SWITCH ASSEMBLY
Using a circuit tester (set to "ohm"), check that there is continuity between terminals S and M, and between terminal S and ground.
Also check to be sure there is no continuity between M terminal and B.
Terminal/Resistance
S - M/1 ohms or less
S - Ground/1 ohms or less
M - B/1 Mohms or more
Scheme 22
Scheme 23
- Using a lead wire, connect the S terminal of switch assembly to positive terminal of battery, and starter body to ground terminal of battery. The pinion should be forced endwise on shaft. NOTE: With the pinion forced endwise on shaft, starter motor can sometimes rotate because current flows, through pull-in coil, to motor. This is not a problem.
- Disconnect the connector from M terminal. Then using a lead wire, connect the positive terminal of battery and M terminal and ground terminal to starter body. In this test set up, the pinion should return to its original position even when it is pulled out with a screwdriver.
