PROCEDURE
| Step | Check | Yes | No |
|---|---|---|---|
| 1 START INSPECTIONS. Perform the pre-inspection. < Ref. to INSPECTION , General Description. > Perform the self-diagnosis. < Ref. to OPERATION , Diagnostic Chart for Self-Diagnosis. > | Does the self-diagnosis operate? | Go to step 2. | < Ref. to A/C OR SELF-DIAGNOSIS SYSTEMS DO NOT OPERATE , Diagnostics for A/C System Malfunction. > |
| 2 CONFIRM MALFUNCTION PART. Confirm the malfunction part with self-diagnosis. | Can the malfunction part be confirmed? | Repair the malfunction part according to each diagnostics chart. | Go to step 3. |
| 3 CHECK COMPARTMENT TEMPERATURE. Turn the A/C switch ON. Set the temperature control dial to maximum cold position. Check the compartment temperature changes. | Is the compartment temperature changed? | Go to step 4. | < Ref. to COMPARTMENT TEMPERATURE DOES NOT CHANGE , OR A/C SYSTEM DOES NOT RESPOND PROMPTLY., Diagnostics for A/C System Malfunction. > |
| 4 CHECK A/C SYSTEM RESPONSE. Change the temperature setting, and check the response of A/C system. | Does the A/C system respond quickly? | A/C system is OK. | < Ref. to COMPARTMENT TEMPERATURE DOES NOT CHANGE , OR A/C SYSTEM DOES NOT RESPOND PROMPTLY., Diagnostics for A/C System Malfunction. > |
BASIC DIAGNOSTIC PROCEDURE
CAUTION
- Never connect the battery in reverse polarity. The Auto A/C control module will be destroyed instantly.
- Do not disconnect the battery cables while the engine is running. A large counter electromotive force will be generated in the alternator, and this voltage may damage electronic parts such as auto A/C control module.
- Before disconnecting the connectors of each sensor and the auto A/C control module, be sure to turn off the ignition switch. The auto A/C control module may be damaged.
- Every A/C-related part is a precision part. Do not drop them.
- Airbag system wiring harness is routed near the A/C control panel (auto A/C control module) and junction box. CAUTION: Airbag system connectors are colored yellow. Do not use electrical test equipment on these circuits. Be careful not to damage the airbag system wiring harness when servicing the A/C control panel (auto A/C control module) and junction box.
INSPECTION
Before performing diagnosis, check the following items which might affect A/C system problems.
BATTERY
- Measure the battery voltage and specific gravity of electrolyte. Standard voltage: 12 V Specific gravity: Above 1.260
- Check the condition of the fuses for A/C system power supply and other fuses.
- Check the condition of the harnesses and harness connectors connection.
Scheme 1
Scheme 2
- Turn the ignition switch to ON and push the A/C switch.
- Turn the temperature control dial to maximum hot position.
- Turn the air flow control dial to "DEF" position.
- Turn the fan speed control dial to MAX speed position.
- Firmly hold a thin paper (b) in front of the in-vehicle sensor suction port (a) for the auto A/C control module and check that the paper moves towards the port indicating that air is being sucked into the port. NOTE: Ensure the paper does not get sucked into the port. (Scheme 1): Checking Sensor
- If the paper does not move at all, remove the auto A/C control module < Ref. to «REMOVAL»(/subaru/impreza-wrx/gdgg-2-2005-2007/remont/general-servicing-all-makes/#hvac-system-heater-ventilator-and-ac), Control Unit (Auto A/C Model). > and check for improper connection of the aspirator hose (A), auto A/C control module and heater unit, and secure as necessary. (Scheme 2): Checking For Improper Connection Of Aspirator Hose
A/C LINE
Check the connection for A/C line (A) and lower side high-pressure pipe.
Checking Connection For A/C Line And Lower Side High-Pressure Pipe. Scheme 3
CONTROL LINKAGE
- Check the state of mode door linkage.
- Check the state of air mix door linkage.
- Check the state of intake door linkage.
CONTROL SWITCHES
Start and warm-up the engine completely.
- Inspection using switches SWITCH INSPECTION REFERENCE No. Item to be checked Switch position Judgment standard 1 Air flow control dial Turn the dial to the right. Outlet opening (mode) switches AUTO --> VENT --> BILEVEL --> HEAT --> DEF/HEAT --> DEF each time turning the dial. 2 Fan speed control dial Turn the dial to the right Fan speed switches OFF --> AUTO --> 1st - 25th each time turning the dial. 3 FRESH/RECIRC switch Press the FRESH/RECIRC switch. Inlet opening switches RECIRC --> FRESH each time pressing the switch. Press the FRESH/RECIRC switch longer (more than 1.0 seconds). LED blinks twice, and switches to AUTO. 4 A/C switch Turn the A/C switch to ON with the fan speed control dial position other than OFF. LED comes on, and the compressor will be operated. Press the FRESH/RECIRC switch longer (more than 1.0 seconds). LED blinks twice, and switches to AUTO. 5 Auto function Operate from 1) in order. Set the following dials and switches to AUTO. Air flow control dial Fan speed control dial FRESH/RECIRC switch A/C switch Turn the temperature control dial to the left fully, to set to the maximum cool position. Outlet air temperature: COOL Fan speed: MAX Outlet opening: VENT Inlet opening: Internal air Compressor: AUTO 3)Turn the temperature control dial to the right slowly, to change the setting gradually to the maximum hot position. Outlet air temperature: COOL --> HOT Fan speed: AUTO Outlet opening: AUTO Inlet opening: AUTO Compressor: AUTO 4) Turn the temperature control dial to the right fully, to set to the maximum hot position. Outlet air temperature: HOT Fan speed: MAX Outlet opening: HEAT Inlet opening: External air Compressor: AUTO 6 Defroster interlock Turn the air flow control dial to DEF or DEF/HEAT position. Outlet air temperature: AUTO Fan speed: AUTO Outlet opening: DEF or DEF/HEAT Inlet opening: External air Compressor: ON 7 Rear window defogger switch Press the rear window defogger switch. LED comes on.
- Inspection of illumination control ILLUMINATION CONTROL INSPECTION REFERENCE No. Item to be checked Switch operation Judgment standard 1 Illumination Turn the lighting switch to ON. Illumination comes on. LED goes dim if it has been illuminated.
Identifying Engine Compartment Electrical Component Location. Scheme 4
Identifying Passenger Compartment Electrical Component Location. Scheme 5
Identifying Auto A/C Control Module Connector Terminals. Scheme 6
| Content | Connector & Terminal No. | Signal (V) |
|---|---|---|
| Battery power supply (Memory back-up) | B1 - B12 | Battery voltage, 13 - 14 (engine running) |
| IGN power supply | A8 -B12 | Battery voltage (ignition switch ON), 13 - 14 (engine running) |
| ACC power supply | B2 -B12 | Battery voltage, 0 (engine cranking), Battery voltage (engine running) |
| Auto A/C control module ground circuit | B12 -chassis ground | 0 (ignition switch ON) - circuit constantly grounded to chassis |
| Sensor ground circuit | B17 -chassis ground | 0 (ignition switch ON) - circuit constantly grounded to chassis |
| Ambient sensor | B9 -B17 | Approx. 5 (disconnect connector, and ignition switch ON) |
| Evaporator sensor | B7 -B17 | |
| Thermometer | B15 -B12 | |
| Sunload sensor | B16 - B17 | Approx. 5 (disconnect connector, and ignition switch ON) |
| Air mix door actuator | B5 -B1 | Battery voltage (ignition switch ON) |
| Air mix door actuator P.B.R. | A4 -B17 | LAN connection |
| Mode door actuator | B6 -B17 | Battery voltage (ignition switch ON) |
| Mode door actuator P.B.R. | A12 -B17 | LAN connection |
| Intake door FRS voltage | A15 -A7 | Battery voltage (FRESH/RECIRC switch OFF) |
| Intake door CIRC voltage | A7 -A15 | Battery voltage (FRESH/RECIRC switch ON) |
| Blower fan relay | B14 - body | Battery voltage (ignition switch ON) |
| A/C relay | B3 -B12 | 0 (ignition and A/C switches ON) Battery voltage (A/C switch OFF) |
| Illumination control signal | B10 - B20 | Battery voltage (ignition and lighting switches ON) |
| Rear window defogger | A13 - B12 | 0 (ignition switch ON, rear window defogger switch ON) |
TERMINALS REFERENCE
AIR CONDITIONER AUTO A/C MODEL
< Ref. to AIR CONDITIONING in SYSTEM WIRING DIAGRAMS . >
Identifying Air Conditioner Switches. Scheme 7
| Step | Check | Yes | No |
|---|---|---|---|
| 1 SELECT CONTROL PANEL TO SELF-DIAGNOSIS MODE. Turn the fan speed control dial to OFF position. Start the engine and press the A/C switch for at least 5 seconds. The A/C switch must be pressed within 10 seconds after starting engine. | Does the self-diagnosis mode operate? | Go to step 2. | < Ref. to A/C OR SELF-DIAGNOSIS SYSTEMS DO NOT OPERATE , Diagnostics for A/C System Malfunction. > |
| 2 CHECK LED ILLUMINATION. Make sure that all switch LED illuminate on control panel. | Do all LED illuminate? | Go to step 3. | Check the switch LED. |
| 3 CHECK SENSORS MALFUNCTION. Turn the fan speed control dial to AUTO position. If the system has trouble for each sensor, rear window defogger switch LED is turned off. If the system has no trouble, rear window defogger switch LED is illuminated. | Does the rear window defogger switch LED illuminate? | Go to step 5. | Go to step 4. |
| 4 CONFIRM MALFUNCTIONING SENSOR. Turn the fan speed control dial to 1 - 6th position. Turn the air flow control dial to each mode position, check each switch LED illumination according to sensor check table. < Ref. to SENSOR CHECK TABLE , OPERATION, Diagnostic Chart for Self-Diagnosis. > | Do FRESH/RECIRC and A/C switch LED illuminate when turning the dial to each mode position? | Go to step 5. | Repair the malfunctioning sensor. < Ref. to DIAGNOSTIC PROCEDURE FOR SENSORS . > |
| 5 CHECK MODE DOOR POSITION SIGNAL. Turn the fan speed control dial to 7 - 12th position. If the system has trouble for mode door position signal, rear window defogger switch LED is turned off. If the system has no trouble, rear window defogger switch LED is illuminated. | Does the rear window defogger switch LED illuminate? | Go to step 6 . | Check the mode door actuator circuit. < Ref. to MODE DOOR ACTUATOR , Diagnostic Procedure for Actuators. > |
| 6 CHECK BLOWER FAN OPERATION. Turn the fan speed control dial to 13 - 18th position. Turn the temperature control dial, check that blower fan speed changes depending on set temperature. | Does the blower fan speed change? | Go to step 7. | Check the blower motor circuit. < Ref. to BLOWER FAN DOES NOT ROTATE , Diagnostics for A/C System Malfunction. > |
| 7 CHECK OPERATION OF EACH ACTUATOR, BLOWER FAN AND COMPRESSOR CLUTCH. Turn the fan speed control dial to 19 - 25th position. Select the operating mode by turning air flow control dial. Check the operation of each mode according to operating mode table. < Ref. to OPERATING MODE TABLE , OPERATION, Diagnostic Chart for Self-Diagnosis. > Air inlet: Air outlet: Air mix door: Blower fan: A/C compressor | Does the operation of each mode match to operating mode table? | Push the A/C switch or turn the ignition switch to OFF, and finish the self-diagnosis. | Repair the mal-function part according to each diagnostics chart. |
DIAGNOSTIC CHART
SENSOR CHECK TABLE
Note. When the sunload sensor is checked indoors or in the shade, open circuit might be indicated. Always check the sunload sensor at a place where sun shines directly on it.
| Air flow control dial position | Checked sensor | No trouble | Short circuit | Open circuit |
|---|---|---|---|---|
| VENT | Ambient sensor | A/C switch LED and FRESH/RECIRC switch LED illuminate | A/C switch LED illuminate | FRESH/RECIRC switch LED illuminate |
| BI-LEVEL | In-vehicle sensor | A/C switch LED and FRESH/RECIRC switch LED illuminate | A/C switch LED illuminate | FRESH/RECIRC switch LED illuminate |
| HEAT | Evaporator sensor | A/C switch LED and FRESH/RECIRC switch LED illuminate | A/C switch LED illuminate | FRESH/RECIRC switch LED illuminate |
| DEF/HEAT | Sunload sensor | A/C switch LED and FRESH/RECIRC switch LED illuminate | A/C switch LED illuminate | FRESH/RECIRC switch LED illuminate |
| DEF | Air mix door motor (Potentio balance resistor) | A/C switch LED and FRESH/RECIRC switch LED illuminate | A/C switch LED illuminate | |
SENSOR CHECK
OPERATING MODE TABLE
| Operation | Air flow control dial position | ||||
|---|---|---|---|---|---|
| VENT | BI-LEVEL | HEAT | DEF/HEAT | DEF | |
| Air outlet | VENT | BI-LEVEL | HEAT | DEF/HEAT | DEF |
| Air inlet | RECIRC | RECIRC | RECIRC | FRESH | FRESH |
| Air mix door | FULL COOL | FULL COOL | FULL HOT | FULL HOT | FULL COOL |
| Blower fan | 5V | 5V | 8V | 10V | Power supply voltage |
| A/C compressor | ON | OFF | OFF | ON | ON |
OPERATING MODE
A/C OR SELF-DIAGNOSIS SYSTEMS DO NOT OPERATE
TROUBLE SYMPTOM
- Switch LEDs are faulty or switches do not operate.
- Self-diagnosis system does not operate.
WIRING DIAGRAM
Wiring Diagram - A/C Or Self-Diagnosis Systems Do Not Operate. Scheme 8
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK FUSE. Turn the ignition switch to OFF. Remove the fuse No. 2 from main fuse box. Check the condition of fuse. | Is the fuse blown-out? | Replace the fuse. | Go to step 2. |
| 2 CHECK FUSE. Turn the ignition switch to OFF. Remove the fuses No. 9 and No. 17 from fuse & relay box. Check the condition of fuse. | Is the fuse blown-out? | Replace the fuse. | Go to step 3. |
| 3 CHECK AUTO A/C CONTROL MODULE POWER CIRCUIT. Pull out the auto A/C control module connector. Measure the voltage between auto A/C control module connector terminal and chassis ground when turning ignition switch to OFF. Connector & terminal (B283) No. 1 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 4. | Repair the short circuit in harness for power supply line. |
| 4 CHECK AUTO A/C CONTROL MODULE POWER CIRCUIT. Measure the voltage between auto A/C control module connector terminal and chassis ground when turning the ignition switch to ACC. Connector & terminal (B283) No. 2 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 5. | Repair the short circuit in harness for power supply line. |
| 5 CHECK AUTO A/C CONTROL MODULE POWER CIRCUIT. Measure the voltage between auto A/C control module connector terminal and chassis ground when turning the ignition switch to ON. Connector & terminal (B282) No. 8 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 6. | Repair the short circuit in harness for power supply line. |
| 6 CHECK AUTO A/C CONTROL MODULE GROUND CIRCUIT. Measure the resistance of harness between auto A/C control module and chassis ground. Connector & terminal (B283) No. 12 - Chassis ground | Is the resistance less than 5 ohms? | Go to step 7. | Repair the harness for ground line. |
| 7 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
BLOWER FAN DOES NOT ROTATE
TROUBLE SYMPTOM
- Blower motor is not rotated.
- Blower motor is not rotated at "HI".
WIRING DIAGRAM
Wiring Diagram - Blower Fan Does Not Rotate. Scheme 9
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK FUSE. Remove the No. 1, No. 2 and No. 17 fuses in fuse & relay box. Check the condition of fuses. | Are any of the fuses blown-out? | Replace the fuse. | Go to step 2. |
| 2 CHECK POWER SUPPLY TO BLOWER FAN MOTOR. Turn the ignition switch to ON. Turn the fan speed control dial to the right. Measure the voltage between blower fan motor and chassis ground. Connector & terminal (B87) No. 1 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 3. | Repair the open circuit in harness for blower fan motor power supply line. |
| 3 CHECK BLOWER FAN MOTOR RELAY. Turn the ignition switch to OFF. Remove the blower fan motor relay. Connect the battery positive (+) terminal to No. 1 terminal and negative (-) terminal to No. 3 terminal of blower fan motor connector. Measure the resistance between No. 2 and No. 4 terminals. Terminals No. 2 -No. 4 | Is the resistance less than 1 ohms? | Go to step 4. | Replace the blower fan motor relay. |
| 4 CHECK BLOWER FAN MOTOR. Disconnect the connector from blower fan motor. Connect the battery positive (+) terminal to No. 1 terminal and negative (-) terminal to No. 2 terminal of blower fan motor connector. Make sure that the blower fan motor is operated. | Does the blower fan motor operate? | Go to step 5. | Replace the blower fan motor. |
| 5 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
COMPARTMENT TEMPERATURE DOES NOT CHANGE, OR A/C SYSTEM DOES NOT RESPOND PROMPTLY
TROUBLE SYMPTOM
- Compartment temperature is not changed. (No cool air is discharged.)
- A/C system does not respond quickly.
WIRING DIAGRAM
Wiring Diagram - Compartment Temperature Does Not Change. Scheme 10
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK FUSE. Turn the ignition switch to OFF. Remove the No. 2 fuse in main fuse box. Check the condition of fuse. | Is the fuse blown-out? | Replace the fuse. | Go to step 2. |
| 2 CHECK POWER SUPPLY TO MAGNET CLUTCH OF A/C COMPRESSOR. Start the engine, and turn A/C switch to ON. Set the temperature control dial to maximum cold position. Measure the voltage between magnet clutch connector and chassis ground. Connector & terminal (F24) No. 1 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 3. | Repair the open circuit in harness for power supply line of the A/C compressor. |
| 3 CHECK SIGNAL VOLTAGE TO A/C RELAY. Turn the ignition switch to ON. Turn the A/C switch to ON. Measure the signal voltage between A/C relay and chassis ground. Connector & terminal (F129) No. 7 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 4. | Repair the open circuit in harness for A/C relay signal circuit. |
| 4 CHECK A/C RELAY. Check the A/C relay. < Ref. to INSPECTION , Relay and Fuse. > | Is the operation of the relay OK? | Go to step 5. | Replace the A/C relay. |
| 5 CHECK OPERATION OF MAIN FAN MOTOR. Start the engine. Turn the A/C switch to ON. Check the operation of main fan motor. | Does the radiator main fan operate? | Go to step 10 . | Go to step 6. |
| 6 CHECK POWER SUPPLY TO MAIN FAN MOTOR. CAUTION: Be careful not to overheat the engine during repair. Turn the ignition switch to OFF. Disconnect the connector from main fan motor. Start the engine, and warm it up until engine coolant temperature increases over 95°C (203°F). Stop the engine and turn ignition switch to ON. Measure the voltage between main fan motor connector and chassis ground. Connector & terminal (F17) No. 1,2 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 7. | Repair the open circuit in harness for power supply circuit. |
| 7 CHECK GROUND CIRCUIT OF MAIN FAN MOTOR. Turn the ignition switch to OFF. Measure the resistance between main fan motor connector and chassis ground. Connector & terminal (F17) No. 3,4 - Chassis ground | Is the resistance less than 1 ohms? | Go to step 8. | Repair the open circuit in harness between main fan motor connector and chassis ground. |
| 8 CHECK POOR CONTACT. Check poor contact in main fan motor connector. | Is there poor contact in main fan motor connector? | Repair the poor contact in main fan motor connector. | Go to step 9. |
| 9 CHECK MAIN FAN MOTOR. Connect the battery positive (+) terminal to terminal No. 1 and 2, and negative (-) terminal to terminal No. 3 and 4. | Does the main fan rotate? | Repair the poor contact in main fan motor connector. | Replace the main fan motor with a new one. |
| 10 CHECK OPERATION OF SUB FAN MOTOR. Check the operation of sub fan motor. | Does the radiator sub fan operate? | Go to step 15 . | Go to step 11 . |
| 11 CHECK POWER SUPPLY TO SUB FAN MOTOR. CAUTION: Be careful not to overheat the engine during repair. Turn the ignition switch to OFF. Disconnect the connector from sub fan motor. Start the engine, and warm it up until engine coolant temperature increases over 100°C(212°F). Stop the engine and turn the ignition switch to ON. Measure the voltage between sub fan motor connector and chassis ground. Connector & terminal (F16) No. 1, 2 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 12 . | Repair the open circuit in harness for power supply circuit. |
| 12 CHECK GROUND CIRCUIT OF SUB FAN MOTOR. Turn the ignition switch to OFF. Measure the resistance between sub fan motor connector and chassis ground. Connector & terminal (F16) No. 3,4 - Chassis ground | Is the resistance less than 1 ohms? | Go to step 13 . | Repair the open circuit in harness between sub fan motor connector and chassis ground. |
| 13 CHECK POOR CONTACT. Check poor contact in sub fan motor connector. | Is there poor contact in sub fan motor connector? | Repair the poor contact in sub fan motor connector. | Go to step 14 . |
| 14 CHECK SUB FAN MOTOR. Connect the battery positive (+) terminal to terminal No. 1 and 2, and negative (-) terminal to terminal No. 3 and 4. | Does the sub fan rotate? | Repair the poor contact in sub fan motor connector. | Replace the sub fan motor with a new one. |
| 15 CHECK EACH SENSOR AND POTENTIOMETER. Check the sensors and potentiometer for proper operation using the self-diagnostic function. < Ref. to DIAGNOSTIC CHART FOR SELF-DIAGNOSIS . > | Is the operation of each sensor and potentiometer normal? | Go to step 16 . | Check the sensor and circuit. < Ref. to DIAGNOSTIC PROCEDURE FOR SENSORS . > |
| 16 CHECK CONNECTION OF ASPIRATOR HOSE. Make sure the connection of aspirator hose is correct. | Is the connection of aspirator hose correct? | Go to step 17 . | Repair the aspirator hose connection. |
| 17 CHECK EACH ACTUATOR. Check the actuators for proper operation using the self-diagnostic function. < Ref. to DIAGNOSTIC CHART FOR SELF-DIAGNOSIS . > | Is the operation of each actuator normal? | Go to step 18. | Check the actuator and circuit. < Ref. to DIAGNOSTIC PROCEDURE FOR ACTUATORS . > |
| 18 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
| CAUTION |
|---|
| Be careful not to overheat the engine during repair. |
| CAUTION |
|---|
| Be careful not to overheat the engine during repair. |
DIAGNOSTICS CHART
INTAKE DOOR ACTUATOR
TROUBLE SYMPTOM
FRESH/RECIRC mode is not changed.
WIRING DIAGRAM
Wiring Diagram - Intake Door Actuator. Scheme 11
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK FUSE. Remove the No. 17 fuse in fuse & relay box. Check the condition of fuse. | Is the fuse blown-out? | Replace the fuse. | Go to step 2. |
| 2 CHECK SIGNAL VOLTAGE. Change the air intake to RECIRC by pushing FRESH/RECIRC switch. Measure the voltage between auto A/C control module and chassis ground. Connector & terminal (B282) No. 15 (+) - Chassis ground (-) | Is the voltage less than 1 V? | Go to step 3. | Repair the short circuit in harness for power supply line. |
| 3 CHECK SIGNAL VOLTAGE. Change the air intake to FRESH with pushing FRESH/RECIRC switch. Measure the voltage between auto A/C control module and chassis ground. Connector & terminal (B282) No. 7 (+) - Chassis ground (-) | Is the voltage less than 1 V? | Go to step 4. | Repair the short circuit in harness for power supply line. |
| 4 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND FRESH/RECIRC ACTUATOR. Turn the ignition switch to OFF. Disconnect the connector from auto A/C control module and intake door actuator. Measure the resistance of harness between auto A/C control module and intake door actuator. Connector & terminal (B282) No. 15 - (B91) No. 1 | Is the resistance less than 1 ohms? | Go to step 5. | Repair the open circuit in harness between auto A/C control module and intake door actuator. |
| 5 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND FRESH/RECIRC ACTUATOR. Measure the resistance of harness between auto A/C control module and intake door actuator. Connector & terminal (B282) No. 7-(B91) No. 2 | Is the resistance less than 1 ohms? | Go to step 6. | Repair the open circuit in harness between auto A/C control module and intake door actuator. |
| 6 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
MODE DOOR ACTUATOR
TROUBLE SYMPTOM
Air flow outlet is not changed.
WIRING DIAGRAM
Wiring Diagram - Mode Door Actuator. Scheme 12
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK POWER SUPPLY FOR AUTO A/C CONTROL MODULE SIDE. Turn the ignition switch to ON. Turn the A/C switch to ON. Measure the voltage between auto A/C control module harness connector terminal and chassis ground. Connector & terminal (B283) No. 6 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 2. | Replace the auto A/C control module. |
| 2 CHECK POWER SUPPLY FOR ACTUATOR SIDE. Measure the voltage between mode door actuator harness connector terminal and chassis ground. Connector & terminal (B77) No. 1 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 3. | Repair the open circuit in harness between auto A/C control module and mode door actuator. |
| 3 CHECK SIGNAL FOR AUTO A/C CONTROL MODULE SIDE. Measure the voltage between auto A/C control module harness connector terminal and chassis ground with oscilloscope. Connector & terminal (B282) No. 12 (+) - Chassis ground (-) | Is the voltage approx. 5.5 V? | Go to step 4. | Replace the auto A/C control module. |
| 4 CHECK SIGNAL FOR ACTUATOR SIDE. Measure the voltage between mode door actuator harness connector terminal and chassis ground. Connector & terminal (B77) No. 3 (+) - Chassis ground (-) | Is the voltage approx. 5.5 V? | Go to step 5. | Repair the open circuit in harness between auto A/C control module and mode door actuator. |
| 5 CHECK GROUND CIRCUIT OF ACTUATOR. Turn the ignition switch and A/C switch to OFF. Measure the resistance between mode door actuator harness connector terminal and chassis ground. Connector & terminal (B77) No. 2 - Chassis ground | Is the resistance less than 1 ohms? | Go to step 6. | Repair the open circuit in harness between mode door actuator and chassis ground. |
| 6 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
AIR MIX DOOR ACTUATOR
TROUBLE SYMPTOM
Outlet air temperature is not changed.
WIRING DIAGRAM
Wiring Diagram - Air Mix Door Actuator. Scheme 13
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK POWER SUPPLY FOR AUTO A/C CONTROL MODULE SIDE. Turn the ignition switch to ON. Turn the A/C switch to ON. Measure the voltage between auto A/C control module harness connector terminal and chassis ground. Connector & terminal (B283) No. 5 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 2. | Replace the auto A/C control module. |
| 2 CHECK POWER SUPPLY FOR ACTUATOR SIDE. Measure the voltage between air mix door actuator harness connector terminal and chassis ground. Connector & terminal (B293) No. 1 (+) - Chassis ground (-) | Is the voltage more than 10 V? | Go to step 3. | Repair the open circuit in harness between auto A/C control module and air mix door actuator. |
| 3 CHECK SIGNAL FOR AUTO A/C CONTROL MODULE SIDE. Measure the voltage between auto A/C control module harness connector terminal and chassis ground with oscilloscope. Connector & terminal (B282) No. 4 (+) - Chassis ground (-) | Is the voltage approx. 5.5 V? | Go to step 4. | Replace the auto A/C control module. |
| 4 CHECK SIGNAL FOR ACTUATOR SIDE. Measure the voltage between air mix door actuator harness connector terminal and chassis ground with oscilloscope. Connector & terminal (B293) No. 3 (+) - Chassis ground (-) | Is the voltage approx. 5.5 V? | Go to step 5. | Repair the open circuit in harness between auto A/C control module and air mix door actuator. |
| 5 CHECK GROUND CIRCUIT OF ACTUATOR. Turn the ignition switch and A/C switch to OFF. Measure the resistance between air mix door actuator harness connector terminal and chassis ground. Connector & terminal (B293) No. 2 - Chassis ground | Is the resistance less than 1 ohms? | Go to step 6. | Repair the open circuit in harness between air mix door actuator and chassis ground. |
| 6 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
AMBIENT SENSOR
TROUBLE SYMPTOM
Fan speed is not switched when the fan speed control dial is in AUTO position.
WIRING DIAGRAM
Wiring Diagram - Ambient Sensor. Scheme 14
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK AMBIENT SENSOR. Turn the ignition switch to OFF. Disconnect the connector from ambient sensor. Measure the resistance between connector terminals of ambient sensor. Terminals No. 1 - No. 2 | Is the resistance approx. 2.2 kohms at 25°C (77°F)? | Go to step 2. | Replace the ambient sensor. |
| 2 CHECK INPUT SIGNALS FOR AMBIENT SENSOR. Turn the ignition ON. Measure the voltage between (F78) connector terminals. Connector & terminal (F78) No. 1 (+) - No. 2 (-) | Is the voltage approx. 5 V? | Go to step 6. | Go to step 3. |
| 3 CHECK OUTPUT SIGNALS FROM AUTO A/C CONTROL MODULE. Turn the ignition switch to OFF. Pull out the auto A/C control module. Disconnect the connector from ambient sensor. Turn the ignition switch to ON. Measure the voltage between connector terminals of auto A/C control module. Connector & terminal (B283) No. 9 (+) - No. 17(-) | Is the voltage approx. 5 V? | Go to step 4. | Go to step 6. |
| 4 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND AMBIENT SENSOR. Turn the ignition switch to OFF. Disconnect the connectors from auto A/C control module. Measure the resistance of harness between auto A/C control module and ambient sensor. Connector & terminal (F78) No. 1 - (B283) No. 9 | Is the resistance less than 1 ohms? | Go to step 5. | Repair the open circuit in harness between auto A/C control module and ambient sensor. |
| 5 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND AMBIENT SENSOR. Measure the resistance of harness between auto A/C control module and ambient sensor. Connector & terminal (F78) No. 2 - (B283) No. 17 | Is the resistance less than 1 ohms? | Go to step 6. | Repair the open circuit in harness between auto A/C control module and ambient sensor. |
| 6 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
IN-VEHICLE SENSOR
TROUBLE SYMPTOM
- When turning the AUTO switch to ON, blower fan speed, outlet port and inlet port is not changed.
- If the switch LED indicates that the sensor is malfunctioning, replace the auto A/C control module. The in-vehicle sensor is built into the auto A/C control module and cannot be replaced as a single unit.
EVAPORATOR SENSOR
WIRING DIAGRAM
Wiring Diagram - Evaporator Sensor. Scheme 15
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK EVAPORATOR SENSOR. Turn the ignition switch to OFF. Remove the glove box. Disconnect the connector from evaporator sensor. Measure the resistance between connector terminals of evaporator sensor. Terminals No. 1 - No. 2 | Is the resistance approx. 3.3 kohms at 20°C (68°F)? | Go to step 2. | Replace the evaporator sensor. |
| 2 CHECK INPUT SIGNALS FOR EVAPORATOR SENSOR. Turn the ignition switch to ON. Measure the voltage between (B256) connector terminal and chassis ground. Connector & terminal (B256) No. 2 (+) - Chassis ground (-) | Is the voltage approx. 5 V? | Go to step 6. | Go to step 3. |
| 3 CHECK OUTPUT SIGNALS FROM AUTO A/C CONTROL MODULE. Turn the ignition switch to OFF. Pull out the auto A/C control module. Turn the ignition switch to ON. Measure the voltage between auto A/C control module connector terminals. Connector & terminal (B283) No. 7 (+) - No. 17 (-) | Is the voltage approx. 5 V? | Go to step 4. | Go to step 6. |
| 4 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND EVAPORATOR SENSOR. Turn the ignition switch to OFF. Disconnect the connectors from auto A/C control module. Measure the resistance of harness between auto A/C control module and evaporator sensor. Connector & terminal (B256) No. 2 - (B283) No. 7 | Is the resistance less than 1 ohms? | Go to step 5. | Repair the open circuit in harness between auto A/C control module and evaporator sensor. |
| 5 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND EVAPORATOR SENSOR. Measure the resistance of harness between auto A/C control module and evaporator sensor. Connector & terminal (B256) No. 1 - (B283) No. 17 | Is the resistance less than 1 ohms? | Go to step 6. | Repair the open circuit in harness between auto A/C control module and evaporator sensor. |
| 6 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
SUNLOAD SENSOR
TROUBLE SYMPTOM
- Sensor identified that sunlight is at maximum. Then, A/C system is controlled to COOL side.
- Sensor identified that sunlight is at minimum. Then, A/C system is controlled to HOT side.
Note. When the sunload sensor is checked indoors or in the shade, it may be diagnosed as open circuit. Always check the sunload sensor at a place where sun shines directly on it.
WIRING DIAGRAM
Wiring Diagram - Sunload Sensor. Scheme 16
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK INPUT VOLTAGE TO SUNLOAD SENSOR. Turn the ignition switch to ON. Measure the input voltage to sunload sensor. Connector & terminal (i51) No. 2 (+) - Chassis ground (-) | Is the voltage approx. 5 V? | Go to step 3. | Go to step 2. |
| 2 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND SUN-LOAD SENSOR. Turn the ignition switch to OFF. Disconnect the connectors from auto A/C control module. Measure the resistance of harness between auto A/C control module and sunload sensor. Connector & terminal (i51) No. 2 - (B283) No. 16 | Is the resistance less than 1 ohms? | Go to step 3. | Repair the harness between auto A/C control module and sunload sensor. |
| 3 CHECK HARNESS CONNECTOR BETWEEN AUTO A/C CONTROL MODULE AND SUNLOAD SENSOR. Measure the resistance of harness between auto A/C control module and sunload sensor. Connector & terminal (i51) No. 1 - (B283) No. 17 | Is the resistance less than 1 ohms? | Go to step 4. | Repair the harness between auto A/C control module and sunload sensor. |
| 4 CHECK THE INPUT VOLTAGE TO AUTO A/C CONTROL MODULE. Connect the auto A/C control module connector. Turn the ignition switch to ON. Measure the voltage between auto A/C control module connector terminals. Connector & terminal (B283) No. 16(+) - (B283) No. 17 (-) | Is the voltage approx. 2.5 V? | Go to step 5. | Replace the sunload sensor. |
| 5 CHECK POOR CONTACT. Check poor contact in auto A/C control module connector. | Is there poor contact in connector? | Repair the connector. | Replace the auto A/C control module. |
DIAGNOSTICS CHART
| Symptom | Problem parts |
|---|---|
| A/C system fails to operate. | Fuse (M/B No. 5, F/B No. 17) Connector (Poor contact) Ground Auto A/C control module Blower fan motor Blower fan relay A/C Relay Compressor (Magnet clutch) Evaporator sensor |
| Fuse is blown out. | Fuse (M/B No. 5, F/B No. 17) Connector (Poor contact) |
| Illumination cannot dim. | Fuse (M/B No. 5, F/B No. 17) Connector (Poor contact) Auto A/C control module |
| Blower fan does not rotate or fan speed cannot be controlled. | Fuse (M/B No. 7, F/B No. 17) Connector (Poor contact) Ground Auto A/C control module Blower fan motor Blower fan relay |
| Unable to switch suction vents. | Connector (Poor contact) Auto A/C control module Intake door actuator |
| Unable to switch blow vents. | Connector (Poor contact) Auto A/C control module Mode door actuator |
| Compartment temperature does not increase. (No hot air is discharged.) | Connector (Poor contact) Auto A/C control module Air mix door actuator In-vehicle sensor, ambient sensor, evaporator sensor and sunload sensor In-vehicle sensor aspirator hose |
| Compartment temperature does not decrease. (No cool air is discharged.) | Connector (Poor contact) Auto A/C control module Air mix door actuator A/C Relay Compressor (Magnet clutch) Radiator fan motor Radiator fan relay In-vehicle sensor, ambient sensor, evaporator sensor and sunload sensor In-vehicle sensor aspirator hose |
| Compartment temperature is higher or lower than setting temperature. | Auto A/C control module Air mix door actuator In-vehicle sensor, ambient sensor, evaporator sensor and sunload sensor In-vehicle sensor aspirator hose |
| Compartment temperature does not quickly respond to setting temperature. | Air mix door actuator In-vehicle sensor, ambient sensor, evaporator sensor and sunload sensor In-vehicle sensor aspirator hose |
| Radiator fan does not rotate during A/C operation. | Radiator fan motor Radiator fan relay |
PROBLEM SYMPTOMS
