Engine Cooling System - Cooling (h4dotc) Subaru Impreza WRX GH

SPECIFICATION

ENGINE COOLANT CAPACITY SPECIFICATION

COOLANT SPECIFICATION

ENGINE COOLANT TEMPERATURE SPECIFICATION

Scheme 52

Scheme 53

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

PREPARATION TOOL

PREPARATION TOOL SPECIFICATION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 499207400 CAM SPROCKET WRENCH Used for removing and installing exhaust cam sprocket. 499977100 CRANK PULLEY WRENCH Used to stop rotation of the crank pulley when loosening or tightening crank pulley bolts. (MT model) 499977400 CRANK PULLEY WRENCH Used to stop rotation of the crank pulley when loosening or tightening crank pulley bolts. (AT model) 499977500 CAM SPROCKET WRENCH Used for removing and installing intake cam sprocket. 1B021XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting for electrical system

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

INSPECTION

DETECTING CONDITION

1. Engine coolant temperature is 96°C (205°F) or more.
2. Vehicle speed is 19 km/h (12 MPH) or less.

TROUBLE SYMPTOMS

Radiator main fan and sub fan do not rotate under the above conditions.

DIAGNOSTIC PROCEDURE CHART

Scheme 59

1. Set the vehicle on a lift.
2. Lift up the vehicle.
3. Remove the under cover.
4. Remove the drain plug to drain engine coolant into container. NOTE: Remove the coolant filler tank cap so that engine coolant will drain faster.
5. Install the drain plug.

FILLING OF ENGINE COOLANT

1. Pour cooling system conditioner through the filler neck. Cooling system protective agent: Refer to "SPECIFICATION" for the cooling system protective agent. SPECIFICATION, General Description. >
2. Fill the engine coolant into coolant filler tank up to the filler neck position. Recommended engine coolant: Refer to "SPECIFICATION" for the recommended engine coolant. SPECIFICATION, General Description. > Coolant level: Refer to "SPECIFICATION" for the recommended engine coolant. SPECIFICATION, General Description. > CAUTION: Do not confuse the cap of coolant filler tank and cap of radiator. NOTE: When pouring the engine coolant, the radiator side cap must not be removed.
3. Fill engine coolant into the reservoir tank up to "FULL" level.
4. Close the coolant filler tank cap, and start the engine. Race 5 to 6 times at 3,000 rpm or less, then stop the engine. (Complete this operation within 40 seconds.)
5. Wait for one minute after the engine stops, then open the coolant filler tank cap. If the engine coolant level drops, add engine coolant into the coolant filler tank up to the filler neck position.
6. Perform the procedures 4) and 5) again.
7. Install the coolant filler tank cap and reservoir tank cap properly.
8. Start the engine and operate the heater at maximum hot position and the blower speed setting to "LO".
9. Run the engine at 2,000 rpm or less until radiator fan starts and stops. NOTE: Be careful with the engine coolant temperature gauge to prevent overheating.
10. Stop the engine and wait until the engine coolant temperature lowers to 30°C (86°F) or less.
11. Open the coolant filler tank cap. If the engine coolant level drops, add engine coolant into the coolant filler tank up to the filler neck position and the reservoir tank to "FULL" level.
12. Install the coolant filler tank cap and reservoir tank cap properly.
13. Set the heater setting to maximum hot position and the blower speed setting to "LO" and start the engine. Perform racing at 3,000 rpm or less. If the flowing sound is heard from heater core, repeat the procedures from step 9 ) again.

RELATIONSHIP OF ENGINE COOLANT CONCENTRATION AND FREEZING TEMPERATURE

The concentration and safe operating temperature of engine coolant is shown in the diagram 1. Measuring the temperature and specific gravity of the coolant will provide this information. [Example]

If the coolant temperature is 25°C (77°F) and its specific gravity is 1.054, the concentration is 35% (point A), the safe operating temperature is -14°C (7°F) (point B), and the freezing temperature is -20°C (-4°F) (point C).

1. Diagram 1

Scheme 60

PROCEDURE TO ADJUST THE CONCENTRATION OF THE COOLANT

To adjust the concentration of coolant according to temperature, find the proper engine coolant concentration in the diagram 1 and replace the necessary amount of coolant with an undiluted solution of engine coolant (concentration 50%).

The amount of engine coolant that should be replaced can be determined using the diagram 2.

[Example]

Assume that the engine coolant concentration must be increased from 25% to 40%. Find point A, where the 25% line of engine coolant concentration intersects with the 40% curve of the necessary engine coolant concentration, and read the scale on the vertical axis of the graph at height A. The quantity of coolant to be drained is 2.1 l (2.2 US qt, 1.8 lmp qt). Drain 2.1 l (2.2 US qt, 1.8 lmp qt) of coolant from the cooling system and add 2.1 l (2.2 US qt, 1.8 lmp qt) undiluted engine coolant solution.

If a coolant concentration of 50% is needed, drain all the coolant and refill with the undiluted solution only.

1. Diagram 2

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Remove the radiator. REMOVAL, Radiator. >
2. Remove the V-belts. REMOVAL , V-belt . >
3. Remove the crank pulley. REMOVAL , Crank Pulley . >
4. Remove the timing belt cover. REMOVAL , Timing Belt Cover . >
5. Remove the timing belt. REMOVAL , Timing Belt . >
6. Remove the automatic belt tension adjuster (A).
7. Remove the belt idler (B).
8. Remove the belt idler No. 2 (C).
9. Remove the cam sprocket LH. REMOVAL , Cam Sprocket . >
10. Remove the belt cover LH No. 2.
11. Remove the tensioner bracket.
12. Disconnect the hose from water pump.
13. Remove the water pump.

Scheme 65

Scheme 66

1. Install the water pump onto cylinder block (LH). NOTE: Use a new gasket. When installing the water pump, tighten the bolts in two stages in alphabetical sequence as shown in figure. Tightening torque: First: 12 N.m (1.2 kgf-m, 8.9 ft-lb) Second: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
2. Install the hose to water pump.
3. Install the tensioner bracket. Tightening torque: 24.5 N.m (2.5 kgf-m, 18.1 ft-lb)
4. Install the belt cover No. 2 (LH). Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
5. Install the cam sprocket LH. INSTALLATION , Cam Sprocket . >
6. Install the belt idler No. 2 (C). Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)
7. Install the belt idler (B). Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)
8. Install an automatic belt tension adjuster (A) with the tension rod held by a pin. AUTOMATIC BELT TENSION ADJUSTER ASSEMBLY AND BELT IDLER , INSTALLATION, Timing Belt . >
9. Install the timing belt. TIMING BELT , INSTALLATION, Timing Belt . >
10. Install the timing belt cover. INSTALLATION , Timing Belt Cover . >
11. Install the crank pulley. INSTALLATION , Crank Pulley . >
12. Install the V-belts. INSTALLATION , V-belt . >
13. Install the radiator. INSTALLATION, Radiator. >

Scheme 67

1. Check the water pump bearing for smooth rotation.
2. Check the water pump pulley for abnormalities.
3. Make sure the impeller is not deformed or damaged.
4. Inspect the clearance between impeller and pump case. Clearance between impeller and pump case: Standard 0.5 - 1.5 mm (0.020 - 0.059 in)
5. After water pump installation, check pulley shaft for engine coolant leaks or noise. If leaks or noise are noted, replace the water pump assembly.

Scheme 68

1. Set the vehicle on a lift.
2. Lift up the vehicle.
3. Remove the under cover.
4. Drain engine coolant completely. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
5. Disconnect the radiator outlet hose from thermostat cover.
6. Remove the thermostat cover, and then remove the gasket and thermostat.

Scheme 69

Scheme 70

1. Install a gasket to thermostat. NOTE: Use a new gasket.
2. Install the thermostat and thermostat cover. NOTE: The thermostat must be installed with the jiggle pin facing upward. Tightening torque: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
3. Connect the radiator outlet hose to thermostat cover.
4. Install the under cover.
5. Lower the vehicle.
6. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >

Replace the thermostat if the valve does not close completely at an ambient temperature or if the following test shows unsatisfactory results.

1. Inspection method

Immerse the thermostat and a thermometer in water. Raise water temperature gradually, and measure the temperature and valve lift when the valve begins to open and when the valve is fully opened. During the test, agitate the water for even temperature distribution. The measured value should meet the specification.

Note. Leave the thermostat in the boiling water for five minutes or more before measuring the valve lift. Hold the thermostat with a wire or the like to avoid contacting with container bottom.

Opening start temperature

76 - 80°C (169 - 176°F)

Full open temperature

91°C (196°F)

Valve lift

9.0 mm (0.354 in) or more

Scheme 71

REMOVAL

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Remove the heat shield cover from radiator. (AT model)
6. Drain engine coolant completely. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
7. Disconnect the connectors of radiator main fan (A) and sub fan motor (B).
8. Disconnect the radiator outlet hose from thermostat cover.
9. Disconnect the ATF cooler hoses from ATF pipes. Plug the ATF pipe to prevent ATF from leaking. (AT model)
10. Lower the vehicle.
11. Remove the air intake duct. REMOVAL , Air Intake Duct . >
12. Disconnect the over flow hose.
13. Remove the reservoir tank. REMOVAL, Reservoir Tank. >
14. Disconnect the radiator inlet hose (A) from the radiator.
15. Disconnect the two coolant filler tank hoses from the radiator.
16. Remove the radiator upper brackets.
17. Move the radiator to the left while lifting it upward.
18. Lift the radiator up and away from vehicle.

Scheme 80

1. Attach the radiator lower cushion to the hole on the radiator lower bracket.
2. Install the radiator to vehicle. NOTE: Make pins on the lower side of radiator be fitted into the radiator lower cushions on body side.
3. Install the radiator upper brackets and tighten the bolts. Tightening torque: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
4. Connect the two coolant filler tank hoses to the radiator.
5. Connect the radiator inlet hose (A).
6. Install the reservoir tank. INSTALLATION, Reservoir Tank. >
7. Connect the over flow hose.
8. Install the air intake duct. INSTALLATION , Air Intake Duct . >
9. Lift up the vehicle.
10. Connect the ATF cooler hoses. (AT model)
11. Connect the radiator outlet hose.
12. Connect the connectors to the radiator main fan motor (A) and sub fan motor (B).
13. Install the heat shield cover to the radiator. (AT model) Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
14. Install the under cover.
15. Lower the vehicle.
16. Connect the battery ground cable to battery.
17. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
18. Check the ATF level. INSPECTION , Automatic Transmission Fluid . >

Scheme 81

1. Remove the coolant filler tank cap, fill the coolant filler tank with engine coolant, then install the tester to the installation position of the cap.
2. Apply a pressure of 122 kPa (1.2 kg/cm 2 ,18 psi) to the radiator and check the following points: Leakage from the radiator or its vicinity Leakage from the hose or its connections CAUTION: Inspection must be carried out at the side of coolant filler tank, not at the side of radiator. Engine should be turned off. Wipe engine coolant from check points in advance. Be careful of the spurt of engine coolant when removing the tester. Be careful not to deform the filler neck of the coolant filler tank when installing and removing the tester.

Scheme 82

1. Attach the radiator cap to tester.
2. Increase pressure until the tester gauge pointer stops. Radiator cap is functioning properly if it holds the service limit pressure for five to six seconds. Remove the cap if it is opened under a pressure less than the service limit value Coolant filler tank side Specification: 93 - 123 kPa (0.95 - 1.25 kg/cm 2 , 14 - 18 psi) Service limit: 83 kPa (0.85 kg/cm 2 , 12 psi) Radiator side Specification: 122 - 152 kPa (1.24 - 1.55 kg/cm 2 , 18 - 22 psi) Service limit: 112 kPa (1.14 kg/cm 2 , 16 psi) CAUTION: Be sure to remove foreign matter and rust from the cap in advance. Otherwise, results of pressure test will be incorrect. Do not confuse the cap of coolant filler tank and cap of radiator.

Scheme 83

Scheme 84

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Disconnect the main fan motor connector (A).
6. Remove the heat shield cover from radiator. (AT model)
7. Drain approximately 1 l (1.06 US qt, 0.88 lmp qt) of coolant. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
8. Remove the ATF hose from the clip of the radiator main fan motor assembly. (AT model)
9. Lower the vehicle.
10. Remove the air intake duct.
11. Disconnect the over flow hose.
12. Remove the over flow pipe.
13. Remove the reservoir tank. REMOVAL, Reservoir Tank. >
14. Remove the mounting bolts from radiator main fan motor assembly.
15. Disconnect the radiator inlet hose (A) from the radiator.
16. Remove the radiator main fan motor assembly from vehicle.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

7.5 N.m(0.76 kgf-m, 5.5 ft-lb)

Tightening torque

3 N.m (0.3 kgf-m, 2.2 ft-lb)

Scheme 85

1. Remove the clip which holds the fan motor connector onto the shroud.
2. Remove the nuts which hold the fan to the fan motor.
3. Remove the bolts which hold fan motor onto shroud.

Scheme 86

ASSEMBLY

Assemble in the reverse order of disassembly.

Tightening torque

4.41 N.m (0.45 kgf-m, 3.25 ft-lb)

Tightening torque

3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

Scheme 87

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Disconnect the sub fan motor connector (B).
6. Remove the heat shield cover from radiator. (AT model)
7. Drain approximately 1 G (1.06 US qt, 0.88 lmp qt) of coolant. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
8. Lower the vehicle.
9. Remove the air intake duct.
10. Disconnect the over flow hose.
11. Remove the over flow pipe.
12. Remove the reservoir tank. REMOVAL, Reservoir Tank. >
13. Remove the mounting bolts from the radiator sub fan motor assembly.
14. Disconnect the radiator inlet hose (A) from the radiator.
15. Remove the radiator sub fan motor assembly from the vehicle.

Install in the reverse order of removal.

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Tightening torque

3 N.m (0.3 kgf-m, 2.2 ft-lb)

Scheme 88

1. Remove the clip which holds the fan motor connector onto the shroud.
2. Remove the nuts which hold the fan to the fan motor.
3. Remove the bolts which hold fan motor onto shroud.

Assemble in the reverse order of disassembly.

Tightening torque

4.41 N.m (0.45 kgf-m, 3.25 ft-lb)

Tightening torque

3.4 N.m (0.35 kgf-m, 2.5 ft-lb)

1. Disconnect the over flow hose (A).
2. Pull out the reservoir tank to the arrow direction while pushing the claw (B).

Scheme 89

Install in the reverse order of removal.

Make sure the engine coolant level is between "FULL" and "LOW".

Scheme 90

1. Drain approximately 3.0 l (3.2 US qt, 2.6 lmp qt) of coolant. DRAINING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >
2. Disconnect the engine coolant hoses from coolant filler tank.
3. Remove the bolts which install the coolant filler tank.
4. Disconnect the engine coolant hose which connects the under side of coolant filler tank.
5. Remove the coolant filler tank.

Scheme 91

1. Install in the reverse order of removal. Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)
2. Fill engine coolant. FILLING OF ENGINE COOLANT, REPLACEMENT, Engine Coolant. >

ENGINE COOLING SYSTEM TROUBLESHOOTING CHART
