | |
| 4500 | 60 | 55 | 34 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 5000 | 55 | 55 | 34 | 23 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 5500 | 54 | 54 | 33 | 22 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 6000 | 52 | 52 | 32 | 21 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 6500 | 50 | 50 | 30 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 6700 | 50 | 50 | 30 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
ENGINE SPEED REFERENCE
Time Needed for Diagnosis: 200 engine revs.
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire judgment value | < Value from Map 3 |
JUDGMENT VALUE
Time Needed for Diagnosis: 200 engine revs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When similar driving conditions are repeated 3 times and the result is OK.
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Note. For the detection standard, refer to DTC P0301. DTC P0301 CYLINDER 1 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0301. DTC P0301 CYLINDER 1 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0301. DTC P0301 CYLINDER 1 MISFIRE DETECTED, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 265
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.243 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.243 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Knock compensation
- Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value
- When normal: Knock compensation value = Fixed at 0°CA
- Failure: Knock compensation value = -5°CA (5°CA retard)
- Whole learning compensation coefficient update not allowed
- Portional learning zone compensation value calculation not allowed
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 266
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.709 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.709 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Knock compensation
- Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value
- When normal: Knock compensation value = Fixed at 0°CA
- Failure: Knock compensation value = -5°CA (5°CA retard)
- Whole learning compensation coefficient update not allowed
- Portional learning zone compensation value calculation not allowed
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the crankshaft position sensor.
Judge as NG when the crank signal is not input even though the starter was rotated.
Scheme 267
Scheme 268
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter switch | ON |
| Crankshaft position sensor signal | Not detected |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position sensor signal | Input exists |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect for faults in crankshaft position sensor output properties.
Judge as NG when there is a problem in the number of crankshaft signals for every revolution.
Scheme 269
Scheme 270
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 8 V |
| Engine speed | < 3000 rpm |
ENABLE CONDITIONS
Perform the diagnosis continuously under 3000 rpm engine speed.
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev. | Not = 30 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 engine revs.
Malfunction indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev. | = 30 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the camshaft position sensor.
Judge as NG when the number of camshaft signals remains abnormal.
Scheme 271
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 8 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment 1
Judge as NG when the condition where the number of camshaft position sensor signals are less than 3 time during 2 engine revs, continues.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Amount of camshaft sensor signal during 2 revs. | < 3 time |
JUDGMENT VALUE
Time Needed for Diagnosis: Engine two revolutions x 50
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement 1
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | > or = 3 time |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revolutions
- Abnormality Judgment 2
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter | ON |
| Camshaft position sensor signal | No input |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
- Normality Judgement 2
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | Input exists |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment from abnormality judgment, and then make the whole learning incomplete.
- Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of the partial learning zone when making a normality judgment --> abnormality judgment.
- AVCS control
- Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
- ISC feedback compensation: Do not perform the AVCS actual timing advance compensation.
- Make the OCV driving Duty to be the given value (9.36%).
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0340. DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect NG judging from secondary air delivery pipe pressure, pulse of secondary air delivery pipe pressure and secondary air pipe airflow amount.
| Secondary Parameters | Enable Condition |
|---|---|
| Pump supply pressure check | |
| Estimate ambient temperature | > or = 4.4 °C |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine | In operation |
| Amount of intake air | > or = 2 g/s (0.07 oz/s) |
| Secondary air pump | Operating |
| Combination valve | Bank open (Except with both banks closed) |
| Combination valve one side closed pulse diagnosis | |
| Estimate ambient temperature | > or = 4.4 °C |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine | In operation |
| Feasible area for diagnosis | Value of Map 10 > or = 1 |
| After fuel cut | > or = 0 ms |
| Combination valve both closed pulse diagnosis | |
| Estimate ambient temperature | > or = 4.4 °C |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine | In operation |
| Engine load | > or = 0.2 g/rev (0.01 oz/rev) |
| After fuel cut | > or = 1000 ms |
| Combination valve changeover pressure diagnosis | |
| Estimate ambient temperature | > or = 4.4 °C |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine | In operation |
| Amount of intake air | > 2 g/s (0.07 oz/s) and < 25 g/s (0.88 oz/s) |
| Engine speed | < 4000 rpm |
| After fuel cut | > or = 1000 ms |
| Overflow diagnosis Estimate ambient temperature | > or = 4.4 °C |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine | In operation |
ENABLE CONDITIONS
Perform diagnosis during secondary air pump operation
Measure secondary air delivery pipe pressure, pulse of secondary air delivery pipe pressure and secondary air pipe airflow amount.
Scheme 272
Pump supply pressure check
Perform the system function diagnosis with how much the pressure rises when the secondary air pump is turned from OFF to ON.
Judge as NG if delivery pipe pressure does not rise though it should when the secondary air pump turns OFF --> ON.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Secondary air supply pipe pressure (after barometric pressure compensation) | < 0.9 kPa (7 mmHg, 0.3 inHg) | P0410 |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms + 2800 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Secondary air supply pipe pressure (after barometric pressure compensation) | > or = 0.9 kPa (7 mmHg, 0.3 inHg) | P0410 |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms + 2800 ms
Combination valve one side closed pulse diagnosis
Perform close stuck diagnosis of the LH combination valve using delivery pipe pressure pulse when the RH combination valve is closed.
Calculate the voltage pulse of the pump delivery pipe pressure when the RH combination valve is closed and the LH combination valve is open. The calculation of delivery pipe pressure should be large when the LH combination valve is open. Judge that the LH combination valve is close stuck if the calculation is small.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculated value when the RH combination valve is closed | < Value of Map 1 | P2443 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculated value when the RH combination valve is closed | > or = Value of Map 1 | P2443 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Perform close stuck diagnosis of the RH combination valve using delivery pipe pressure pulse when the LH combination valve is closed.
Calculate the voltage pulse of the pump delivery pipe pressure when the LH combination valve is closed and the RH combination valve is open. The calculation of delivery pipe pressure should be large when the RH combination valve is open. Judge that the RH combination valve is close stuck if the calculation is small.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculated value when the LH combination valve is closed | < Value of Map 2 | P2441 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculated value when the LH combination valve is closed | > or = Value of Map 2 | P2441 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Combination valve both closed pulse diagnosis
Perform open stuck diagnosis of both combination valves using delivery pipe pressure pulse when both combination valves are closed. Determine which side of valves is stuck open by comparing secondary air flow amount when RH combination valve is closed with that when LH combination valve is closed.
Calculate voltage pulse of the pump supply pipe pressure when both combination valves are closed. The calculation should be small because there is no pulse from supply pipe pressure with both combination valves closed. When the calculation is large, determine that either of the combination valves is stuck open. Determine which side of valves is stuck open by comparing secondary air flow amount when the RH combination valve is closed with that when the LH combination valve is closed. Air flow amount is larger on the open stuck valve.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculation value when both combination valves are closed | > Value from Map 3 | P2440 |
| Air flow amount when the right bank is closed (value from Map 4) | > or = Air flow amount when the left bank is closed (value from Map 5) | |
| Pulse calculation value when both combination valves are closed | > Value from Map 3 | P2442 |
| Air flow amount when the left bank is closed (value from Map 5) | > Air flow amount when the right bank is closed (value from Map 4) |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pulse calculation value when both combination valves are closed | < or = Value from Map 3 | P2440, P2442 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Combination valve changeover pressure diagnosis
Perform the RH combination valve stuck closed diagnosis with the variation of delivery pipe pressure when the RH combination valve turns closed --> open.
Delivery pipe pressure should vary when the RH combination valve turns closed --> open. When the variation is small, determine that the RH combination valve is stuck closed.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pressure variation value when the RH combination valve is switched | < Value of Map 6 | P2441 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pressure variation value when the RH combination valve is switched | > or = Value of Map 6 | P2441 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Perform the LH combination valve stuck closed diagnosis with the variation of delivery pipe pressure when the LH combination valve turns open --> closed.
Delivery pipe pressure should vary when the LH combination valve turns open --> closed. When the variation is small, determine that the LH combination valve is stuck closed.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pressure variation value when the LH combination valve is switched | < Value of Map 7 | P2443 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Pressure variation value when the LH combination valve is switched | > or = Value of Map 7 | P2443 |
JUDGMENT VALUE
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Overflow diagnosis
Perform secondary air system flow abnormality diagnosis using both sides of combination valves secondary air amount when both are closed.
Judge as secondary air system flow abnormality either if there is excessive secondary air flow amount with the RH combination valve closed, or if there is excessive secondary airflow amount with the LH combination valve closed.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Air flow amount when the right bank is closed (value from Map 4) | > Value of Map 8 | P0411 |
| Or | ||
| Air flow amount when the left bank is closed (value from Map 5) | > Value of Map 9 | |
| Voltage at P0RL measurement - Voltage at P0R measurement | < or = 4 V | |
| Voltage at P0RL measurement - Voltage at P0L measurement | < or = 4 V |
JUDGMENT VALUE
P0RL: Both banks all closed pressure
P0R: Right bank all closed pressure
P0L: Left bank all closed pressure
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Air flow amount when the right bank is closed (value from Map 4) | < or = Value of Map 8 | P0411 |
| Or | ||
| Air flow amount when the left bank is closed (value from Map 5) | < or = Value of Map 9 | |
| Voltage at P0RL measurement - Voltage at P0R measurement | < or = 4 V | |
| Voltage at P0RL measurement - Voltage at P0L measurement | < or = 4 V |
JUDGMENT VALUE
P0RL: Both banks all closed pressure
P0R: Right bank all closed pressure
P0L: Left bank all closed pressure
Time Needed for Diagnosis: 4000 ms + 992 ms + 992 ms + 992 ms
Map1
| Amount of intake air (g (oz)/s) Engine speed (rpm) | 0(0) | 60 (2.12) |
|---|---|---|
| 0 | 0 | 0 |
| 10000 | 0 | 0 |
| (V) | ||
ENGINE SPEED REFERENCE
Map2
| Amount of intake air (g (oz)/s) Engine speed (rpm) | 0 (0) | 60 (2.12) |
|---|---|---|
| 0 | 0 | 0 |
| 10000 | 0 | 0 |
| (V) | ||
ENGINE SPEED REFERENCE
Map 3
| Intake air (g (oz)/rev) | 0.1 (0) | 0.25 (0.01) | 0.3 (0.01) | 1 (0.04) |
|---|---|---|---|---|
| Threshold value (V) | 13 | 13 | 3.25 | 3.25 |
THRESHOLD VALUE REFERENCE
Map4
| Secondary air pressure in the pipe when both comb, valve is closing kPa (mmHg, inHg) Secondary air pressure in the pipe when LH comb, valve is closing kPa (mmHg, inHg) | 69.3 (520, 20.5) | 74.6 (560, 22) | 80 (600, 23.6) | 85.3 (640, 25.2) | 90.6 (680, 26.8) | 96 (720, 28.3) | 101.3 (760, 29.9) | 106.6 (800, 31.5) | 112 (840, 33.1) | 117.3 (880, 34.6) | 122.6 (920, 36.2) | 128 (960, 37.8) | 133.3 (1000, 39.4) | 138.6 (1040, 40.9) | 144 (1080, 42.5) | 149.3 (1120, 44.1) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 69.3 (520, 20.5) | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 | 2400 | 2400 |
| 74.6 (560, 22) | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 | 2400 |
| 80 (600, 23.6) | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 |
| 85.3 (640, 25.2) | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 |
| 90.6 (680, 26.8) | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 |
| 96 (720, 28.3) | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 |
| 101.3 (760, 29.9) | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 |
| 106.6 (800,31.5) | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 |
| 112 (840,33.1) | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 |
| 117.3 (880, 34.6) | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 |
| 122.6 (920, 36.2) | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 |
| 128 (960, 37.8) | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 |
| 133.3 (1000,39.4) | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 |
| 138.6 (1040,40.9) | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 |
| 144 (1080,42.5) | 2400 | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 |
| 149.3 (1120,44.1) | 2400 | 2400 | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 |
| (L/min) | ||||||||||||||||
AIR PRESSURE SPECIFICATION
Map 5
| Secondary air pressure in the pipe when both comb, valve is closing kPa (mmHg, inHg) Secondary air pressure in the pipe when RH comb, valve is closing kPa (mmHg, inHg) | 69.3 (520, 20.5) | 74.6 (560, 22) | 80 (600, 23.6) | 85.3 (640, 25.2) | 90.6 (680, 26.8) | 96 (720, 28.3) | 101.3 (760, 29.9) | 106.6 (800, 31.5) | 112 (840, 33.1) | 117.3 (880, 34.6) | 122.6 (920, 36.2) | 128 (960, 37.8) | 133.3 (1000, 39.4) | 138.6 (1040, 40.9) | 144 (1080, 42.5) | 149.3 (1120, 44.1) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 69.3 (520, 20.5) | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 | 2400 | 2400 |
| 74.6 (560, 22) | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 | 2400 |
| 80 (600, 23.6) | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | 2400 |
| 85.3 (640, 25.2) | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 |
| 90.6 (680, 26.8) | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 |
| 96 (720, 28.3) | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 |
| 101.3 (760, 29.9) | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 |
| 106.6 (800,31.5) | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 |
| 112 (840,33.1) | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 |
| 117.3 (880, 34.6) | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 | 1200 |
| 122.6 (920, 36.2) | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 | 1000 |
| 128 (960, 37.8) | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 | 800 |
| 133.3 (1000,39.4) | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 | 600 |
| 138.6 (1040,40.9) | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 | 400 |
| 144 (1080,42.5) | 2400 | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 | 200 |
| 149.3 (1120,44.1) | 2400 | 2400 | 2400 | 2400 | 2200 | 2000 | 1800 | 1600 | 1400 | 1200 | 1000 | 800 | 600 | 400 | 200 | 0 |
| (L/min) | ||||||||||||||||
AIR PRESSURE SPECIFICATION
Map6
| Amount of intake air when RH comb, valve switches (g (oz)/s) Battery voltage when RH comb, valve switches (V) | 10 (0.35) | 15 (0.53) | 20 (0.71) | 25 (0.88) | 26 (0.92) |
|---|---|---|---|---|---|
| 11 | 0.025 | 0.025 | 0.025 | 0.005 | 0 |
| 12 | 0.035 | 0.035 | 0.035 | 0.015 | 0 |
| 13 | 0.05 | 0.05 | 0.05 | 0.025 | 0 |
| 14 | 0.05 | 0.05 | 0.05 | 0.025 | 0 |
| (V) | |||||
AIR PRESSURE SPECIFICATION
Map7
| Amount of intake air when LH comb, valve switches (g (oz)/s) Battery voltage when LH comb, valve switches (V) | 10 (0.35) | 15 (0.53) | 20 (0.71) | 25 (0.88) | 26 (0.92) |
|---|---|---|---|---|---|
| 11 | 0.025 | 0.025 | 0.025 | 0.005 | 0 |
| 12 | 0.035 | 0.035 | 0.035 | 0.015 | 0 |
| 13 | 0.05 | 0.05 | 0.05 | 0.025 | 0 |
| 14 | 0.05 | 0.05 | 0.05 | 0.025 | 0 |
| (V) | |||||
AIR PRESSURE SPECIFICATION
Map 8
| Amount of intake air when P0R is measuring (g (oz)/s) Battery voltage when P0R measuring (V) | 2 (0.07) | 25 (0.88) |
|---|---|---|
| 11.5 | 345 | 345 |
| 12.5 | 345 | 345 |
| 13.5 | 345 | 345 |
| 14.5 | 390 | 390 |
| 15.5 | 420 | 420 |
| (L/min) | ||
AIR PRESSURE SPECIFICATION
Map 9
| Amount of intake air when P0L is measuring (g (oz)/s) Battery voltage when P0L measuring (V) | 2 (0.07) | 25 (0.88) |
|---|---|---|
| 11.5 | 345 | 345 |
| 12.5 | 345 | 345 |
| 13.5 | 345 | 345 |
| 14.5 | 390 | 390 |
| 15.5 | 420 | 420 |
| (L/min) | ||
AIR PRESSURE SPECIFICATION
Map 10
| Amount of intake air (g (oz)/s) Engine speed (rpm) | 0 (0) | 60 (2.12) |
|---|---|---|
| 500 | 0 | 0 |
| 5000 | 0 | 0 |
AIR PRESSURE SPECIFICATION
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Note. For the detection standard, refer to DTC P0410. DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs OFF signal | LOW |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs OFF signal | HIGH |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs ON signal | HIGH |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs ON signal | LOW |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0413. DTC P0413 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "A" CIRCUIT OPEN, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0414. DTC P0414 SECONDARY AIR INJECTION SYSTEM SWITCHING VALVE "A" CIRCUIT SHORTED, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs OFF signal | LOW |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs OFF signal | HIGH |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the deterioration of the catalyst function.
Though the front oxygen sensor output would change slowly with a new catalyst, the sensor output with a deteriorated catalyst becomes high and the inversion time is shortened.
For this reason, the catalyst diagnosis is carried out by monitoring the front oxygen sensor output and comparing it with the front oxygen (A/F) sensor output.
Scheme 273
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Engine coolant temperature | > or = 70°C (158°F) |
| Estimated catalyst temperature | > or = 500°C (932 °F) |
| Misfire detection every 200 rotations | < 5 time |
| Learning value of evaporation gas density | < 0.2 |
| Sub feedback | In operation |
| Evaporative system diagnosis | Not in operation |
| Time of difference (< 0.10) between actual lambda and target lambda | > or = 1000 ms |
| Vehicle speed | > 60 km/h (37.3 MPH) |
| Amount of intake air | > or = 10g/s (0.35oz/s) and < 50g/s (1.76 oz/s) |
| Engine load change every 0.5 engine revs. | < 0.02 g/rev (0 oz/rev) |
| Rear oxygen output change from 660 mV or less to 660 mV or more | Experienced after fuel cut |
| Elapsed time after starting the engine | > or = 200s |
| Purge execution calculated time | > or = 5 s |
ENABLE CONDITIONS
Perform the diagnosis only once at a constant 60 km/h (37.3 MPH) or higher.
After establishing the execution conditions, calculate the front oxygen (A/F) sensor lambda deviation cumulative value per 32 milliseconds x 4 (Sum |(sglmd n - sglmd n-1 )|) and rear oxygen sensor output voltage deviation cumulative value (Sum |(ro2sad n - ro2sad n-1 )|), and when the front oxygen (A/F) sensor lambda deviation cumulative value (Sum |(sglmd n - sglmd n-1 )|) becomes the predetermined value or more, calculate the diagnostic value.
- Abnormality Judgment
If the duration of time while the following conditions are met is within the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum |(ro2sad n - ro2sad n-1 )| /Sum |(sglmd n - sglmd n-1 ) | > 11 |
JUDGMENT VALUE
Time Needed for Diagnosis: 30 - 55 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is within the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum |(ro2sad n - ro2sad n-1 )| /Sum |(sglmd n - sglmd n-1 ) | < or = 11 |
JUDGMENT VALUE
Time Needed for Diagnosis: 30 - 55 seconds
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Note. For the detection standard, refer to DTC P0442. DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Check if there is a leakage in fuel system or not, and perform the function diagnosis of valve.
Scheme 274
In this system diagnosis, check for leakage and valve function is conducted by changing the fuel tank pressure and monitoring the pressure change using the fuel tank pressure sensor. When in 0.04 inch diagnosis, perform in the order of mode Z --> mode A --> mode B --> mode C and mode D; When in 0.02 inch diagnosis, perform in the order of mode A --> mode B --> mode C --> mode D and mode E.
0.04-inch Diagnosis
Scheme 275
| Mode | Mode Description | Diagnosis Period |
|---|---|---|
| Mode Z (Purge control solenoid valve opening failure diagnosis) | Perform purge control solenoid valve opening failure diagnosis from the size of tank pressure variation from diagnosis start. | 0 ms + 3000 ms - 0 ms + 3000 ms + 13000 ms |
| Mode A (Estimated evaporation amount) | Calculate the tank pressure change amount (P1). | 10000 ms |
| Mode B (Sealed negative pressure, large leakage judgment) | Decrease the pressure in the tank to the target value by introducing the intake manifold pressure to the fuel tank. If the tank pressure cannot be reduced, it is diagnosed as large leak. | 0-10000 ms + 25000 ms |
| Mode C (Pressure increase check, advanced OK judgment) | Wait until the tank pressure returns to the target (start level of P2 calculation). If the tank pressure does not become the value, make advanced OK judgment. | 0 - 18600 ms |
| Mode D (Negative pressure variation measurement, evaporation leakage diagnosis) | Calculate the tank pressure variation (P2), and obtain the diagnostic value using P1 found in Mode A. Perform the evaporation diagnosis using the diagnostic value. | 0 ms +10000 ms |
MODE DESCRIPTION
Mode Table for Evaporative Emission Control System Diagnosis
| Mode | Behavior of tank internal pressure under normal conditions | Diagnostic item | DTC |
|---|---|---|---|
| Mode Z | Roughly the same as barometric pressure (Same as 0 kPa (0 mmHg, 0 inHg)) | Purge control solenoid valve is judged to be open. | P0457 |
| Mode A | Pressure is in proportion to amount of evaporative emission. | None | |
| Mode B | Negative pressure is formed due to intake manifold negative pressure | Large leak | P0457 |
| Mode C | Reaches target pressure | None | |
| Mode D | Pressure change is small. | EVAP system large leak determination [1.0 mm (0.04 in)] | P0442 |
DTC CHART
0.02-inch Diagnosis
Scheme 276
| Mode | Mode Description | Diagnosis Period |
|---|---|---|
| Mode A (0 point compensation) | When the pressure in the tank is not near 0 mmHg, wait until it returns to 0 point (near 0 mmHg). | 0 - Value of Map 1 |
| Mode B (Negative pressure introduced) | Decrease the pressure in the tank to the target value by introducing the intake manifold pressure to the fuel tank. | 0 - Value of Map 2 |
| Mode C (Negative pressure maintained) | Wait until the tank pressure returns to the target (start level of P2 calculation). | 0 - 22820 ms + 0 + Value from Map 2 |
| Mode D (Negative pressure change calculated) | Calculate the time it takes for the tank pressure to change to the Mode E shifting pressure. If the tank pressure does not change to the Mode E shifting pressure, make advanced OK judgment. | 0 - 0 ms + 200000 ms |
| Mode E (Evaporation generated amount calculation) | Calculate the amount of evaporation (P1). | 0 - 0 ms + 200000 ms + Value from Map 3 |
MODE DESCRIPTION
Map1
| Fuel level ( l , US gal, lmp gal) | 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57,8.8 | 50, 13.21,11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 13800 | 13800 | 11400 | 9000 | 7000 | 5000 | 5000 |
FUEL LEVEL REFERENCE
Map2
| Fuel level ( l , US gal, lmp gal) | 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50, 13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 19520 | 19520 | 19850 | 20180 | 19975 | 19770 | 19770 |
FUEL LEVEL REFERENCE
Map 3
| Fuel level ( l , US gal, lmp gal) | 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50,13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 80000 | 80000 | 70000 | 60000 | 60000 | 60000 | 60000 |
FUEL LEVEL REFERENCE
COMPONENT DESCRIPTION
Pressure control solenoid valve
PCV controls the fuel tank pressure to be equal to the atmospheric air pressure. Normally, the solenoid is set to OFF. The valve opens and closes mechanically in accordance with the pressure difference between tank and atmospheric air, or tank and canister.
The valve is forcibly opened by setting the solenoid to ON at the time of diagnosis.
Scheme 277
Valve Operation and Air Flow
In the figure below, divided by the diaphragm, the part above X is charged with atmospheric air pressure, and the part below X is charged with tank pressure. Also, the part above Y is charged with tank pressure, and the part below Y is charged with canister pressure.
If the atmospheric air pressure port is A, tank pressure port is B, and canister pressure port is C, the air flows according to pressure difference from each port as shown in the table below.
Scheme 278
| Condition of pressure | Flow |
|---|---|
| A < B (solenoid OFF) | B --> C |
| B < C (solenoid OFF) | C --> B |
| Solenoid ON | B <-- --> C |
CONDITION OF PRESSURE
When A < B (solenoid OFF)
Scheme 279
When B < C (solenoid OFF)
Scheme 280
When Solenoid is ON
Scheme 281
Drain valve
Drain valve controls the ambient air to be introduced to the canister.
Scheme 282
0.04-inch Diagnosis
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Total time of canister purge operation | > or = 120000 ms |
| Elapsed time after starting the engine | > or = 856 s |
| Learning value of evaporation gas density | <0.08 |
| Engine speed | 1050 rpm - 6500 rpm |
| Fuel tank pressure | > or = -4 kPa (-30 mmHg, -1.2 inHg) |
| Intake manifold relative vacuum (relative pressure) | > or = - 13.3 kPa (- 100 mmHg, - 3.9 inHg) |
| Vehicle speed | > or = 32km/h (19.9 MPH) |
| Fuel level | 9.6 l (2.54 US gal, 2.11 lmp gal) - 54.4 l (14.37 US gal, 11.97 lmp gal) |
| Closed air/fuel ratio control | In operation |
| Fuel temperature | 10°C (14 °F) - 45 °C (113 °F) |
| Intake air temperature | > or = -10°C (14°F) |
| Pressure change every one second | < 1.7 mmHg (Mode A) < 1.7 mmHg (Mode D) |
| Minimum pressure change value every one second - Maximum pressure change value every one second | < 1.7 mmHg (Mode A) < 1.7 mmHg (Mode D) |
| Change of fuel level per 128 milliseconds | < 3 l (0.79 US gal, 0.66 lmp gal) |
| Air fuel ratio | 0.76 - 1.25 |
ENABLE CONDITIONS
0.02-inch Diagnosis
| Secondary Parameters | Enable Condition |
|---|---|
| At starting a diagnosis | |
| Evap. diagnosis | Incomplete |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Time since last incomplete 0.02-inch leakage diagnosis When cancelling in mode A | > 120000 ms |
| When cancelling in other than mode A | > 600000 ms |
| Total time of canister purge operation | > or = 120000 ms |
| Elapsed time after starting the engine | > or = 120 s |
| Fuel temperature | 10°C (14 °F) - 55 °C (131 °F) |
| Fuel level | 9.6 l (2.54 US gal, 2.11 lmp gal) - 54.4 l (14.37 US gal, 11.97 lmp gal) |
| Intake manifold relative vacuum (relative pressure) | > or = - 13.3 kPa (- 100 mmHg, - 3.9 inHg) |
| Fuel tank pressure | 0.7 kPa (-5 mmHg, -0.2 inHg) - 1.4 kPa (10.7 mmHg, 0.4 inHg) |
| Vehicle speed | 50 km/h (31.1 MPH) - 510 km/h (316.9 MPH) continues for 125000 ms |
| Closed air/fuel ratio control | In operation |
| Engine speed | 1050 rpm - 6000 rpm |
| During diagnosis | |
| Change of fuel level | < or = Value of Map 4 |
| Pressure change every one second | < 0.1 kPa (0.44 mmHg, 0 inHg) |
| Minimum pressure change value every one second - Maximum pressure change value every one second | < 0.1 kPa (0.51 mmHg, 0 inHg) (Mode D) |
| Pressure change in tank every second | < or = 0.1 kPa (0.75 mmHg, 0 inHg) |
| Barometric pressure change | 0.5 kPa (-3.6 mmhg, -0.1 inHg) - 0.3 kPa (2.4 mmhg, 0.1 inHg) (Mode D) |
| 0.3 kPa (-2.4 mmhg, -0.1 inHg) - 0.3 kPa (2.4 mmhg, 0.1 inHg) (Mode E) |
ENABLE CONDITION
Map4
| Fuel level ( l , US gal, lmp gal) | 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50, 13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Change ( l , US gal, lmp gal) | 5, 1.32, 1.1 | 5, 1.32, 1.1 | 5, 1.32, 1.1 | 5, 1.32, 1.1 | 5, 1.32, 1.1 | 5, 1.32, 1.1 | 5, 1.32, 1.1 |
FUEL LEVEL REFERENCE
0.04-inch Diagnosis
- Perform the diagnosis only once in 856 seconds or more after starting the engine, at a constant speed of 32 km/h (20 MPH) or more.
- Pay attention to the fuel temperature and fuel level.
0.02-inch Diagnosis
- Perform the diagnosis 125 seconds or more at a constant engine speed of 50 km/h (31 MPH) or higher to judge as NG or OK.
- If judgment cannot be made, repeat the diagnosis.
- Pay attention to the fuel level.
Purge control solenoid valve stuck open fault diagnosis
DTC
P0457 Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)
Purpose of Mode Z
When performing the leakage diagnosis of EVAP system, the purge control solenoid valve must operate normally. Therefore, mode Z is used to diagnose the purge control solenoid valve stuck open condition. Note that if a purge control solenoid valve stuck open fault is detected, the EVAP system leakage diagnosis is cancelled.
DIAGNOSTIC METHOD
Purge control solenoid valve functional diagnosis is performed by monitoring the tank pressure in mode Z.
- Abnormality Judgment
If OK judgment cannot be made, extend Mode Z, and Judge as NG when the following conditions are established after predetermined amount of time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Evptez - evptezha | > 0.9 kPa (6.5 mmHg, 0.3 inHg) | P0457 |
| Evptezini | < or = 1.4 kPa (10.7 mmHg, 0.4 inHg) | |
| Time of 2 l (0.53 US gal, 0.44 lmp gal) or more fuel no sloshing | > or = 40000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 0 ms + 3000 ms + 13000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
When judgment for purge control solenoid valve stuck open NG is made, end the evaporative diagnosis. Cancel the evaporative diagnosis when the OK/NG judgment for purge control solenoid valve stuck open cannot be made in Mode Z.
- Normality Judgment
Judge as OK and change to Mode A when the following conditions are established after predetermined time has passed since Mode Z started.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Evptez - evptezha | < or = 0.4 kPa (3 mmHg, 0.1 inHg) | P0457 |
JUDGMENT VALUE
Normal
Scheme 283
evptez - evptezha < or = 0.4 kPa (3 mmHg, 0.1 inHg) Normal when above is established
Time Needed for Diagnosis: 0 ms + 3000 ms
Purge control solenoid valve Open Fixation
Scheme 284
- evptezini < or = 1.4 kPa (10.7 mmHg, 0.4 inHg)
- evptez - evptezha > 0.9 kPa (6.5 mmHg, 0.3 inHg)
- No fuel sloshing of over 2 l (0.53 US gal, 0.44 lmp gal) lasts for more than 40000 ms.
Judge as abnormal when all are established.
Leak Diagnosis
DTC
P0441 Evaporative emission system incorrect purge flow
P0442 Evaporative Emission Control System Leak Detected (Small Leak)
P0457 Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)
- The diagnostic consists of creating a sealed vacuum in the fuel tank and then determining the presence of leakage from the speed at which the tank internal pressure returns to barometric pressure.
- The diagnosis is divided into the following five phases.
Mode A: (Estimated evaporation gas amount)
Calculate the tank pressure change amount (P1) when using mode A. After calculating P1, switch to mode B.
Mode B: (Negative pressure sealed)
Introduce negative pressure in the intake manifold to the tank.
Approx. 0 --> -1.4 kPa (0 --> -10.5 mmHg, 0 --> -0.4 inHg)
When the pressure above (desired negative pressure) is reached, enters Mode C.
In this case, if the tank pressure does not reach the target negative pressure, judge that there is a large leakage in the system and terminate the evaporative emission control system diagnosis.
Abnormality Judgment
Judge as NG (large leakage) when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Time to reach target negative pressure | > or = 10000 ms + 25000 ms | P0457 |
| Or | ||
| Mode B time | > or = 10000 ms | |
| (Min. pressure value in tank when in mode B) - (Tank pressure when mode B started) | > -0.3 kPa (-2.5 mmHg, -0.1 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 0 ms + 3000 ms + 10000 ms + 10000 ms + 25000 ms
Mode C: (Check pressure rise)
Stop the introduction of negative pressure. (Wait until the tank pressure returns to the start level of P2 calculation.)
Change to Mode D when the tank pressure returns to the start level of P2 calculation.
Judge immediate OK and change to Mode E when it does not return in spite of spending the specified time.
| Tank pressure when starting calculation of P2 | Time for advanced OK judgment |
|---|---|
| 1.4 kPa (-10.5 mmHg, -0.4 inHg) | 18600 ms |
TANK PRESSURE SPECIFICATION
Time Needed for Diagnosis: 0 ms + 3000 ms + 10000 ms + 10000 ms + 25000 ms + 18600 ms
Mode D: (Measure amount of negative pressure change)
Monitor the tank pressure change amount when using mode D. In this case, the tank pressure increases, (nears barometric pressure) because evaporation occurs. However, if any leakage exists, the pressure increases additionally in proportion to this leakage. The pressure variation of this tank is P2.
After calculating P2, perform a small leak diagnosis according to the items below.
When Mode D is ended
Assign tank variations measured in Mode A and Mode D, P1 and P2, to the formula below, judge small leaks in the system. If the measured judgment value exceeds the threshold value, it is judged to be a malfunction.
Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
Judge as OK and clear the NG if the following conditions are not established within the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| P2 - 1.5 - x P1 | > or = Value of Map 5 | P0442 |
| P2: Tank pressure that changes every 10000 ms in mode D | ||
| P1: Tank pressure that changes every 10000 ms in mode A |
JUDGMENT VALUE
*1.5 -: Evaporation amount compensation value when below negative pressure (Amount of evaporation occurrence increases as a vacuum condition increases.)
Map 5 Malfunction criteria limit for evaporation diagnosis
Map 5 Malfunction criteria limit for evaporation diagnosis
| Fuel temperature vs. Fuel level | 25 °C (77 °F) | 30°C (86 °F) | 35 °C (95 °F) | 40°C (104°F) | 45°C (113°F) |
|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0.3 kPa (2.1 mmHg, 0.1 inHg) | 0.3 kPa (2.2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.35 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0.3 kPa (2.1 mmHg, 0.1 inHg) | 0.3 kPa (2.2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.35 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) |
| 20 l (5.28 US gal, 4.4 Imp gal) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.6 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 30 l (7.93 US gal, 6.6 lmp gal) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (3.05 mmHg, 0.1 inHg) | 0.4 kPa (3.15 mmHg, 0.1 inHg) | 0.4 kPa (3.25 mmHg, 0.1 inHg) | 0.4 kPa (3.35 mmHg, 0.1 inHg) |
| 40 l (10.57 US gal, 8.8 Imp gal) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (3.15 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 Imp gal) | 0.4 kPa (3.2 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.5 kPa (3.6 mmHg, 0.1 inHg) | 0.5 kPa (3.7 mmHg, 0.1 inHg) |
| 60 l (15.85 US gal, 13.2 Imp gal) | 0.4 kPa (3.2 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.5 kPa (3.6 mmHg, 0.1 inHg) | 0.5 kPa (3.7 mmHg, 0.1 inHg) |
FUEL TEMPERATURE SPECIFICATION
Purge control solenoid valve 2 stuck close diagnosis
Perform purge control solenoid valve 2 stuck close diagnosis using the variation gap between the tank pressure at the end of mode C and after mode C.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Elapsed time after completion of mode C advanced OK judgement | = 3500 ms | P0441 |
| Tank pressure variation after completion of mode C advanced OK judgement | < 0.758 mmHg |
DTC CHART
Time Needed for Diagnosis: 0 ms + 3000 ms + 10000 ms + 10000 ms + 25000 ms + 18600 ms + 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Leak Diagnosis
DTC
P0456 Evaporative Emission Control System Leak Detected (very small leak)
- The diagnostic consists of creating a sealed vacuum in the fuel tank and then determining the presence of leakage from the speed at which the tank internal pressure returns to barometric pressure.
- The diagnosis is divided into the following five phases.
Mode A: (0 point compensation)
When the pressure in the tank is not near 0 mmHg, wait until it returns to 0 point (near 0 mmHg). Shift to mode B when returned to the 0 point. Cancel the diagnosis when 0 point does not return in the specified time.
Mode B: (Negative pressure introduced)
Introduce negative pressure in the intake manifold to the tank.
Approx. 0 --> -2 kPa (0 --> -15 mmHg, 0 --> -0.6 inHg)
When the pressure above (desired negative pressure) is reached, enters Mode C.
When the tank internal pressure does not reach the target negative pressure, the diagnosis is cancelled.
Mode C: (Negative pressure maintained)
Stop the introduction of negative pressure. (Wait until the tank pressure returns to the start level of P2 calculation.)
Change to Mode D either when the tank pressure returns to the start level of P2 calculation, or when the predetermined amount of time has passed.
Mode D: (Calculate the amount of negative pressure change)
Monitor the tank pressure in mode D, calculate the pressure change in the tank (P2), and measure the time (evpdset) for the tank pressure to change to the Mode E shifting pressure. When the Mode E shifting pressure is reached, Mode E is entered. If it does not change to the Mode E shifting pressure after the predetermined amount of time has passed, make advanced OK judgment or cancel the diagnosis according to the value of P2.
Normality Judgment
Judge as OK when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Advanced OK judgment 1 | |
| Mode D time | > or = 0ms + 10000 ms |
| Tank internal pressure | < or = Value of Map 6 |
| Advanced OK judgment 2 | |
| Mode D time | > or = 0 ms + 200000 ms |
| P2 | < or = Value of Map 7 |
JUDGMENT VALUE
Map6
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50, 13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Tank pressure (kPa, mmHg, inHgl) | 1.9, -14.62, -0.6 | 1.9, -14.62, -0.6 | 1.9, -14.59, -0.6 | 1.9, -14.56, -0.6 | 1.9, -14.42, -0.6 | 1.9, -14.28, -0.6 | 1.9, -14.28, -0.6 |
FUEL LEVEL REFERENCE
Map7
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50, 13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Tank pressure (kPa, mmHg, inHgl) | 0.9, 7, 0.3 | 0.9, 7, 0.3 | 0.9, 7.05, 0.3 | 0.9, 7.1,0.3 | 1.1, 8.2, 0.3 | 1.3, 9.6, 0.4 | 1.3, 9.6, 0.4 |
FUEL LEVEL REFERENCE
Mode E: (Evaporation occurrence amount calculation)
Calculate the change of tank pressure with the time evpdset (P1) to judge as NG/OK according to the value of P1. (ambiguous determination acceptable).
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| P1 | < Value of Map 8 |
JUDGMENT VALUE
Map 8 Malfunction criteria limit for evaporation diagnosis
| Time (evpdset) vs. Fuel level | 0 ms | 30000 ms | 50000 ms | 100000 ms | 160000 ms | 200000 ms |
|---|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 20 l (5.28 US gal, 4.4 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 30 l (7.93 US gal, 6.6 Imp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 40 l (10.57 US gal, 8.8 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.85 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.3 kPa (2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0 kPa (0 mmHg, 0 inHg) |
| 60 l (15.85 US gal, 13.2 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.3 kPa (2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0 kPa (0 mmHg, 0 inHg) |
FUEL LEVEL REFERENCE
Time Needed for Diagnosis: Value of Map1+ Value of Map2 + 22820 ms + 0 + Value of Map2 + 0 ms + 200000 ms + Value of Map3 + 0 ms + 200000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| P1 | > Value of Map 9 |
JUDGMENT VALUE
Map 9 Malfunction criteria limit for evaporation diagnosis
| Time (evpdset) vs. Fuel level | 0 ms | 30000 ms | 50000 ms | 100000 ms | 160000 ms | 200000 ms |
|---|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) |
| 20 l (5.28 US gal, 4.4 Imp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.4 kPa (3.25 mmHg, 0.1 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) |
| 30 l (7.93 US gal, 6.6 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.4 kPa (3 mmHg, 0.1 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) |
| 40 l (10.57 US gal, 8.8 Imp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.3 kPa (2.25 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.2 kPa (1.5 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) |
| 60 l (15.85 US gal, 13.2 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.2 kPa (1.5 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) |
FUEL LEVEL REFERENCE
Time Needed for Diagnosis: Value of Map1+ Value of Map2 + 22820 ms + 0 + Value of Map2 + 0 ms + 200000 ms + Value of Map3 + 0 ms + 200000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect open or short circuit of the drain valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 285
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Pressure control solenoid valve control: Open the pressure control solenoid valve.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the drain valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 286
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Pressure control solenoid valve control: Open the pressure control solenoid valve.
Memorize the freeze frame data. (For test mode $02)
Detect the tank pressure sensor output property abnormality.
Judge as NG when there is no pressure variation, which should exist in the tank, considering the engine status.
Scheme 287
| Secondary Parameters | Enable Condition |
|---|---|
| Elapsed time after starting the engine | > or = 60 s |
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Fuel temperature | < 35 °C (95 °F) |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
ENABLE CONDITIONS
- Perform the diagnosis continuously after 60 s have passed since the engine started.
- Pay attention to the fuel level and temperature.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Number of times that the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is 2 l (0.53 US gal, 0.44 lmp gal) or more (with enable condition established) | > or = 16 time |
| Maximum - Minimum tank pressure (with enable condition completed) | < 0 kPa (0.375 mmHg, 0 inHg) |
| Maximum - Minimum fuel temperature (with enable condition completed) | > or = 7 °C (44.6 °F) |
JUDGMENT VALUE
If the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is less than 2 l (0.53 US gal, 0.44 lmp gal), extend 60 s and make judgment with the Max. and Min. values for the fuel level in 60 s x 2. If a difference does not appear, extend the time (60 s x 3,60 s x 4,60 s x 5) and continue the judgment. If the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is 2 l (0.53 US gal, 0.44 lmp gal) or more, the diagnosis counter counts up.
Time Needed for Diagnosis: 60 s x 16 time or more
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Maximum - Minimum tank pressure | > or = 0 kPa (0.375 mmHg, 0 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Purge control solenoid valve control: Purge fixed mode is prohibited.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the fuel tank pressure sensor.
Judge as NG if out of specification.
Scheme 288
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < -7.5 kPa (-55.9 mmHg, -2.2 inHg) |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 15000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > or = -7.5 kPa (-55.9 mmHg, -2.2 inHg) |
| Battery voltage | > or = 10.9 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Purge control solenoid valve control: Purge fixed mode is prohibited.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of the fuel tank pressure sensor.
Judge as NG if out of specification.
Scheme 289
| Secondary Parameters | Enable Condition |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 5000 ms |
| Vehicle speed | > or = 2km/h (1.2 MPH) |
| All conditions of EVAP canister purge | Completed |
| Learning value of evaporation gas concentration (left and right) | < 0.08 |
| Main feedback compensation coefficient (left and right) | > or = 0.9 |
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Perform the diagnosis when purging enable conditions are met without idling.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > or = 7.9 kPa (59.6 mmHg, 2.3 inHg) |
| Fuel temperature | < 35 °C (95 °F) |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 15000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < 7.9 kPa (59.6 mmHg, 2.3 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Purge control solenoid valve control: Purge fixed mode is prohibited.
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0442. DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0442. DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 290
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | < 0.75 |
| Terminal output voltage | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 291
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
ENABLE CONDITION
Always perform the diagnosis after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | > or = 0.25 |
| Terminal output voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect malfunctions of the fuel level sensor output property.
If the fuel level does not vary in a particular driving condition / engine condition where it should, judge as NG.
Scheme 292
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 330957 g (11672.85 oz) |
| Max. - min. values of fuel level output | < 2.6 l (0.69 US gal, 0.57 lmp gal) |
| Battery voltage | > or = 10.9 V |
| Engine speed | < 6500 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 330957 g (11672.85 oz) |
| Max. - min. values of fuel level output | > or = 2.6 l (0.69 US gal, 0.57 lmp gal) |
| Battery voltage | > or = 10.9 V |
| Engine speed | < 6500 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 293
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 0.173 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | > or = 0.173 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 294
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | > or = 7.212 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 7.212 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the unstable output faults from the fuel level sensor caused by noise. Judge as NG when the max. value and cumulative value of output voltage variation of the fuel level sensor is larger than the threshold value.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine speed | > or = 500 rpm |
| Elapsed time after starting the engine | > or = 1 second |
| Battery voltage | > or = 10.9 V |
| Idle switch | ON |
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) and < 54.4 l (14.37 US gal, 11.97 lmp gal) |
| Vehicle speed = 0 km/h (0 MPH) | > or = 10000 ms |
ENABLE CONDITION
- Always perform the diagnosis continuously at idle speed.
- Pay attention to the fuel level.
Calculate the Max. value (DELFLMAX) and cumulative value (SUMFL) of output voltage variation of fuel level sensor during 12.2 seconds. Judge it normal when both max. and cumulative values are not over the threshold value. Otherwise, when either of them is over the threshold value, the diagnosis counter counts up. Judge as NG if the counter indicated 4 time.
Scheme 295
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Integrated times of the condition reaching follows | > or = 4 time |
| DELFLMAX | > or = Value from Map |
| Or | |
| SUMFL | > or = 25.92 V |
| At this time, DELFLMAX: Maximum difference of sensor output for 12288 ms SUMFL: Integrated value of the sensor output deviation for 12288 ms |
JUDGMENT VALUE
Map
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50, 13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Measured voltage (V) | 0.27 | 0.27 | 0.426 | 0.582 | 0.738 | 0.894 | 0.894 |
FUEL LEVEL REFERENCE
The diagnosis counter does not count up when the following conditions are completed within 12288 ms.
| Maximum value - minimum value of change of tank pressure during 12288 ms | > or = 0 kPa (0.375 mmHg, 0 inHg) |
|---|---|
| Maximum value - minimum value of battery voltage during 12288 ms | > or = 0.969 V |
TANK PRESSURE SPECIFICATION
Time Needed for Diagnosis: 12288 ms x 4 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| DELFLMAX | < Value from Map |
| SUMFL | < 25.92 V |
| At this time, DELFLMAX: Maximum difference of sensor output for 12288 ms SUMFL: Integrated value of the sensor output deviation for 12288 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 12288 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG when outside of the judgment value.
Judge NG when the received data from ABSCM&H/U is abnormal vehicle speed, and the vehicle speed data is impossible.
Vehicle speed signals are taken in to the ABS control module and hydraulic control unit, and normal/erroneous data of the ABS wheel speed sensor is received by CAN communication from the ABS control module and hydraulic control unit.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after engine starting | > or = 2000 ms |
ENABLE CONDITION
Always perform diagnosis more than 2000 ms after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front ABS wheel speed sensor status | Malfunction |
| Either of the following is established | |
| Front left wheel speed | > or = 300 km/h (186.4 MPH) |
| Front right wheel speed | > or = 300 km/h (186.4 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 512 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front left wheel speed | > 0 km/h (0 MPH) and |
| < 300 km/h (186.4 MPH) | |
| Front right wheel speed | > 0 km/h (0 MPH) and |
| < 300 km/h (186.4 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 512 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Accelerator sensor signal process: Not allowed full closed point learning (hold the previous value)
- ABS wheel speed sensor signal process: Vehicle speed = 10 km/h (6 MPH)
- Fuel cut control: Not allowed vehicle speed 0 km/h (0 MPH) fuel cut. Normally the high vehicle speed fuel cut performs on vehicle speed condition and engine speed, but perform the fuel cut only on engine speed condition (4400 rpm or more).
- ISC control: Open loop compensation is set to (1 g (0.04 oz) oz/s) Not allowed ISC feedback volume calculation.
- Air conditioner control: Not allowed air conditioner cut at accelerating.
- Radiator fan control: Both main and sub fan ON drive
- Gear ratio judgment: Gear = Control as fixed in sixth gear
- Tumble generator valve control: Open the tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of starter SW.
Judge as ON NG when the starter SW signal remains ON.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine condition | After engine starting |
| Starter OFF signal | Not detected |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 180000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter OFF signal | Detected |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
| DTC | Item | Outline of diagnosis |
|---|---|---|
| P0513 | Incorrect Immobilizer Key | Incorrect immobilizer key (Use of unregistered key in body integrated unit) |
| P1570 | Antenna | Faulty antenna |
| P1571 | Reference Code Incompatibility | Reference code incompatibility between body integrated unit and ECM |
| P1572 | IMM Circuit Failure (Except Antenna Circuit) | Communication failure between body integrated unit and ECM |
| P1574 | Key Communication Failure | Failure of body integrated unit to verify key (transponder) ID code or transponder failure |
| P1576 | EGI Control Module EEPROM | ECM malfunctioning |
| P1577 | IMM Control Module EEPROM | Body integrated unit malfunctioning |
| P1578 | Meter Failure | Reference code incompatibility between body integrated unit and combination meter |
DTC CHART
When starting the engine.
Perform the diagnosis only after starting the engine.
Judge as NG when the conditions for the outline of the diagnosis of the top are established.
Detect malfunction of CAN communication.
When CAN communications is not possible, and CAN communications with AT is not possible, judge as NG if data from the AT is not normal.
ECM and TCM are connected by high speed CAN.
(Common Specifications)
CAN Protocol 2.0 B (Active)
Frame Format: 11 Bit ID Frame (Standard Frame)
(High speed CAN)
Conforms to IS011898
Communication Speed: 500 kbps
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Perform the diagnosis continuously after starting the engine.
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Bus off flag or error warning flag | Set (error) |
| Or | |
| ID received from body integrated unit, TCM, ABSCM or VDCCM | None during 500 milliseconds |
| Or | |
| Data updated from body integrated unit, TCM, ABSCM or VDCCM | None during 500 milliseconds |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Bus off flag or error warning flag | Clear (No error) |
| ID received from body integrated unit, TCM, ABSCM and VDCCM | Yes |
| Data updated from body integrated unit, TCM, ABSCM and VDCCM | Yes |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Accelerator pedal position sensor request target throttle opening angle calculation: AT protecting torque guard is usually obtained by CAN communication. It is specified as 408 N.m (42 kgf-m, 301 ft-lb).
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of microcomputer (RAM).
When there is a problem in the main CPU normal RAM, or the sub CPU normal RAM, judge as NG. Judge as OK when both are operating properly.
If it is possible to write data to the whole area of RAM in the initial routine, and is possible to read the same data, it is judged as OK, and if not, NG.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Diagnosis with the initial routine.
Perform the diagnosis as soon as the ignition switch is turned to ON.
Abnormality Judgment
Judge as NG if the criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Main CPU normal RAM abnormal | |
| Write 5AA5A55A and then read. (Whole area of RAM) | 5AA5A55A cannot be read. |
| Write A55A5AA5 and then read. (Whole area of RAM) | A55A5AA5 cannot be read. |
| Sub CPU normal RAM abnormal | |
| Write 5AA5 and then read. (Whole area of RAM) | 5AA5 cannot be read. |
| Write A55A and then read. (Whole area of RAM) | A55A cannot be read. |
JUDGMENT VALUE
Time Needed for Diagnosis: Undetermined
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Main CPU normal RAM abnormal | |
| Write 5AA5A55A and then read. (Whole area of RAM) | 5AA5A55A can be read. |
| And write A55A5AA5 and then read. (Whole area of RAM) | A55A5AA5 can be read. |
| Sub CPU normal RAM abnormal | |
| Write 5AA5 and then read. (Whole area of RAM) | 5AA5 can be read. |
| And write A55A and then read. (Whole area of RAM) | A55A can be read. |
JUDGMENT VALUE
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG when SUM value of ROM is outside the standard value.
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
ENABLE CONDITION
Always perform the diagnosis continuously.
Abnormality Judgment
Judge as NG if the criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| SUM value of ROM | Standard |
JUDGMENT VALUE
Time Needed for Diagnosis: Undetermined
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when any one of the followings is established.
- When the read value of throttle position sensor 1 signal is mismatched between main CPU and sub CPU.
- When the read value of accelerator pedal position sensor 1 signal is mismatched between main CPU and sub CPU.
- When the sub CPU operates abnormally.
- When the communication between main CPU <--> sub CPU is abnormal.
- When the input amplifier circuit of throttle position sensor 1 is abnormal.
- When the cruise control cannot be canceled correctly.
- When the signal of brake SW1 and 2 is mismatched.
Scheme 296
| Secondary Parameters | Enable Conditions |
|---|---|
| (1) Ignition switch | ON |
| (2) Ignition switch | ON |
| (3) None | |
| (4) None | |
| (5) Throttle opening angle | |
| (6) Brake switch (only with cruise control) | ON |
| (7) None |
ENABLE CONDITION
- (4): Always perform the diagnosis continuously.
- (5): Always perform the diagnosis continuously when idling.
- (6): Perform the diagnosis when the brake pedal is depressed.
- (7): Always perform the diagnosis continuously.
- (8): Always perform the diagnosis continuously when the cruise control pedal is not operating.
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| (1) Difference of CPU reading value of the throttle position sensor signal | < or = 0.0858 V |
| (2) Difference of CPU read value of the accelerator pedal position sensor signal | < or = 0.35 V |
| (3) WD pulse from sub CPU | WD pulse occur |
| (4) Communication between CPU | Possible to communicate |
| (5) |Throttle position sensor 1 opening angle - (Throttle position sensor 1 opening angle after passing amplifier) 1/4 | < 3° |
| (6) Cruise control cancel signal at brake ON | Cruise control cancel signal ON |
| (7) Brake switch 1, 2 signal | SW 1 and 2 are matched |
JUDGMENT VALUE
Time Needed for Diagnosis
- 600 milliseconds
- 830 milliseconds
- 200 milliseconds
- 200 milliseconds
- 24 milliseconds
- 250 milliseconds
- 200 milliseconds
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the target opening angle and actual opening angle is mismatched or the current to motor is the specified duty or more for specified time continuously.
Scheme 297
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON |
| Normal operation of electric throttle control | ON |
ENABLE CONDITIONS
Always perform the diagnosis continuously when the electric throttle control is operating.
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Difference between target opening angle and actual opening angle | 3.5° or less |
| Output duty to drive circuit | 95% or less |
JUDGMENT VALUE
Time Needed for Diagnosis
- Target opening angle and actual opening angle: 250 milliseconds (For NG) 2000 milliseconds (For OK)
- Output duty to drive circuit: 2000 milliseconds
Details of Judgment Value
Scheme 298
Details of Judgment time (The actual opening angle < or = target opening angle is always 1000 milliseconds)
Scheme 299
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when there is CAN communication with the AT and there is a MIL lighting request.
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | Yes |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | None |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of neutral SW.
Judge as NG when the neutral terminal input in ECM differs from the received data from TCM.
| Secondary Parameters | Enable Conditions |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITION
Perform the diagnosis continuously after two seconds have passed since the engine started.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF and when the other switches are "ON" | LOW (ON) |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF and when the other switches are "ON" | HIGH (OFF) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge the open or short circuit of the neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITIONS
Perform the diagnosis continuously in 2 seconds after starting the engine.
- Abnormality Judgment
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | LOW (ON) continues. |
| Driving condition change Engine speed 600 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 900 rpm & Vehicle speed > 0 km/h (0 MPH) | From a) to b) |
JUDGMENT VALUE
Time Needed for Diagnosis: 3 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear NG when there is change in the neutral SW.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to HIGH (OFF). |
| Driving condition change Engine speed 600 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 900 rpm & Vehicle speed > 0 km/h (0 MPH) | From a) to b) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Cruise control: Not allowed to command cruise control.
Memorize the freeze frame data. (For test mode $02)
Judge the open or short circuit of the neutral SW.
Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITIONS
Perform the diagnosis continuously in 2 seconds after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | HIGH (OFF) |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | LOW (ON) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge the open or short circuit of the neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Starter relay | OFF |
ENABLE CONDITIONS
Perform the diagnosis continuously in 2 seconds after starting the engine.
- Abnormality Judgment
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | HIGH (OFF) continues. |
| Driving condition change Engine speed 600 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 900 rpm & Vehicle speed > or = 0 km/h (0 MPH) | From a) to b) |
JUDGMENT VALUE
Time Needed for Diagnosis: 3 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear NG when there is change in the neutral SW.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to LOW (ON). |
| Driving condition change Engine speed 600 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 900 rpm & Vehicle speed > or = 0 km/h (0 MPH) | From a) to b) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect that lambda value remains low.
Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio |
|---|
| Lambda > 1: Lean |
| Lambda < 1: Rich |
AIR FUEL RATIO REFERENCE
Scheme 300
| Secondary Parameters | Enable Condition |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 4096 ms |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Rear oxygen sensor sub feedback | Execution |
| Rear oxygen sensor output voltage - Feedback target voltage or | 0.2 V - 0.1 V |
| Rear oxygen sensor sub feedback compensation coefficient or | On Min. |
| Rear oxygen sensor sub feedback compensation coefficient | On Max. |
| Elapsed time after starting the engine | > or = 60000 ms |
| Engine coolant temperature | > or = 70°C (158°F) |
| Vehicle speed | > or = 20 km/h (12.4 MPH) |
| Amount of intake air | > or = 6 g/s (0.21 oz/s) |
| Load change at 180°CA | < 0.02 g/rev (0 oz/rev) |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Learning value of evaporation gas density | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
| Targeted lambda value load compensation coefficient | 1 - 1 |
ENABLE CONDITIONS
Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | < 0.85 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > or = 0.85 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
- Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Detect that lambda value remains high.
Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio |
|---|
| Lambda > 1: Lean |
| Lambda < 1: Rich |
AIR FUEL RATIO REFERENCE
Scheme 301
| Secondary Parameters | Enable Condition |
|---|---|
| Time needed for all secondary parameters to be in enable conditions | > or = 4096 ms |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Rear oxygen sensor sub feedback | Execution |
| Rear oxygen sensor output voltage - Feedback target voltage or | 0.2 V - 0.1 V |
| Rear oxygen sensor sub feedback compensation coefficient or | On Min. |
| Rear oxygen sensor sub feedback compensation coefficient | On Max. |
| Elapsed time after starting the engine | > or = 60000 ms |
| Engine coolant temperature | > or = 70°C (158°F) |
| Vehicle speed | > or = 20 km/h (12.4 MPH) |
| Amount of intake air | > or = 6 g/s (0.21 oz/s) |
| Load change at 180°CA | < 0.02 g/rev (0 oz/rev) |
| Front oxygen (A/F) sensor impedance | 0 ohms - 50 ohms |
| Learning value of evaporation gas density | < 0.2 |
| Total time of operating canister purge | > or = 19.9 s |
| Targeted lambda value load compensation coefficient | 1 - 1 |
ENABLE CONDITIONS
Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > 1.15 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | < or = 1.15 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
- Correction when re-starting at high temperature: Normally minimum value 0.3 --> 0.
- Purge control: Not allowed to purge.
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Judge as NG when the valve is opened more than the default opening angle, but does not move to the close direction with the motor power stopped.
Scheme 302
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 6 V |
| Throttle position sensor | Normal |
ENABLE CONDITIONS
- Ignition switch ON --> OFF
- Ignition switch OFF --> ON (Only after clearing memory)
- Abnormality Judgment
Judge as NG when the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | < 2° |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | > or = 2° |
JUDGMENT VALUE
Time Needed for Diagnosis: 3400 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Detect the open/short circuit of pressure control solenoid valve.
Judge as NG when ECM output level is different from actual terminal level.
Scheme 303
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis :2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Always detect abnormality that both combination valve electromagnetic valve and the reed valve are open failure.
Calculate the integrated value of Max./Min. value and output voltage deviation of the secondary air delivery pipe pressure sensor output voltage in a given time after engine start. Judge as NG if the integrated value and the difference between Max. and Min. values are large.
| Secondary Parameters | Enable Condition |
|---|---|
| Engine speed | > or = 500 rpm and < 10000 rpm |
| Elapsed time after starting the engine | > or = 9000 ms |
| After secondary air system stops | > or = 9000 ms |
| Amount of intake air | > or = 2 g/s (0.07 oz/s) and < 400 g/s (14.11 oz/s) |
| Battery voltage | > or = 10.9 V |
| Engine load | > 0 g/rev |
| After fuel cut | > or = 1000 ms |
ENABLE CONDITIONS
Perform continuous diagnosis when air flow amount is large during the secondary air pump stop after engine start.
When both combination valve electromagnetic valve and the reed valve are open failure, the failure appears as pulses in the secondary air delivery pipe pressure sensor output. Detect abnormality by capturing these pulses using the following method.
- Abnormality Judgment
Calculate Max./Min. value of the secondary air delivery pipe pressure sensor output voltage and the sum of the output voltage deviation for the given time. Compare the difference between Max. and Min. values with threshold value and also compare the sum value with the threshold value. If both values exceed the threshold value, count up NG counter and then judge as NG if the counter reaches the given times.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Pipe inner pressure difference between Max. and Min. | > 0.05 V |
| Sum of the pipe inner pressure variation value every 4 milliseconds | > 5 V |
| Barometric pressure variation value | < 26.7 kPa (200 mmHg, 7.9 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms x 20 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear NG if neither exceeds the threshold value, or if either of the two exceeds the threshold value.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Pipe inner pressure difference between Max. and Min. | < or = 0.05 V |
| Sum of the pipe inner pressure variation value every 4 milliseconds | < or = 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs ON signal | HIGH |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Ignition | ON |
| Terminal output voltage when ECM outputs ON signal | LOW |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open/short circuit of pressure control solenoid valve.
Judge as NG when ECM output level is different from actual terminal level.
Scheme 304
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis after starting the engine.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or =1 second |
| Terminal output voltage when ECM outputs ON signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data.(For test mode $02)
Detect the abnormal function (stuck closed) of the drain valve.
Judge as NG when fuel tank pressure is low.
Scheme 305
| Secondary Parameters | Enable Condition |
|---|---|
| Drain valve | Open |
| Battery voltage | > or = 10.9 V |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Tank pressure when starter is OFF --> ON | 0.7 kPa (-5 mmHg, - 0.2 inHg) and 1.4 kPa (10.7 mmHg, 0.4 inHg) |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < or = -4 kPa (-30 mmHg, -1.2 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > or = -4 kPa (-30 mmHg, -1.2 inHg) |
| Cumulative time when all the malfunction criteria below are met. | > or = 30000 ms |
| Purge control solenoid valve duty | Not = 0 |
| Fuel temperature | 10°C (14°F) - 55 °C (131 °F) |
| Intake manifold relative pressure | > or = -26.7 kPa (-200 mmHg, -7.9 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Pressure control solenoid valve control: Open the pressure control solenoid valve.
Memorize the freeze frame data. (For test mode $02)
Detect the blow-by hose release abnormality.
Judge as NG when the diagnosis terminal voltage is high.
Scheme 306
| Secondary Parameters | Enable Conditions |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
| Positive crankcase ventilation diagnosis voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
| Positive crankcase ventilation diagnosis voltage | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the open/short circuit of back-up power supply circuit.
Judge as NG when the backup power voltage is low.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | Low |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | High |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. DTC P0513 INCORRECT IMMOBILIZER KEY, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect malfunctions of the catalyst advanced idling retard angle control.
Judge as NG when ECM is not controlling the angle properly during catalyst advanced idling retard angle control.
Judge as NG if there is exhaust gas temperature diagnosis and idle speed diagnosis and if either of them is NG.
- Exhaust gas temperature diagnosis
Judge as NG when the estimated exhausted gas temperature in 14 seconds after the cold start is below the specified value.
- Idle speed diagnosis
Judge as NG when actual engine speed is not close to target engine speed after terminating the retard angle control.
| Secondary Parameters | Enable Condition |
|---|---|
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
| Battery voltage | > or = 10.9 V |
| Cold start diagnosis | Incomplete |
| Vehicle speed | < 3 km/h (1.9 MPH) |
| Misfire within 200 engine revs. | < 5 |
| Time after starting | = 14 seconds |
ENABLE CONDITIONS
Perform the diagnosis at cold start.
- Exhaust gas temperature diagnosis
Abnormality Judgment
Calculate the estimated exhaust gas temperature when the diagnostic enable condition is established. Judge as NG when the following conditions are established after engine starting within the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Estimated exhaust gas temperature | < Value from Map |
JUDGMENT VALUE
Map
| Coolant temperature after starting the engine | 40°C (-40°F) | 30°C (-22 °F) | 20°C (--> °F) | 10°C (14 °F) | 0°C (32 °F) | 10°C (50°F) | 20°C (68 °F) | 30°C (86 °F) | 40°C (104 °F) | 45 °C (113 °F) |
|---|---|---|---|---|---|---|---|---|---|---|
| Threshold value (AT model) | 200°C (392 °F) | 200°C (392 °F) | 200°C (392 °F) | 200°C (392 °F) | 95 °C (203 °F) | 95 °C (203 °F) | 89 °C (192.2 °F) | 83 °C (181.4°F) | 79 °C (174.2 °F) | 79 °C (174.2 °F) |
| Threshold value (MT model) | 200°C (392 °F) | 200°C (392 °F) | 200°C (392 °F) | 200°C (392 °F) | 92 °C (197.6 °F) | 89 °C (192.2 °F) | 86 °C (186.8 °F) | 82 °C (179.6 °F) | 78 °C (172.4 °F) | 78 °C (172.4 °F) |
COOLANT TEMPERATURE SPECIFICATION
Time Needed for Diagnosis: 14 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Estimated exhaust gas temperature | > or = Value from Map |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- Idle speed diagnosis
Abnormality Judgment
Judge as NG when the following conditions are established after the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Continuous time of (Target engine speed - Actual engine speed > -100 rpm) | > or = 6000 ms |
| Continuous time of (actual retard amount > 30°CA) | > or = 0 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 14 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Continuous time of (Target engine speed - Actual engine speed > -100 rpm) | < 6000 ms |
| Continuous time of (actual retard amount > 30°CA) | < 0 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of tumble generator valve motor function.
Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30°C (-22°F) |
| Ambient air temperature | > or = -30°C (-22 °F) |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | > or = 64.3 ° |
| Tumble generator valve "close" signal output | > or = 3200 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | < 64.3 ° |
| Tumble generator valve "close" signal output | > or = 3200 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Tumble generator valve control
- Output the open signal.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of tumble generator valve motor function.
Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30°C (-22 °F) |
| Ambient air temperature | > or = -30°C (-22 °F) |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | > or = 64.3 ° |
| Tumble generator valve "close" signal output | > or = 3200 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | < 64.3 ° |
| Tumble generator valve "close" signal output | > or = 3200 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Tumble generator valve control
- Output the open signal.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of tumble generator valve motor function.
Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30°C (-22°F) |
| Ambient air temperature | > or = -30°C (-22 °F) |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | < 64.3 ° |
| Tumble generator valve "open" signal output | > or = 4600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | > or = 64.3 ° |
| Tumble generator valve "open" signal output | > or = 4600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Tumble generator valve control
- Output the close signal.
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of tumble generator valve motor function.
Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | > or = -30°C (-22°F) |
| Ambient air temperature | > or = -30°C (-22°F) |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | < 64.3 ° |
| Tumble generator valve "open" signal output | > or = 4600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening | > or = 64.3 ° |
| Tumble generator valve "open" signal output | > or = 4600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Tumble generator valve control
- Output the close signal.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the open signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 307
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs immediately after the tumble generator valve output is set to OFF --> ON, and judge open NG when the open NG signal is sent 96 ms x 20 time in a row.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Open NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 20 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Open NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve control: Not allowed to move tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 308
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs immediately after the tumble generator valve output is set to OFF --> ON, and judge overcurrent NG when the overcurrent NG signal is sent 96 ms x 10 time in a row.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 10 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve control: Not allowed to move tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the open signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 309
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs immediately after the tumble generator valve output is set to OFF --> ON, and judge open NG when the open NG signal is sent 96 ms x 20 time in a row.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Open NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 20 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Open NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve control: Not allowed to move tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 310
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 10.9 V |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs immediately after the tumble generator valve output is set to OFF --> ON, and judge overcurrent NG when the overcurrent NG signal is sent 96 ms x 10 time in a row.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 10 time
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve control: Not allowed to move tumble generator valve.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of tumble generator valve position sensor. Judge as NG if out of specification.
Scheme 311
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of tumble generator valve position sensor.
Judge as NG if out of specification.
Scheme 312
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of tumble generator valve position sensor.
Judge as NG if out of specification.
Scheme 313
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of tumble generator valve position sensor.
Judge as NG if out of specification.
Scheme 314
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Tumble generator valve opening
- For tumble generator valve full closing points learning, not allowed to update to closing side.
- For tumble generator valve full opening points learning, not allowed to update to opening side.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the oil flow control solenoid valve.
Judge as NG when the current is small even though the duty signal is large.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil flow control solenoid valve control duty | > or = 99.61 % |
| Oil control solenoid valve control present current | < 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil flow control solenoid valve | > or = 0.14 A |
| Target current value of the oil flow control solenoid valve - Oil flow control solenoid valve control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
- Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
- AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced. ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the oil flow control solenoid valve driving duty a predetermined value (9.36%).
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of oil flow control solenoid valve.
Judge as NG when the current is large even though the duty signal is small.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil flow control solenoid valve control duty | < 0.39 % |
| Oil control solenoid valve control present current | > or = 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil flow control solenoid valve - Oil flow control solenoid valve control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
- Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
- Ignition timing partial learning compensation: Enter the initial value (0°CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
- AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced. ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the oil flow control solenoid valve driving duty a predetermined value (9.36%).
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P2088. DTC P2088 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P2089. DTC P2089 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1), Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the malfunction of fuel system from the size of the sub feedback learning value.
Control the sub feedback learning and judge as NG when the learning value is in the lean zone.
Scheme 315
| Secondary Parameters | Enable Condition |
|---|---|
| Conditions for carrying out the sub feedback learning | Completed |
| Continuous time when all conditions are established. | > or = 1 s |
ENABLE CONDITIONS
Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < -0.04 (AT model) |
| <-0.04 (MT model) |
JUDGMENT VALUE
Time Needed for Diagnosis: 5 s x 1 time
Malfunction indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = -0.04 +0.005 (AT model) |
| > or = -0.04 + 0 (MT model) |
JUDGMENT VALUE
Time Needed for Diagnosis: 5 s
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When similar driving conditions are repeated 3 times and the result is OK.
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of fuel system from the size of the sub feedback learning value.
Sub feedback learning is being performed. When the learning value goes to the rich side, judge as NG.
Scheme 316
| Secondary Parameters | Enable Condition |
|---|---|
| Conditions for carrying out the sub feedback learning | Completed |
| Continuous time when all conditions are established. | > or = 1 s |
ENABLE CONDITIONS
Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = 0.04 (AT model) |
| > or = 0.04 (MT model) |
JUDGMENT VALUE
Time Needed for Diagnosis: 5 s x 1 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < 0.04 + -0.005 (AT model) |
| < 0.04 + 0 (MT model) |
JUDGMENT VALUE
Time Needed for Diagnosis: 5 s
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When similar driving conditions are repeated 3 times and the result is OK.
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the motor current becomes large or drive circuit is heated.
Scheme 317
| Secondary Parameters | Enable Condition |
|---|---|
| Under control of electronic throttle control | ON |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor current | < or = 8 A |
| Drive circuit inner temperature | < or = 175°C (347°F) |
JUDGMENT VALUE
Time Needed for Diagnosis
- milliseconds (For NG)
- milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the electronic throttle control power is not supplied even when ECM sets the electronic throttle control relay to ON.
Scheme 318
| Secondary Parameters | Enable Condition |
|---|---|
| Electronic throttle control relay output | ON |
ENABLE CONDITION
Always perform the diagnosis continuously.
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | > or = 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis
- milliseconds (For NG)
- milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the electronic throttle control power is supplied even when ECM sets the electronic throttle control relay to OFF.
Scheme 319
| Secondary Parameters | Enable Condition |
|---|---|
| Electronic throttle control relay output | OFF |
ENABLE CONDITION
- When ignition switch ON --> OFF
- Ignition switch OFF --> ON (Only after clearing memory)
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | < or = 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis
- milliseconds (For NG)
- milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when full close point learning cannot conducted or abnormal value is detected.
Scheme 320
| Secondary Parameters | Enable Condition |
|---|---|
| Ignition switch | ON --> OFF |
| Ignition switch (only after clear memory) | OFF --> ON |
ENABLE CONDITIONS
Perform the diagnosis at full closed point learning.
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Throttle sensor opening angle at full close point learning | 10.127° or more, 19.872° or less |
| Throttle opening angle when the ignition switch is ON - Throttle minimum stop position | > or = 1.683° |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 - 80 milliseconds
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 321
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- Single malfunction: Control with normal sensor
- Simultaneous failure: Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 322
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- Single malfunction: Control with normal sensor
- Simultaneous failure: Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 323
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 0.217 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- Single malfunction: Control with normal sensor
- Simultaneous failure: Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 324
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- Single malfunction: Control with normal sensor
- Simultaneous failure: Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 325
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | > Value from Map |
JUDGMENT VALUE
Map
| Throttle position sensor 1 opening angle (°) = d | 0 < or = d < 2.125° | 2.125 ° < or = d < 4.25° | 4.25 ° < or = d < 9 ° | 9° < or = d < 31.625° | 31.625 ° < or = d |
|---|---|---|---|---|---|
| Sensor output difference (°) | 5.15° | 6.15° | 8.28° | 10.4° | 12.4° |
THROTTLE POSITION SENSOR REFERENCE
Time Needed for Diagnosis: 212 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | < or = Value from Map |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed (Only with engine stopped)
Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)
Memorize the freeze frame data. (For test mode $02)
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 326
| Secondary Parameters | Enable Conditions |
|---|---|
| Ignition switch | ON |
| Battery voltage | > or = 6 V |
ENABLE CONDITION
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | > Value from Map |
JUDGMENT VALUE
Map
| Throttle position sensor 1 opening angle (°) = d | 0 < or = d < 0.6 ° | 0.6° < or = d < 1.2° | 1.2° < or = d < 2° | 2° < or = d <4° | 4° < or = d |
|---|---|---|---|---|---|
| Sensor output difference (°) | 1.465 ° | 1.597° | 1.663 ° | 2.455 ° | 3.116° |
THROTTLE POSITION SENSOR REFERENCE
Time Needed for Diagnosis: 116 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | < or = Value from Map |
JUDGMENT VALUE
Time Needed for Diagnosis: 116 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
Throttle opening is fixed to 6°.
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the purge control solenoid valve 2.
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect open or short circuit of the purge control solenoid valve 2.
Judge as NG when the ECM output level differs from the actual terminal level.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Detect the malfunction of secondary air pressure sensor output property.
Judge as NG when the secondary air pressure sensor output is largely different from the intake manifold pressure at engine start.
| Secondary Parameters | Enable Condition |
|---|---|
| Engine speed | < 300 rpm |
| Vehicle speed | < 1 km/h (0.6 MPH) |
| After secondary air system stops | > or = 2976 ms |
ENABLE CONDITIONS
Perform the diagnosis with ignition switch ON.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Secondary air pipe pressure - Intake manifold pressure | > or = 26.7 kPa (200 mmHg, 7.9 inHg) |
| Intake manifold pressure at engine start - Intake manifold pressure | < 1.3 kPa (9.99 mmHg, 0.4 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 328 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Secondary air pipe pressure - Intake manifold pressure | < 26.7 kPa (200 mmHg, 7.9 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 262 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG if out of specification.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Output voltage | < 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Output voltage | > or = 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Judge as NG if out of specification.
| Secondary Parameters | Enable Condition |
|---|---|
| None |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Output voltage | > 4.916 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Output voltage | < or = 4.916 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
Memorize the freeze frame data. (For test mode $02)
Note. For the detection standard, refer to DTC P0410. DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0410. DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0410. DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0410. DTC P0410 SECONDARY AIR INJECTION SYSTEM, Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the secondary air pump malfunction (always ON).
After the secondary air pump turns to OFF, judge as NG if the secondary air pipe pressure is higher than that before the secondary air pump operation.
| Secondary Parameters | Enable Condition |
|---|---|
| Battery voltage | > or = 7 V |
| Engine | In operation |
ENABLE CONDITIONS
Always perform the diagnosis continuously.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Time since secondary air control completion | > or = 3000 ms and |
| < or = 8000 ms | |
| Secondary air pipe pressure - Secondary air pressure before operation | > 6.7 kPa (50 mmHg, 2 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 8000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgment Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Time since secondary air control completion | > or = 3000 ms and |
| < or = 8000 ms | |
| Secondary air pipe pressure - Secondary air pressure before operation | < 6.7 kPa (50 mmHg, 2 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 8000 ms
- When the OK idling cycle is completed 40 times in a row
- When "Clear Memory" is performed
- When the OK driving cycle is completed 3 times in a row
- When "Clear Memory" is performed
None
- Memorize the freeze frame data. (For test mode $02)
- Memorize the diagnostic value and trouble standard value. (For test mode $06)
