Speed Control Systems (h4so) Subaru Impreza WRX GH

Engine Control Systems 2 illustrations ~165 words

SPECIFICATION

Accelerator pedalStrokeAt pedal pad50 - 59 mm (1.97 - 2.32 in)

GENERAL SPECIFICATION

Scheme 2

Scheme 2: COMPONENT
Scheme 2: COMPONENT

CAUTION

  1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
  2. Remove contamination including dirt and corrosion before removal or installation.
  3. Keep the parts in order and protect them from dust and dirt.
  4. Before removal or installation, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
  5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
  6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
  7. Place shop jacks or rigid racks at the specified points.
  8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

REMOVAL

  1. Disconnect the ground cable from battery.
  2. Disconnect the connector (A).
  3. Remove the nut (B) securing accelerator pedal assembly.

Scheme 3

Scheme 3
Scheme 3

INSTALLATION

Install in the reverse order of removal.

Tightening torque

18 N.m (1.8 kgf-m, 13.3 ft-lb)

DISASSEMBLY

Note. The accelerator pedal cannot be disassembled.
