Engine Controls - Engine (diagnostics) (H4SO) (except Sti) Subaru Impreza WRX STI GR

DIAGNOSTIC PROCEDURE CHART

CHECK LIST NO. 1

Check the following item when problem has occurred.

Note. Use copies of this page for interviewing customers.

Scheme 112

CHECK LIST NO. 2

Check the following item about the vehicle's state when malfunction indicator light turns on.

Note. Use copies of this page for interviewing customers.

Scheme 113

Scheme 114

Scheme 115

1. Airbag system wiring harness is routed near the ECM, main relay and fuel pump relay. CAUTION: Do not use electrical test equipment on the airbag system circuits. Be careful not to damage the airbag system wiring harness when servicing the ECM, TCM, main relay and fuel pump relay.
2. Never connect the battery in reverse polarity. Doing so will damage the ECM instantly, and other parts will also be damaged.
3. Do not disconnect the battery terminals while the engine is running. A large counter electromotive force will be generated in the generator, and this voltage may damage electronic parts such as ECM etc.
4. Before disconnecting the connectors of each sensor and ECM, be sure to turn the ignition switch to OFF. Perform the Clear Memory Mode after connecting the connectors. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
5. When measuring the voltage or resistance of individual sensor or all electrical control modules, use a tapered pin with a diameter of less than 0.6 mm (0.024 in). Do not insert the pin 4 mm (0.16 in) or more into the part. CAUTION: When replacing the ECM, be careful not to use the wrong spec. ECM to avoid any damage on the fuel injection system. NOTE: When replacing the ECM of the models with Immobilizer, immobilizer system must be registered. To do so, all ignition keys and ID cards need to be prepared. Refer to the "PC application help for Subaru Select Monitor".
6. Take care not to allow water to get into the connectors when servicing or washing the vehicle in rainy weather. Avoid exposure to water even if the connectors are waterproof.
7. Use ECM mounting stud bolts at the body side grounding point when measuring voltage and resistance inside the passenger compartment.
8. Use the engine ground terminal or engine assembly for the grounding point to chassis when measuring the voltage and resistance in engine compartment.
9. Every engine control system-related part is a precision part. Do not drop them.
10. Observe the following cautions when installing a radio in vehicle. CAUTION: The antenna must be kept as far apart as possible from control module. (ECM is installed under the passenger's side floor mat.) The antenna feeder must be placed as far apart as possible from the ECM and engine control system harness. Carefully adjust the antenna for correct matching. When mounting a large power type radio, pay special attention to the three items mentioned above. Incorrect installation of the radio may affect the operation of ECM.
11. When disconnecting the fuel hose, release the fuel pressure. Refer to «RELEASING OF FUEL PRESSURE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/fuel-system/#fuel-injection-system-h4so-except-sti__releasing-of-fuel-pressure) , PROCEDURE, Fuel.
12. Warning lights may illuminate when performing driving test with jacked-up or lifted-up condition, but this is not a system malfunction. The reason for this is the speed difference between the front and rear wheels. After diagnosis of engine control system, perform the ABS memory clear procedure of self-diagnosis function.

INSPECTION

Before performing diagnostics, check the following item which might affect engine problems.

BATTERY

1. Measure the battery voltage and specific gravity of the electrolyte. Standard voltage: 12 V Specific gravity: 1.260 or more
2. Check the condition of the main and other fuses, and harnesses and connectors. Also check for proper grounding.

ENGINE GROUND

Check if the engine ground terminal is properly connected to engine.

NOTE

1. The on-board diagnostic (OBD) system detects and indicates a fault in various inputs and outputs of the complex electronic control. Malfunction indicator light in the combination meter indicates occurrence of a fault or trouble.
2. Further, against such a failure of sensors as may disable the drive, the fail-safe function is provided to ensure the minimal driveability.
3. The OBD system incorporated with the vehicles within this type of engine complies with OBD-II regulations. The OBD system monitors the components and the system malfunction listed in appropriate Engine article which affects on emissions.
4. When the system decides that a malfunction occurs, malfunction indicator light illuminates. At the same time of the malfunction indicator light illumination or blinking, a DTC and a freeze frame engine conditions are stored into on-board computer.
5. The OBD system stores freeze frame engine condition data (engine load, engine coolant temperature, fuel trim, engine speed and vehicle speed, etc.) into on-board computer when it detects a malfunction.
6. Freeze frame engine condition data are stored until the DTCs are cleared. However when such malfunctions as fuel trim fault and misfire are detected with the freeze frame engine condition data stored, they are rewritten into those related to the fuel trim fault and misfire.
7. When the malfunction does not occur again for three consecutive driving cycles, malfunction indicator light is turned off, but DTC remains at on-board computer.
8. When performing diagnosis, connect the Subaru Select Monitor or general scan tool to the vehicle.

PREPARATION TOOL

PREPARATION TOOL REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system. 499987500 CRANKSHAFT SOCKET Used for rotating crankshaft

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

ECM CONNECTOR REFERENCE

WAVEFORM REFERENCE Input/output name Measuring condition Waveform 1. Crankshaft position sensor At idling 2. Camshaft position sensor At idling

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

ELECTRICAL SPECIFICATION

SPECIFICATION CHART

Measuring condition

1. After engine is warmed-up.
2. Set the select lever in "P" range or "N" range, or the shift lever in neutral.
3. Turn the A/C to OFF.
4. Turn all the accessory switches to OFF.

This connector is used for Subaru Select Monitor.

Scheme 139

DLC CONNECTOR TERMINALS REFERENCE

Scheme 140

1. Prepare a scan tool (general scan tool) required by SAE J1978.
2. Connect the general scan tool to data link connector located in the lower portion of the instrument panel (on the driver's side).
3. Using the general scan tool, call up DTC and freeze frame data. General scan tool functions consist of: MODE $01: Current powertrain diagnostic data MODE $02: Powertrain freeze frame data MODE $03: Emission-related powertrain DTC MODE $04: Clear/Reset emission-related diagnostic information MODE $06: Request on-board monitoring test results for intermittently monitored systems MODE $07: Request on-board monitoring test results for continuously monitored systems MODE $09: Request vehicle information

Note. Read out the data according to repair procedures. (For detailed operation procedure, see the general scan tool operation information.) For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

MODE $01: (CURRENT POWERTRAIN DIAGNOSTIC DATA)

Refer to data denoting the current operating condition of analog input/output, digital input/output or the powertrain system.

A list of the support data and PID (Parameter Identification) codes are shown in the following table.

SUPPORT DATA AND PID REFERENCE

MODE $02 (POWERTRAIN FREEZE FRAME DATA)

Refer to data denoting the operating condition when trouble is detected by on-board diagnosis system. A list of the support data and PID (Parameter Identification) codes are shown in the following table.

SUPPORT DATA AND PID CODES REFERENCE

MODE $03 (EMISSION-RELATED POWERTRAIN DTC)

Refer to "List of Diagnostic Trouble Code (DTC)" for information about data denoting emission-related powertrain DTC. Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

MODE $04 (CLEAR/RESET EMISSION-RELATED DIAGNOSTIC INFORMATION)

Refer to the mode used to clear or reset emission-related diagnostic information (OBD-II trouble diagnostic information).

Note. Refer to general scan tool manufacturer's instruction information to clear the emission-related diagnostic information (MODE $04).

MODE $06

Refer to test value of troubleshooting and data of test limit indicated on the support data bit sequence table. A list of the support data is shown in the following table.

SUPPORT DATA REFERENCE

MODE $07

Refer to the data of DTC (pending code) for troubleshooting result about emission in the first time.

MODE $09

Refer to data of vehicle specification (V.I.N. calibration ID, diagnosis frequency etc.).

Scheme 141

1. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti__preparation-tool) , General Description.
2. Prepare the personal computer which has been installed the Subaru Select Monitor.
3. Connect the USB cable between SDI (Subaru Diagnosis Interface) and USB port on the personal computer (dedicated port for the Subaru Select Monitor). NOTE: The dedicated port for the Subaru Select Monitor means the USB port which was used to install the Subaru Select Monitor.
4. Connect the diagnosis cable to the SDI.
5. Connect the SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools except for Subaru Select Monitor and general scan tool.
6. Start up the personal computer.
7. Turn the ignition switch to ON (engine OFF), and run the "PC application for Subaru Select Monitor".
8. Call up DTC and data, then record them. NOTE: For detailed operation procedure, see the "PC application help for Subaru Select Monitor".

READ CURRENT DATA FOR ENGINE (NORMAL MODE)

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {Current Data Display&Save}.
5. On «Current Data Display&Save» display, select {Normal sampling}.
6. Using the scroll key, scroll the display screen up or down until the desired data is shown. A list of the support data is shown in the following table.

DISPLAY CONTENTS REFERENCE

READ CURRENT DATA FOR ENGINE (OBD MODE)

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {OBD System}.
5. On «OBD Menu» display, select {Current Data Display&Save}.
6. On «Current Data Display&Save» display, select {All data display}.
7. Using the scroll key, scroll the display screen up or down until the desired data is shown. A list of the support data is shown in the following table.

DISPLAY CONTENTS REFERENCE

READ FREEZE FRAME DATA FOR ENGINE (OBD MODE)

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {OBD System}.
5. On «OBD Menu» display, select {Freeze Frame Data Display}. A list of the support data is shown in the following table.

DISPLAY CONTENTS REFERENCE

.N REGISTRATION

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {Entry VIN}.
5. Perform the procedures shown on the display screen. NOTE: For detailed operation procedures, see "PC application help for Subaru Select Monitor".

SUBARU SELECT MONITOR (NORMAL MODE)

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {Diagnostic Code(s) Display}.
5. On «Diagnostic Code(s) Display» display, select {Temporary Diagnostic Code(s)} or {Memorized Diagnostic Code(s)}.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor". For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

SUBARU SELECT MONITOR (OBD MODE)

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {OBD System}.
5. On «OBD Menu» display, select {Diagnostic Code(s) Display}.
6. Make sure DTC is shown on the screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor". For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

GENERAL SCAN TOOL

Refer to data denoting emission-related powertrain DTC.

For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

Note. Refer to general scan tool manufacturer's instruction information to access powertrain DTC (MODE $03).

PROCEDURE

Perform the diagnosis shown in the following DTC table.

When performing the diagnosis not listed in "List of Diagnostic Trouble Code (DTC)", see the item on the drive cycle. Refer to DRIVE CYCLE .

DTC CHART

PREPARATION FOR THE INSPECTION MODE

1. Check that the battery voltage is 12 V or more and fuel remains approx. half [20 - 40 l (5.3 - 10.6 US gal, 4.4 - 8.8 lmp gal)].
2. Lift up the vehicle using a garage jack and place it on rigid racks, or drive the vehicle onto free rollers.

Scheme 142

Scheme 143

1. Check that no DTC remains after clearing memory. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
2. Warm up the engine.
3. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti__preparation-tool) , General Description.
4. Prepare PC with Subaru Select Monitor installed.
5. Connect the USB cable to SDI (Subaru Diagnosis Interface) and USB port on the personal computer (dedicated port for the Subaru Select Monitor). NOTE: The dedicated port for the Subaru Select Monitor means the USB port which was used to install the Subaru Select Monitor.
6. Connect the diagnosis cable to SDI.
7. Connect the delivery (test) mode connector (A) located under the glove box.
8. Connect SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools except for Subaru Select Monitor and general scan tool.
9. Start the PC.
10. Turn the ignition switch to ON (engine OFF) and run the "PC application for Subaru Select Monitor".
11. On «Main Menu» display, select {Each System Check}.
12. On «System Selection Menu» display, select {Engine Control System}.
13. Click the [OK] button after the information of engine type has been displayed.
14. On «Engine Diagnosis» display, select {Dealer Check Mode Procedure}.
15. When the «Perform Inspection (Dealer Check) Mode?» is shown on the screen, click the [Next] button.
16. Perform subsequent procedures as instructed on the display screen. If trouble still remains in the memory, the corresponding DTC appears on the display screen. NOTE: For detailed operation procedures, see "PC application help for Subaru Select Monitor". For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to «LIST OF DIAGNOSTIC TROUBLE CODE (DTC)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) . Release the parking brake. The speed difference between front and rear wheels may light the ABS warning light, but this does not indicate a malfunction. When engine control diagnosis is finished, perform the ABS memory clearance procedure of self-diagnosis function. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/anti-locktraction-control/#brakes-abs-diagnostics-except-sti) .

1. After performing the diagnostics and clearing the memory, check that no DTC remains. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
2. Warm up the engine.
3. Connect the delivery (test) mode connector (A) located under the glove box.
4. Connect the general scan tool to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools except for Subaru Select Monitor and general scan tool.
5. Start the engine. NOTE: Ensure the selector lever is placed in "P" range before starting. (AT model) Depress the clutch pedal when starting engine. (MT model)
6. Turn the neutral position switch to ON using select lever or shift lever.
7. Depress the brake pedal to turn the brake switch ON. (AT model)
8. Keep the engine speed in 2,500 - 3,000 rpm range for 40 seconds.
9. Place the select lever or shift lever in D position (AT model) or 1st gear (MT model) and drive the vehicle at 5 to 10 km/h (3 to 6 MPH). NOTE: For AWD model, release the parking brake. The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunctions. When engine control diagnosis is finished, perform the ABS memory clearance procedure of self-diagnosis system. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/anti-locktraction-control/#brakes-abs-diagnostics-except-sti) .
10. Using the general scan tool, check for DTC and record the result(s). NOTE: For detailed operation procedures, see the general scan tool operation information. For details concerning DTC, see "List of Diagnostic Trouble Code (DTC)". Refer to «LIST OF DIAGNOSTIC TROUBLE CODE (DTC)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .

For the troubleshooting, there are driving patterns described below. Driving in the specified pattern allows to diagnose malfunctioning items listed below. After the repair of the following trouble items, be sure to drive the vehicle with the specified drive patterns to check whether the function is resumed correctly.

PREPARATION FOR DRIVE CYCLE

1. Check that the battery voltage is 12 V or more and fuel remains approx. half [20-40 l (5.3-10.6 US gal, 4.4 - 8.8 lmp gal)].
2. After performing the diagnostics and clearing the memory, check that no DTC remains. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
3. Disconnect the delivery (test) mode connector. NOTE: Perform the diagnosis after warming up the engine except when the engine coolant temperature at starting is specified. Perform the diagnosis twice if the DTC marked with*. After completing the first diagnosis, stop the engine and perform second diagnosis in same condition.

DRIVE CYCLE A - DRIVE THE VEHICLE WITH 80 KM/H (50 MPH) FOR 20 MINUTES, AND THEN IDLE THE ENGINE FOR A MINUTE

DTC CHART

DRIVE CYCLE B -10 MINUTES IDLING

Note. Drive the vehicle at 10 km/h (6 MPH) or more before diagnosis.

DTC CHART

Scheme 144

DTC CHART

DRIVE CYCLED

1. DRIFT DIAGNOSIS Make sure that the engine coolant temperature at engine starting is less than 30°C (86°F). Make sure that fuel remains 10 l (2.6 US gal, 2.2 lmp gal) or more and the battery voltage is 10.9 V or more. Start the engine, and check that the engine coolant temperature increases by 10°C (50°F) or more, and reaches 75°C (167°F) or more, when the engine is warmed up. Idle the engine for 120 seconds or more in the condition of step 3).
2. STUCK DIAGNOSIS Make sure that the battery voltage is 10.9 V or more. Perform the Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) . Drive for approximately 50 l (13.2 US gal, 11 lmp gal) of fuel. NOTE: It is acceptable to drive the vehicle intermittently. Do not disconnect the battery terminals while diagnosing. (Data will be cleared by disconnecting the battery terminals.)

DTC CHART

DRIVE CYCLE E

1. Make sure that the battery voltage is 10.9 V or more.
2. Perform the Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
3. Drive for approximately 30 l (7.9 US gal, 6.6 lmp gal) of fuel.

Note. It is acceptable to drive the vehicle intermittently. Do not disconnect the battery terminals while diagnosing. (Data will be cleared by disconnecting the battery terminals.)

DTC CHART

DRIVE CYCLE F

1. Make sure that the engine coolant temperature at engine starting is less than 30°C (86°F).
2. Start the engine, and warm it up until engine coolant temperature increases over 95°C (203°F).
3. Idle the engine for 10 minutes or more in the condition of step 2.

Note. Do not disconnect the battery terminals while diagnosing. (Data will be cleared by disconnecting the battery terminals.)

DTC CHART

DRIVE CYCLE H

1. Perform the Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) .
2. With the ignition switch ON, read the engine coolant temperature, intake air temperature and fuel temperature. Refer to «READ CURRENT DATA FOR ENGINE (NORMAL MODE)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti__read-current-data-for-engine-normal) , OPERATION, Subaru Select Monitor.
3. If the values from step 2) satisfy the following two conditions, start the engine. Condition: |Engine coolant temperature - Intake air temperature | < or = 5°C (41 °F) |Engine coolant temperature - Fuel temperature | < or = 2°C (36°F) NOTE: If the conditions are not satisfied, turn the ignition switch to OFF and wait until the parameters are satisfied. Start AT vehicles in the "P" range, and MT vehicles in the neutral position.
4. Idle the engine for 1 minute under the conditions in step 3). DTC CHART DTC Item Condition *P1602 Control Module Programming Error

OPERATION

Note. When Clear Memory Mode is performed in OBD mode of Subaru Select Monitor, only DTCs are cleared.

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {Clearing Memory}.
5. When the "Clear Memory?" is shown on the screen, click the [YES] button.
6. When "Done" and "Turn off the ignition switch." are shown on the display screen, turn the ignition switch to OFF.

Note. Initial diagnosis of electronic throttle control is performed after memory clearance. Wait for 10 seconds or more after turning the ignition switch to ON, and then start the engine. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

1. On «Main Menu» display, select {Each System Check}.
2. On «System Selection Menu» display, select {Engine Control System}.
3. Click the [OK] button after the information of engine type has been displayed.
4. On «Engine Diagnosis» display, select {OBD System}.
5. On «OBD Menu» display, select {Clear Diagnostic Code}.
6. When the "Clear Diagnostic Code?" is shown on the screen, click the [Yes] button.
7. When "Done" and "Turn off the ignition switch." are shown on the display screen, turn the ignition switch to OFF.

Note. Initial diagnosis of electronic throttle control is performed after memory clearance. Wait for 10 seconds or more after turning the ignition switch to ON, and then start the engine. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

For clear memory procedures using the general scan tool, see "General Scan Tool Instruction information".

Note. Initial diagnosis of electronic throttle control is performed after memory clearance. For this reason, start the engine after 10 seconds or more have elapsed since the ignition switch was turned to ON.

1. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti__preparation-tool) , General Description.
2. Prepare PC with Subaru Select Monitor installed.
3. Connect the USB cable to SDI (Subaru Diagnosis Interface) and USB port on the personal computer (dedicated port for the Subaru Select Monitor). NOTE: The dedicated port for the Subaru Select Monitor means the USB port which was used to install the Subaru Select Monitor.
4. Connect the diagnosis cable to SDI.
5. Connect the delivery (test) mode connector (A) located under the glove box.
6. Connect SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools except for Subaru Select Monitor and general scan tool.
7. Start the PC.
8. Turn the ignition switch to ON (engine OFF) and run the "PC application for Subaru Select Monitor".
9. On «Main Menu» display, select {Each System Check}.
10. On «System Selection Menu» display, select {Engine Control System}.
11. Click the [OK] button after the information of engine type has been displayed.
12. On «Engine Diagnosis» display, select {System Operation Check Mode}.
13. On «System Operation Check Mode» display, select {Actuator ON/OFF Operation}.
14. Select the desired compulsory actuator on the «Actuator ON/OFF Operation» display screen and click the [Next] button.
15. Clicking the [Exit] button completes the compulsory valve operation check mode. The display will then return to the «Actuator ON/OFF Operation» screen. A list of the support data is shown in the following table. DISPLAY DESCRIPTION Description Display Compulsory fuel pump relay operation check Fuel Pump Relay Compulsory purge control solenoid valve operation check CPC Solenoid Valve Compulsory radiator fan relay operation check Radiator Fan Relay Compulsory air conditioning relay operation check A/C Compressor Relay Compulsory pressure control solenoid valve operation check PCV Solenoid Valve Compulsory drain valve operation check Vent. Solenoid Valve NOTE: The following parts will be displayed but not functional. DISPLAY DESCRIPTION Display EGR Solenoid Valve ASV Solenoid Valve FICD Solenoid Pressure Switching Sol.1 Pressure Switching Sol.2 AAI Solenoid Valve Tank Sensor Cntl Valve Turbocharger Wastegate Solenoid EXH. Bypass Control Permit Flag Secondary Air Combi Valve 2 For detailed operation procedures, see "PC application help for Subaru Select Monitor".

1. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti__preparation-tool) , General Description.
2. Prepare PC with Subaru Select Monitor installed.
3. Connect the USB cable to SDI (Subaru Diagnosis Interface) and USB port on the personal computer (dedicated port for the Subaru Select Monitor). NOTE: The dedicated port for the Subaru Select Monitor means the USB port which was used to install the Subaru Select Monitor.
4. Connect the diagnosis cable to SDI.
5. Connect SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools except for Subaru Select Monitor and general scan tool.
6. Start the PC.
7. Turn the ignition switch to ON (engine OFF) and run the "PC application for Subaru Select Monitor".
8. On «Main Menu» display, select {Each System Check}.
9. On «System Selection Menu» display, select {Engine Control System}.
10. Click the [OK] button after the information of engine type has been displayed.
11. On «Engine Diagnosis» display, select {System Operation Check Mode}.
12. The following items are displayed on the monitor. DISPLAY DESCRIPTION Display Actuator ON/OFF Operation Immobilizer System Fuel Pump Control Fixed Idle Ignition Timing Idle Speed Control Injector Control EGR Valve Control

FUEL PUMP CONTROL (OFF DRIVE)

1. On «System Operation Check Mode» display, select {Fuel Pump Control}.
2. On «Fuel Pump Control» display, select {OFF Drive}.
3. On «Start the Engine» display, start the engine and click the [OK] button.
4. On «OFF Drive» display, click the [Execution] button and execute the OFF drive.
5. Click the [Cancel] button to stop the OFF drive.
6. Click the [Exit] button to end the OFF drive. The screen will return to the «Fuel Pump Control» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

FUEL PUMP CONTROL (ON/OFF DRIVE)

1. On «System Operation Check Mode» display, select {Fuel Pump Control}.
2. On «Fuel Pump Control» display, select {ON/OFF Dr.}.
3. On «Turn Ignition Switch ON with Engine OFF» display, turn the ignition switch to ON and click the [OK] button.
4. On «ON/OFF Dr.» display, click the [Execution] button and execute the ON/OFF drive.
5. Click the [Cancel] button to stop the ON/OFF drive.
6. Click the [Exit] button to end the ON/OFF drive. The screen will return to the «Fuel Pump Control» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

IDLING IGNITION TIMING FIXED

1. On «System Operation Check Mode» display, select {Fixed Idle Ignition Timing}.
2. On «Start the Engine» display, start the engine and click the [OK] button.
3. On «Fixed Idle Ignition Timing» display, click the [Execution] button and execute the idling ignition timing fixed.
4. Click the [Cancel] button to stop the idling ignition timing fixed.
5. Click the [Exit] button to end the idling ignition timing fixed. The screen will return to the «System Operation Check Mode» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

IDLE SPEED CONTROL

1. On «System Operation Check Mode» display, select {Idle Speed Control}.
2. On «Start the Engine» display, start the engine and click the [OK] button.
3. In the «Idle Speed Control» display, click the [↑] button or the [↓] button to change the setting values, then click the [OK] button. Setting is possible in a range between 500 rpm - 2,000 rpm, in increments of 50 rpm. However, the engine speed that can actually be controlled will vary depending on the vehicle.
4. Click the [Cancel] button to stop the idle speed control.
5. Click the [Exit] button to end the idle speed control. The screen will return to the «System Operation Check Mode» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

INJECTOR CONTROL (INJECTION STOP MODE)

1. On «System Operation Check Mode» display, select {Injector Control}.
2. On «Injector Control» display, select {Injection Stop Mode}.
3. On «Injection Stop Mode» display, select the fuel injector to be stopped.
4. On «Start the Engine» display, start the engine and click the [OK] button.
5. On «Fuel Injector #» display, click the [Execution] button and execute the injection stop mode.
6. Click the [Cancel] button to stop the injection stop mode.
7. Click the [Exit] button to return to the «Injection Stop Mode» display screen.
8. On «Injection Stop Mode» display, click the [Return] button to end the «Injection Stop Mode». The screen will return to the «injector Control» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

INJECTOR CONTROL (INJECTION QUANTITY CONTROL)

1. On «System Operation Check Mode» display, select {Injector Control}.
2. On «Injector Control» display, select {Injection Quantity Control}.
3. On «Start the Engine» display, start the engine and click the [OK] button.
4. In the «Injection Quantity Control» display, click the [↑] button or the [↓] button to change the setting values, then click the [OK] button. Setting is possible in a range between 0 - 20%, in increments of 1%.
5. Click the [Cancel] button to stop the injection quantity control.
6. Click the [ Exit] button to end the injection quantity control. The screen will return to the «Injector Control» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

EGR VALVE CONTROL

1. On «System Operation Check Mode» display, select {EGR Valve Control}.
2. On «Start the Engine» display, start the engine and click the [OK] button.
3. In the «EGR Valve Control» display, click the [↑] button or the [↓] button to change the setting values, then click the [OK] button. Setting is possible in increments of 1 STEP. However, the STEP number that can actually be controlled will vary depending on the vehicle.
4. Click the [Cancel] button to stop the EGR valve control.
5. Click the [Exit] button to end the EGR valve control. The screen will return to the «System Operation Check Mode» screen.

Note. For detailed operation procedures, see "PC application help for Subaru Select Monitor".

DIAGNOSTIC PROCEDURE CHART

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. When the ignition switch is turned to ON (engine OFF), the malfunction indicator light (A) in the combination meter illuminates. NOTE: If the malfunction indicator light does not illuminate, perform diagnostics of the malfunction indicator light circuit or the combination meter circuit. Refer to «MALFUNCTION INDICATOR LIGHT DOES NOT COME ON»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#engine-controls-engine-diagnostics-h4so-except-sti) , Malfunction Indicator Light.
2. After starting the engine, the malfunction indicator light goes out. If it does not go off, either the engine or emission control system has malfunction.
3. If the diagnostic system detects a misfire which could damage the catalyst, the malfunction indicator light will blink at a cycle of 1 Hz.
4. Turn the ignition switch to OFF and connect the delivery (test) mode connector. When the ignition switch is turned to ON (engine OFF), the malfunction indicator light illuminates. After the engine starts, malfunction indicator light blinks in a cycle of 0.5 Hz. (During diagnosis) Malfunction indicator light blinks at a cycle of 3 Hz after diagnosis if there is no trouble. Malfunction indicator light illuminates if faulty.

DIAGNOSIS

The malfunction indicator light circuit is open or shorted.

TROUBLE SYMPTOM

When the ignition switch is turned to ON (engine OFF), malfunction indicator light does not illuminate.

Scheme 149

DIAGNOSTIC PROCEDURE CHART

The malfunction indicator light circuit is shorted.

Although malfunction indicator light comes on when the engine runs, DTC is not shown on the Subaru Select Monitor display.

WIRING DIAGRAM

DIAGNOSTIC PROCEDURE CHART

1. The malfunction indicator light circuit is open or shorted.
2. The delivery (test) mode connector circuit is open.

Malfunction indicator light does not blink during Inspection Mode.

Scheme 150

DIAGNOSTIC PROCEDURE CHART

The delivery (test) mode connector circuit is shorted.

Malfunction indicator light blinks when delivery (test) mode connector is not connected.

DIAGNOSTIC PROCEDURE CHART

DIAGNOSTIC PROCEDURE CHART

STARTER MOTOR CIRCUIT

Scheme 151

DIAGNOSTIC PROCEDURE CHART

CHECK POWER SUPPLY AND GROUND LINE OF ENGINE CONTROL MODULE (ECM)

Scheme 152

DIAGNOSTIC PROCEDURE CHART

IGNITION CONTROL SYSTEM

Scheme 153

DIAGNOSTIC PROCEDURE CHART

FUEL PUMP CIRCUIT

Scheme 154

DIAGNOSTIC PROCEDURE CHART

FUEL INJECTOR CIRCUIT

Scheme 155

DIAGNOSTIC PROCEDURE CHART

Open or short circuit in data link connector

Subaru Select Monitor communication failure

Scheme 156

DIAGNOSTIC PROCEDURE CHART

LIST

DIAGNOSTIC TROUBLE CODE CHART

DTC DETECTING CONDITION

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0026 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE/PERFORMANCE (BANK 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

Scheme 157

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0028 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE/PERFORMANCE (BANK 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

Scheme 158

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0030 HO2S HEATER CONTROL CIRCUIT (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Scheme 159

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0031 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0032 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0037 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Scheme 160

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0038 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0068 MAP/MAF - THROTTLE POSITION CORRELATION»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Scheme 161

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0076 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

Scheme 162

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0077 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0082 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

Scheme 163

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0083 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Improper idling

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0101 MASS OR VOLUME AIR FLOW CIRCUIT RANGE/PERFORMANCE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance

Scheme 164

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0102 MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0103 MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0107 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0108 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0111 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT RANGE/PERFORMANCE»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0112 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT LOW»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0113 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT HIGH»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0117 ENGINE COOLANT TEMPERATURE CIRCUIT LOW»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Hard to start
2. Improper idling
3. Poor driving performance

Scheme 165

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0118 ENGINE COOLANT TEMPERATURE CIRCUIT HIGH»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Hard to start
2. Improper idling
3. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance

Scheme 166

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0125 INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Engine does not return to idle.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0126 INSUFFICIENT ENGINE COOLANT TEMPERATURE FOR STABLE OPERATION»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Hard to start
2. Improper idling
3. Poor driving performance

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0128 COOLANT THERMOSTAT (ENGINE COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Thermostat remains open.

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0131 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0132 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0133 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Immediately at fault recognition
2. GENERAL DESCRIPTION Refer to «DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0138 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0139 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0140 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 2)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC PROCEDURE CHART

DTC P0171 SYSTEM TOO LEAN (BANK 1)

Refer to DTC P0172 for diagnostic procedure. Refer to DTC P0172 SYSTEM TOO RICH (BANK 1) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

1. Detected when two consecutive driving cycles with fault occur.
2. GENERAL DESCRIPTION Refer to «DTC P0172 SYSTEM TOO RICH (BANK 1)»(/subaru/impreza-wrx-sti/gr-2007-2011/remont/testing-diagnostics/#diagnostic-trouble-code-dtc-detecting-criteria-h4so-except-sti) , Diagnostic Trouble Code (DTC) Detecting Criteria.

1. Improper idling
2. Engine stalls.
3. Poor driving performance
