SPOT MAP LIGHT SWITCH Subaru Impreza WRX GH

Lighting System 3 illustrations

SPOT MAP LIGHT SWITCH

Measure the spot map light resistance.

Scheme 52

Scheme 52: SPOT MAP LIGHT SWITCH
Scheme 52: SPOT MAP LIGHT SWITCH
Switch positionTerminal No.Standard
OFF1 and 21 Mohms or more
ON1 and 218+5.4 ohms

SWITCH POSITION TERMINAL CHART

Scheme 53

Scheme 53: REMOVAL
Scheme 53: REMOVAL

Scheme 54

Scheme 54
Scheme 54
  1. Disconnect the ground cable from the battery.
  2. Remove the lens (A) and mounting screws (B).
  3. Disconnect the harness connector and remove the room light.

Install in the reverse order of removal.
