SPECIAL TOOL
SPECIAL TOOL REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 498575400 OIL PRESSURE GAUGE ASSY Used for measuring oil pressure. 498897200 OIL PRESSURE GAUGE ADAPTER Used oil pump housing when measuring reverse clutch pressure and line pressure. 498897700 OIL PRESSURE ADAPTER SET Used for measuring transfer clutch pressure. 498545400 OIL FILTER WRENCH Used for removing and installing ATF filter. 498277200 STOPPER SET Used for removing and installing automatic transmission assembly to engine. 41099AC000 ENGINE SUPPORT ASSY Used for supporting engine. 398527700 PULLER ASSY Used for removing extension case roller bearing. Used for removing extension oil seal. Used for removing front differential side retainer bearing outer race. Used for removing front differential side retainer bearing outer ball race. 498057300 INSTALLER Used for installing extension oil seal. 498077000 REMOVER Used for removing differential taper roller bearing. 499247400 INSTALLER Used for installing transfer outer snap ring. Used with SNAP RING OUTER GUIDE (499257300). 499257300 SNAP RING OUTER GUIDE Used for installing transfer outer snap ring. Used with INSTALLER (499247400). 499787000 WRENCH ASSY Used for removing and installing differential side retainer. 398437700 DRIFT Used for installing converter case oil seal. Used for installing taper roller bearing of front differential. 398673600 COMPRESSOR Used for removing and installing clutch spring. 498255400 PLATE Used for measuring backlash of hypoid gear. 399893600 PLIERS Used for removing and installing clutch spring. 498247001 MAGNET BASE Used for measuring gear backlash. Used with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring gear backlash. Used with MAGNET BASE (498247001). 498517000 REPLACER Used for removing front roller bearing. 398623600 SEAT Used for removing spring of transfer clutch piston. 499267300 STOPPER PIN Used for installing inhibitor switch. 499787700 WRENCH Used for removing and installing drive pinion lock nut. 499787500 ADAPTER Used for removing and installing drive pinion lock nut. 398643600 GAUGE Used for measuring total end play, extension end play and drive pinion height. 498627100 SEAT Used for holding low clutch piston retainer spring when installing snap ring. 499577000 GAUGE Used for measuring the transmission case mating surface to the reduction gear end surface. For MP-T model. 398744300 GAUGE Use for measuring contact face between multi-plate clutch end and transmission. For VTD model. 499737000 PULLER Used for removing reduction driven gear assembly. 499737100 PULLER SET Used for removing reduction drive gear assembly. 498077600 REMOVER Used for removing ball bearing. 498937110 HOLDER Used for removing and installing drive pinion lock nut. 498677100 COMPRESSOR Used for installing 2-4 brake snap ring. 498437000 HIGH CLUTCH PISTON GUIDE Used for installing high clutch piston. 498437100 LOW CLUTCH PISTON GUIDE Used for installing low clutch piston. 899580100 INSTALLER Used for press-fitting the ball bearing for transfer clutch. 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing differential side retainer oil seal. 28399SA010 OIL SEAL PROTECTOR Used for installing front drive shaft. 398497701 INSTALLER Used for installing needle bearing. 499247300 INSTALLER Used for installing drive pinion shaft oil seal. 899524100 PULLER SET Used for bolt only. Used with PULLER SET (499737100). Used with PULLER (499737000). Puller Cap 398663600 PLIERS Used for removing and installing snap ring. 18482AA010 (Newly adopted tool) CARTRIDGE Troubleshooting for electrical systems. 22771AA030 SUBARU SELECT MONITOR KIT Troubleshooting for electrical systems
