READ DIAGNOSTIC TROUBLE CODE (DTC)
When malfunction of airbag system occurs, the DTC stored in airbag control module will be read out.
Scheme 152
Scheme 153
Scheme 154
Scheme 155
- Prepare the Subaru Select Monitor kit. < Ref. to «SPECIAL TOOL»(/subaru/impreza-wrx/gdgg-2-2005-2007/remont/airbag/#airbag-system-diagnostics__special-tool) , PREPARATION TOOL, General Description. >
- Connect the diagnosis cable to Subaru Select Monitor.
- Insert the cartridge into Subaru Select Monitor. < Ref. to «SPECIAL TOOL»(/subaru/impreza-wrx/gdgg-2-2005-2007/remont/airbag/#airbag-system-diagnostics__special-tool) , PREPARATION TOOL, General Description. >
- Connect the Subaru Select Monitor to data link connector. Data link connector is located in the lower portion of the instrument panel (on the driver's side). Connect the diagnosis cable to data link connector. CAUTION: Do not connect the scan tools except for Subaru Select Monitor.
- Turn the ignition switch to ON (engine OFF), and Subaru Select Monitor power switch to ON.
- On the «Main Menu» display screen, select the {Each System Check} and press the [YES] key.
- On the «System Selection Menu» display screen, select the {Airbag System} and press the [YES] key.
- Press the [YES] key after the {AIRBAG SYSTEM} is displayed.
- On the «Airbag System» display screen, select the {DTC Display} and press the [YES] key.
Note. For details concerning operation procedure, refer to the "SUBARU SELECT MONITOR OPERATION MANUAL". For details concerning DTCs, < Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . >
